Epicweld Gta5200d Plasma Cutter / 200a Tig / Stick Welder 7d Support

US $399.99

Wentworth, New Hampshire, United States
Jul 17th

Open on mobile:
QR code

Product description Features: GTA5200D is the perfect choice for projects and repairs around the home and auto body shop. Combo 3-in-1 multi function Plasma Cutter / TIG Torch / Stick Arc professional welding machine. Advanced IGBT technology, synergistic controlled, very easy and simple operation. Featured wave-form control system: perfect wave form of volts and amps during, short circuits and Arc burning cycles. Automatic compensation for voltage fluctuation, over-voltage protection, under voltage protection, over current protection, over load protection. Automatic temperature control, fan dormancy, steeples amperage control, all generators friendly. This is optimized to deliver a flawless weld, making spatter and post-weld cleanup almost non-existent. All machines tested in the at the factory and come with a three-year warranty. Specifications: Type: Plasma Cutter, TIG-Torch, Stick/Arc 3-in-1 Combo Welding Supply Power: 115V/230V/60Hz/1-Phase Welding current Range: Plasma Cutter: 230V / 5-50A & 115V / 5-35A TIG Torch: 230V / 20-200A &115V / 20-140A STICK ARC: 230V / 20-200A & 115V / 20-140A Welding output,104F(40C): Plasma Cutter: 50A / 100V TIG Torch: 200A / 18V STICK ARC: 200A / 28V Rated Input Current: Plasma Cutter: 27.1A / 230V & 35.7A / 115V TIG Torch: 19.6A / 230V & 23.7A / 115V STICK ARC: 30.4A / 230V & 39A / 115V Duty Cycle: Plasma Cutter: 60% at 50A & 100% at 32A TIG Torch: 60% at 200A & 100% at 126A STICK ARC: 60% at 200A & 100% at 126A Nominal DC Open Circuit Voltage: 73V Efficiency: 85% Power factor: 0.93 Output Terminal Type: Direct Wire Cooling Method: Fan Air Cooled Gas Supply: Clean Dry Oil-Free Air Gas Pressure Range: 45 psi – 75 psi Recommended Gas Inlet Flow (Rate/Pressure): 3.6 scfm @ 70 psi Maximum Severance Cutting Thickness: 1.0 inch Movement Speed: 12.5 inch Net Weight: 40 lbs. Product Size: 19.5 x 9.0 x 14 in. Package Weight: 50 lbs. Shipping Size: 22.6 x 12.2 x 16.63 in. Package Includes: GTA5200D Cutter/TIG/Stick/Arc 3-in-1 Welding Machine 15 Feet (PT-31) Plasma Torch Assembly 15 Feet (WP-17) TIG Torch Assembly 10. Feet 500A Electrode Holder Assembly, 35-50mm Lead Dines 10 Feet 500A Work Clamp, 35-50mm Lead Dines 3 Feet Argon Gas Hose Owner’s Manual EpicWeld GTA5200D is a new digitally controlled 50 amps Plasma Cutter, 200 amps TIG torch and 200 amps Stick Arc 3-in-1 Combo Welding Machine. Designed for portable repair work and small business project use, it is ideal for a welding enthusiast or hobbyist with basic repair needs and general light welding requirements. 10-50A Plasma Cutter ideally cuts a thickness of 3/4 in.; the max severance thickness 1.0 in. 10-200A TIG Torch compact welder has everything you could ask for in the way of features for welding which includes. If you want to weld Steel, Chrome Moly, Stainless, Titanium, or any other metal can be welded with DC output. 10-200A DC Stick/Arc electric current output, easy Arc start, stable welding Arc, deep weld pool, and beautiful welding shape are suitable for welding with different kinds of acid or basic electrode.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Input Amperage	27/40 amps
Item Type	Plasma Cutter & Tig Welder
Brand	EpicWeld
MPN	GTA5200D
UPC	791259581302
