Esab 7018 5/32" Atom Arc 50lb Can Dented.part#255015315

US $149.99

Tampa, Florida, United States
Jul 30th

Open on mobile:
QR code

Esab 7018 5/32" Atom Arc 50lb can Dented.Part#255015315. Atom Arc 7018 is an all-position low hydrogen moisture resistant electrode with a deep, penetrating arc. This premium quality electrode meets a multitude of codes and welding specifications. Atom Arc 7018 was developed to weld carbon and low-alloy steels, including a variety of hardenable steels. Typical Charpy V-Notch Properties Stress Relieved Impact Value 193 ft-lb Impact Value 260 J 1150 °F 621 °C 8 hr Testing Temperature -20 °F Testing Temperature -29 °C Typical Tensile Properties Condition As Welded Stress Relieved Reduction in Area 75 % 77 % Tensile Strength 540 MPa (78 ksi) 485 MPa (70 ksi) Yield Strength 470 MPa (68 ksi) 395 MPa (57 ksi) Elongation 30 % 33 % Testing Time 8 hr Testing Temperature 621 degC (1150 degF) Deposition Data Current Deposition Rate Diameter Deposition Efficiency (%) Optimal Amps 130-220 A 1.7 kg/h (3.8 lb/h) 4.0 mm (5/32 in.) 73.5 % 170 A 90-160 A 1.2 kg/h (2.6 lb/h) 3.2 mm (1/8 in.) 71.6 % 120 A 200-300 A 2.4 kg/h (5.4 lb/h) 4.8 mm (3/16 in.) 74.6 % 250 A 200-300 A 2.2 kg/h (4.9 lb/h) 4.8 mm (3/16 in.) 76.4 % 200 A 70-100 A 0.8 kg/h (1.7 lb/h) 2.4 mm (3/32 in.) 66.3 % 90 A 90-160 A 1.2 kg/h (2.7 lb/h) 3.2 mm (1/8 in.) 70.9 % 140 A 250-350 A 3.3 kg/h (7.2 lb/h) 5.6 mm (7/32 in.) 74 % 300 A 250-350 A 2.9 kg/h (6.5 lb/h) 5.6 mm (7/32 in.) 75 % 250 A 300-400 A 3.5 kg/h (7.7 lb/h) 6.4 mm (1/4 in.) 78 % 300 A 300-400 A 3.9 kg/h (8.7 lb/h) 6.4 mm (1/4 in.) 77 % 350 A 130-220 A 1.4 kg/h (3.1 lb/h) 4.0 mm (5/32 in.) 75 % 140 A Classifications Classifications ASME SFA 5.1 : AWS A5.1 : E7018 H4R Approvals Approvals ABS 3Y/AWS A5.1: E7018 CWB CSA W48 E4918 DNV 3Y(H10) LR 3m,3Ym(H10) MIL-E-22200/1 MIL-7018 Approvals are based on factory location. Please contact ESAB for more information. Consumable Characteristics Coating Type Low-hydrogen iron powder 0 Welding Current AC or DC+ Typical Weld Metal Analysis % Typical Weld Metal Analysis % C Mn P S Si 0.045 % 1.10 % 0.015 % 0.014 % 0.40 % 0.05 % 0.40 %

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Modified Item	No
Country/Region of Manufacture	United States
MPN	255015315
Diameter	5/32 in
Electrode Type	Steel
Custom Bundle	No
Brand	ESAB
UPC	662303016371
