Eoslift Electric Stacker 3520lb. Capacity

US $2871

  • Montclair, California, United States
  • Jun 7th
Model: T1645W Drive Unit: ElectricCurtis Control Industrial Battery Operator Type: Walkie/Stand On Capacity: 3520lb. Load Centre Distance: 23.6" Wheel base: 54.7" Service Weight (with battery): 3278lb. Tires Type: Polyurethane Front Tire Size: 3.1x2.8" Rear Tire Size: 4.5x2.2" Number of wheels front/rear: 4/2+1 Lowered mast height: 82.0" Free lift: 64.2" Lift height: 177.0" Extended mast height: 194.0" Height of tiller in drive position min./max.: 39.4" Lowered height (fork): 2.2" Overall length (platform fold/unfold): 79.1" Overall width: 57.9" Width over forks: 7.8-31.5" Ground clearance, centre of wheel base: 1.2" Min. Aisle width 1000x1200 (platform fold): 96.8" Min. Aisle width 800x1200 (platform fold): 95.7" Turning radius (platform unfold): 77.9" Travel speed, loaded/unloaded: 3.1 m/h Lift speed, loaded/unloaded: 0.43/0.75 Lowering speed, loaded/unloaded: 0.43 fps Max. gradient performance, loaded/unloaded 5/7% Service brake: Electro Magnetic Drive motor rating s260: AC 1.5 kw Lift motor rating at s315%: DC 3 kw Battery voltage, nominal capacity: 24/280 V/Ah Type of drive control: Impulse SHIPPING (applies for listings that do not offer free shipping): Contact us for a shipping estimate. Shipping cost will be added to your invoice. Shipping cost is based on the freight company, weight of the product, size of the product, and the shipping location (distance from shipping point, and whether it is residential or commercial). The cheapest shipping cost will be chosen.
