Netwelder Esab 161LTS MiniArc Stick/DC TIG Welder - 0558101699 MiniArc 161LTS, Tig Package ..0558101699 Includes power source with 10 ft. power cord, 115V/230 input power adapter cable, 10 ft. heavy duty ground cable and clamp, 10 ft, heavy duty electrode holder and cable and sample pack of ESAB electrodes, HW-17F torch, R33 reg/flowmeter and TIG accessory kit. ?Specifications Product Data Page Input Voltage: 115/230 VAC, 1 ph., 60 Hz Voltage Tolerance: +/- 15% 115V Operating Data Output Range (Stick) 5 A/110 A Stick Duty Cycle / Rated Output: 110 A/24.4 V@35% 60 A/22.4 V@100% Output Range (Lift Tig) 5 A/110 A Lift TIG Duty Cycle / Rated Output 110 A/14.4 V@35% 60 A/12.4 V@100% Primary Current 100% Duty Cycle 19 A Stick/10.5 A Tig 35% Duty Cycle 32.5 A Stick/22.5 A Tig Open Circuit Voltage (max) 80 V Stick/15 V Tig 230V Operating Data Output Range (Stick) 5 A/110 A Stick Duty Cycle / Rated Output 160 A/26.4 V@35% 88 A/23.5 V@100% Output Range (Lift Tig) 5 A/160 A Lift TIG Duty Cycle /Rated Output 160 A/16.4 V@35% 88 A/16.4 V@100% Primary Current 100% Duty Cycle 14.5 A Stick/8.4 A Tig 35% Duty Cycle 28.5 A Stick/18.5 A Tig Open Circuit Voltage (max) 80 V Stick/ 15 V Tig Efficiency 80% Power Factor .73 Net Weight 18 lbs. (8 kg) Dimensions W x L x H 5.75 x 15.75 x 10 in. Fixed hot start - allows the operator to easily strike an arc without the electrode sticking to the plate Fixed arc force - allows the operator to get deeper penetration into the plate without the electrode sticking to the plate Lift arc tig gives you the luxury of lifting the tungsten as opposed to traditional scratch starting which can deposit tungsten into the plate resulting in contamination Able to use cellulosic 6010 electrodes with ease 18 Pound weight - Makes this unit portable and easy to carry directly to the job Comes with a rugged carrying case and a shoulder strap Includes 10 ft. work cable with clamp, 10 ft. welding cable with electrode holder Thermal indicator prevents the machine from becoming damaged if airflow is blocked or from exceeding the duty cycle Simple interface - amperage knob, stick/TIG switch and on/off switch on front panel of unit Small and portable, inverter based 5 to 160 Amps current range for DC Welding The MiniArc 161 Automatic Primary Select operates on either 115 or 230 VAC and will automatically configure to the primary input supplied We expect payment within 3 days. We suggest Priority Mail for lighter weight items under 4lbs and UPS for heavier items when shipping in the Unites States. WE USUALLY SHIP THE NEXT BUSINESS DAY AFTER PAYMENT RECEIVED, SAME DAY IN SOME CASES. UPS SENDS TRACKING INFORMATION TO YOUR E-MAIL ADDRESS USED FOR SALE. TRUCK TRACKING INFO SENT IN SEPARATE E-MAIL. All items are covered by Manufacturer warranties. We will help you with any warranty issues. Small items shipped by UPS ground or USPS Priority Mail, unless you choose 1st or 2nd day air at additional charge. Larger welders are shipped via common carrier of our choice. We get it to your door. Additional charges for lift gates or special delivery are at your cost. We strive to always have stock available for shipping, but from time to time stock-outs may occur. Some welders are not stock items and will be ordered from manufacturer when paid for. It usually takes only a few days to ship to you. Some are shipped direct from manufacturer. PLEASE CALL BEFORE RETURNING ANY ITEM. EXCHANGES AND RETURNS SUBJECT TO 20% RE-STOCK PLUS OUTBOUND SHIPPING CHARGES AND RETURN SHIPPING CHARGES. ALL PRODUCTS COVERED BY MFG. WARRANTIES. INTERNATIONAL BUYERS: ONLY ITEMS MARKED FOR SALE FOR INTERNATIONAL SALES WILL BE SOLD INTERNATIONALLY. WARRANTIES MAY NOT BE HONORED IN ALL COUNTRIES. BUYER SOLELY RESPONSIBLE FOR ALL IMPORT FEES AND DUTIES. ALL PAYMENTS IN US DOLLARS, ON CREDIT CARD OR INSTITUTION DOING BUSINESS IN USA. PAYPAL USERS SUBJECT TO EXCHANGE FEE. Paypal is preferred payment method. BUYER SOLELY RESPONSIBLE FOR ALL IMPORT FEES AND DUTIES. ALL PAYMENTS IN US DOLLARS, ON CREDIT CARD OR INSTITUTION DOING BUSINESS IN USA. PAYPAL USERS SUBJECT TO EXCHANGE FEE. Credit Card: Call 800-284-6992, 8:00AM-4:00PM EST M-F to use all major credit cards. ALL PAYMENTS IN US DOLLARS, ON CREDIT CARD OR INSTITUTION DOING BUSINESS IN USA. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
