Elk 4-Channel Recordable Voice and Siren Driver (Elk-120 module), US $69.00 – Picture 0
Elk 4-Channel Recordable Voice and Siren Driver (Elk-120 module), US $69.00 – Picture 0

Elk 4-channel Recordable Voice And Siren Driver (elk-120 Module)

US $69.00

  • Vancouver, British Columbia, Canada
  • Aug 29th
Open on mobile:
QR code
Operating Voltage: 11 to 14 Volts DC Current Draw: .2 to 2 Amps, (depends on volume setting & speaker load) Sound Level: 120 db @ 1 meter, 14 vdc, with one 8 ohm speaker Max. Speaker Loading: 4 Ohms Max. Message Length: 2 min. per channel in voice mode or 4 min. per 2 channels in siren mode Pulsing Input: 1/2 to 2 Second Pulse, 50% duty cycle Size: 3 x 5 x 1.25 (76 x 127 x 32mm) Product Overview The ELK-120 v.3 features 4 channels that can be configured as 2 channels of siren and 2 channels of voice, or all 4 channels can be used for voice. Either way the voice channels are fully recordable and are stored in non-volatile re-programmable memory. Total time of recording is 8 minutes. The Siren channels offer a choice of: Classic Yelp Sound, Temporal Coded Horn, or Pulsing Industrial Horn. The siren sounds can be triggered in sequence with the voice channels. The channels can be configured to play once or to repeat endlessly. Two channels support our unique ComboTrigger™ feature, especially designed for controls that have a single alarm output with a pulsing option for fire or burglary. When pulsed, the Temporal Coded Horn fire signal is sounded. The optional ELK-129 Computer Interface may be used to download .WAV sounds from a PC to the ELK-120. Also available is the ELK-124 offering eight recordable voice channels of 1 minute each. Main Features Four Channels Configurable as: Two Siren and Two Recordable Voice OR Four Recordable Voice Maximum record time is 8 minutes divided between the number of voice channels Siren Sounds: Classic Yelp Siren, Temporal Coded Horn, and Pulsing Industrial Horn Temporal Coded Horn meets ANSI standard for Audible Emergency Evacuation Signaling Recordings stored in non-volatile memory Voice channels accept momentary triggers “One Shot” or Continuous voice playback settings Option to trigger +V1 and or +S3 channels from a steady or pulsing input (ComboTrigger™) Built-in condenser microphone for recording Adjustable speaker volume and current draw
“Tested and working”
Model Elk-120
UPC 762158001208
Modified Item No
Type Sirens & Alarms
Country/Region of Manufacture India
MPN 120
Custom Bundle No
Brand Elk
