Energy Panel Meter Factor Frequency Voltage Voltmeter 0-45000w 45-65hz

US $27.90

suzhou, China
Jul 4th

Open on mobile:
QR code

Product Description Energy Panel Meter Factor Frequency Voltage Voltmeter 0-45000W 45-65Hz Features: 100% brand new and high quality Made of high-quality materials, durable Digital LCD AC Panel Meter Voltage Ampere Frequency Energy Power 40-300V 0-100A The meter can measure AC voltage, AC current, active power, power factor, power frequency and electrical energy. HD LCD has Adopt two-way module Product parameters: Model: D85-2058 AC voltage: AC 40.0-300.0V / 200.0-450.0V (optional) Alternating current: AC 0-99.99A, the minimum resolution is 0.01A Power frequency: 45.0Hz-65.0Hz Power factor: 0.00-1.00PF Active power: 0-45000W, when the power is between 0 and 9999.9W, the display accuracy is 0.1W Electricity: 0-9 99999kwh. When the electric energy is between 0 and 999.99kwh, the display accuracy is 0.01kwh. Between 10000.0-9999.9kwh, the display accuracy is 0.1kwh, when it is between 10000.0 and 999999kwh, the cumulative display is 1kwh Speed: 2 times per second Size: 70 * 39 * 40mm / 2.76 * 1.54 * 1.57 inches Installation size: 68 * 38mm / 2.68 * 1.50 inches Automatic energy saving: energy will be saved when the power is off method: 1. According to the wiring diagram, connect the green wire of the secondary current transformer to the blue terminal of the meter And make the wire of the measuring circuit pass through the hole in the current transformer. 2. Supply power and start measuring and displaying results 3. Keep pressing the button for 5 seconds, the power is zero note: 1. Using the wrong connection method will damage the meter 2. The meter can only be used to measure 45-65Hz alternating current for input (green terminal) and Secondary current transformer (blue terminal), square wave, inverter output and sine wave correction Package Included: 1 * AC panel meter 1 *Manual Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Alternating current	AC 0-99.99A
MPN	Does Not Apply
Power frequency	45.0Hz-65.0Hz
Package Contents	1 * AC panel meter 1 *Manual
Speed	2 times per second
Model	D85-2058
