Emerson Servo Drive Epsilon Ep202-b00 En00

US $839.00

Batavia, Illinois, United States
Mar 8th

Open on mobile:
QR code

240 V in220 V out Power Requirements AC Input Voltage, 47-63 Hz EP 202/204/206: 1?, 20 to 264 VAC DC Input Voltage EP 202/204/206: 10-340 VDC AC Input Current (max. continuous) EP202: 5.0 Arms (140A for 2 ms inrush) Output Current Continuous (rms) / Peak (4 sec.) EP202: 2.2A / 4.4A Continuous Output Power EP202: 0.77 kW Switching Frequency 10 kHz External Logic Supply +18 to 30 VDC @ 0.5A Encoder Supply Output +5 VDC, 250 mA I/O Supply +10 to 30 VDC System Efficiency 93% Cooling Method Convection EP202 through EP209 Internal Fan EP216 Regeneration Internal Energy Absorption (115V / 230V) EP202: 39 Joules / 8 Joules External: Connection to external resistor, EP 202-209: 30 Ohm min, 12A peak, 2 kW avg. EP216: 20 Ohm min, 20A peak, 5 kW avg. Drive Control Inputs Analog: (1) +/-10 VDC, 14 bit, 100 kOhm, Differential Analog Max. Input Rating: Differential +/-14 VDC, Each Input with Reference to Analog Ground +/-14 VDC Digital: (16) (5 on EP-B) +10 to 30 VDC, 2.8 kOhm, Sourcing, Optically Isolated Pulse: (1) Differential RS-422, 1 MHz/Channel, 50% Duty Cycle Single Ended: (1) TTL Schmitt Trigger 500 kHz/ Channel, 50% Duty Cycle Motor Overtemperature: 0 to +5 VDC, 10 kOhm, single ended Drive Control Outputs Analog: (2) +/-10 VDC, 10 bit, Single-ended 20mA Digital: (8) (3 on EP-B) +10 to 30 VDC, 150 mA, Sourcing Optically Isolated Short Circuit Protected Pulse: Differential RS-422 and TTL compatible, 20 mA/Channel Sink or Source Environmental Rated Ambient Temperature: 32° to 104°F (0° to 40°C) for rated performance Maximum Ambient Temperature: 32° to 122°F (0° to 50°C) with power derating of 3.0%/1.8F (1°C) above 104°F (40°C) Rated Altitude: 3280’ (1000 m) Maximum Altitude: For altitudes >3280’ (1000 m) derate output by 1%/328’ (100 m ) Vibration: 10 to 2000 Hz @ 2g Humidity: 10 to 95% non-condensing Storage Temperature: -13° to 167°F (-25° to 75°C) Ingress Protection: IP-20 Serial Interface 2 RS485 connectors for multi-drop applications Modbus RTU w/ 32-bit extension, 9600 to 19.2 kBaud Ethernet Interface (EP-P only) 1 RJ-45, Modbus TCP/IP or EtherNet/IP DeviceNet (EP-xDN models only) Power Consumption: 25 mA Baud Rates: 125, 250 and 500 kps Node Addresses: 00-63 Profibus-DP (EP-PPB model only) Baud: 1.5 to 12 Mb, Address Range: 00-126 DIMENSIONS AND WEIGHT DIM. A DIM. B WEIGHT (KG) EP202 / EP204 -B,-I,-IDN 53.3 11.4 1.63 Compliance and Standards UL/CUL certified CE certified RoSH Compliant C-Tick certification by the Australian Communications Authority (ACA Used, in great condition. FREE SHIPPING! AK, HI, PR: Free shipping for items via the USPS. BUT, buyer pays actual shipping cost for items sent via UPS or Fed Ex. International buyers pay actual shipping charge (via the US Post Office). Payment: Paypal If you are the buyer of this item, payment is expected within a 24 hour period after purchase. If you are not able to send payment within this time frame, please contact us to make other arrangements. Warranty: All items are warrantied against D.O.A. (it will work when it arrives). No warranty beyond that. I have made an honest and fair evaluation of this item, but I am only human. I do miss things occasionally, and if it is not as I have represented it, I certainly will do what I can to "make it right". Returns: I accept returns only for items under warranty - no returns for purchasing the incorrect item, customer order changes, etc.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Emerson
MPN	EP202-B00
Model	Epsilon
