Eoslift Electric Powered Walkie Pallet Truck 2860lb. Capacity

US $1500

  • Montclair, California, United States
  • Jun 9th
Model name: W13 Drive unit: Electric2 Battery Maintenance Free Curtis Control Operator Type: Walkie Capacity: 2860lbs. Load centre distance: 39" Wheel base: 50" Service weight (with battery): 644lb. Tires type: Polyurethane Front tire size (single/tandem): 2.9*3.8"/3.1*2.3" Rear tire size (balance roller/steering wheel): 4.5*1.6"/9.9*2.6" Number of wheels front/rear: 2(4)/2+1 Lift height: 4.7" Height of tiller in drive position min./max.: 33.5"/62.3" Lowered fork height: 3.0"/3.3" Overall length: 55.9" Overall width: 27.7" Fork dimensions: 45.2/48"*6.3*1.7" Width across forks: 21.3*27" Min. aisle width 1000x1200: 81.0" Min. aisle width 800x1200: 79.4" Turning radius: 54.5" Travel speed, loaded/unloaded: 2.6/2.9 m/h Lift speed, loaded/unloaded: 0.18/0.2 fps Lowering speed. loaded/unloaded: 0.19/0.19 fps Gradeability, loaded/unloaded: 5/7% Service brake: Electromagnetic Drive motor rating s260 min.: DC 0.6 kw Lift motor rating at s315%" DC 0.8 kw Battery acc. to din 43531/35/36, a, b, c no: Maintenance-free Battery voltage, nominal capacity: 24/70 V/Ah Battery weight: 110lb. 76.6 hours used SHIPPING (applies for listings that do not offer free shipping): Contact us for a shipping estimate. Shipping cost will be added to your invoice. Shipping cost is based on the freight company, weight of the product, size of the product, and the shipping location (distance from shipping point, and whether it is residential or commercial). The cheapest shipping cost will be chosen.
