ESAB Rebel Multi-Process Welder MIG/Stick/TIG EMP 215ic 0558102240 READY-TO-WELD. Tweco Fusion 180 MIG gun with 10-ft. (3-m) cable Spare MIG gun parts kit, including contact tips and drive rolls Tweco 200A electrode holder with 13-ft. (4-m) cable Four general purpose 6013 Stick electrodes ESAB 70S-6 .030 4-in., 2-lb. sample spool Tweco TIG torch and accessories Tweco ground clamp with leads Victor argon flowgauge regulator with 12.5-ft. (3.8-m) gas hose 120V and 230V adapter plugs Does NOT include spool gun or foot control. TECHNICAL DATA Current Range 5-150A (120V), 5-240A (230V) MIG (GMAW) Welding Output 130A/20.5V (120V) @ 20% Duty Cycle 205A/24.3V (230V) @ 25% Duty Cycle Stick (SMAW) Welding Output 90A/23.6V (120V) @ 40% Duty Cycle 180A/27.2V (230V) @ 25% Duty Cycle TIG (GTAW) Welding Output 130A/15.2V (120V) @ 40% Duty Cycle 180A/17.2V (230V) @ 30% Duty Cycle Max Plate Thickness 3/8 in. (12.7 mm) Protection Class IP23S Approvals CSA E60974-1-00, IEC 60974-1 Generator Size Recommendation 3.7 kVA (110V); 7.5 kVA (230V) Weight 40 lbs. (18.2 kg) Dimensions H 16 in. x W 9 in. x D 23 in. (H 406 mm x W 229 mm x D 584 mm) Warranty 3 years – handle to handle; 1 year – torch; 100% satisfaction guarantee You don't know the meaning of a typical day -- What it's like to work 9 to 5 at a desk. You don't know where you'll wind up on your next job, bu you do know that you'll have to be ready for anything. And when it comes to welding, that means any process, any power, any material, anywhere, and every time. Meet REBEL! The go-anywhere, weld-anything machine that has everything you need to get the job done - start to finish. It's anything but typical. HIGH PERFORMANCE Many machines claim they’re multi-process, but are little more than a MIG machine in disguise. Rebel is a true multi-process welder, which means whether you’re welding MIG, Flux-Cored, Stick – even those tricky 6010 rods – or TIG, Rebel will perform like it was born to run that process. CRAZY SMART TECHNOLOGY Whether you’ve been welding for two years or 20, Rebel can make your job easier with sMIG (smartMIG). For rookies, there’s basic mode, which makes setup simple. And for veterans, the exclusive, built-in arc control that constantly monitors your weld and adapts for superior, repeatable welds will truly blow your mind. VERSATILITY You never know what welding process your next job will require, or what kind of input power you’ll have available. That’s why we’ve packed Rebel with the kinds of features that give you the flexibility to go anywhere and weld anything. UNMATCHED TOUGHNESS You’re on-site, out in the field, and in the shop. So you need a machine that you can move around and that can withstand some serious wear and tear. Rebel can. With a sturdy, five-handle roll cage, steel unibody construction, and IP23S-level protection, it’s the go-anywhere machine for a reason. THE TOTAL PACKAGE It takes more than a machine to get up and welding. So when you buy a Rebel, you can expect all the equipment you need to get going – right out of the box – and from some of the best names in the industry. THE MOST INCREDIBLE MACHINE ON-SITE. TRUE MULTI-PROCESS. Professional-grade MIG performance, including flux-cored Excellent Stick performance, including 6010/6011 cellulosic and 308L electrodes Exceptional lift TIG performance down to 5A Compatible with spool gun for welding aluminum DUAL VOLTAGE. Runs on 120V–230V single-phase input power (adapter included) Top-level performance across all processes – even on 120V power Auto-detect knows what type of input power the machine’s connected to Runs off a 3.7 kVA (120V) or 7.5 kVA (230V) generator LARGE, 4.3-INCH COLOR SCREEN. Intuitive LCD/TFT display Well protected by front handles and a hefty composite bezel Easily switch from one process to the next Built-in on-screen manual, spare parts listing, and welding parameters guide Multi-lingual capabilities, including English, French, and Spanish RUGGED CASE DESIGN. Five-handle roll cage for easy transport and handling Steel unibody housing for increased protection and superior durability Recessed body panels for increased strength NEVER-BEFORE-SEEN sMIG TECHNOLOGY. Exclusive, built-in dynamic arc control that constantly monitors complex arc characteristics adapting to your technique to provide a smooth, stable arc and superior, repeatable welds. Produces less spatter and weld defects Two modes – basic and advanced Basic mode reduces the MIG learning curve – set wire diameter and material thickness and you’re ready to weld Advanced mode gives full control to adjust the arc characteristics to your liking SOLID CAST ALUMINUM FEEDER. The design of this cast feeder mechanism increases durability, decreases wire shavings and bird nesting, provides for easy drive roll changes (no tools required), and delivers consistent feeding performance. All in all it has optimized alignment and long-life drive stand components that ensure accurate, smooth wire feeding LIGHTWEIGHT. A 40-pound design makes it easy to carry from jobsite to jobsite. MULTI-MATERIAL. Weld steel, stainless, and even aluminum with the optional spool gun. WELD PARAMETER STORAGE. Save up to four welding parameters per process; ideal for switching between jobs. TRIGGER HOLD FUNCTION 2T/4T. Reduces operator fatigue when MIG or TIG welding. INFINITE VOLTAGE CONTROL. Fine-tune the arc characteristic by adjusting the voltage setting. ADJUSTABLE INDUCTANCE. Perfect for fine-tuning arc stability and controlling spatter. ADJUSTABLE BURN-BACK CONTROL. Prevents wire from sticking in the weld pool or burning back, damaging the contact tip. ADJUSTABLE ARC FORCE CONTROL. Optimizes Stick electrode performance and allows the operator to increase the arc voltage for a short period of time to avoid arc outs and “sticking” when the arc is too short. ADJUSTABLE HOT START CONTROL. Increases the initial welding current to avoid the electrode sticking to the workpiece; particularly useful for difficult-to-start electrodes. LIFT TIG ARC STARTS. Provides TIG arc starts without the use of high frequency. Ideal for the shop or site application where sensitive electronic devices operate. GAS PRE- AND POST-FLOW TIME ADJUSTMENT. Purges gas line and prevents porosity at the start and end of welding; especially useful when MIG welding aluminum. IP23S. The enclosure is built to protect you and your machine. Designed to a higher standard, Rebel can withstand harsh outdoor environments. WARRANTY. Rebel comes backed with a rock-solid, three-year, handle-to-handle warranty and 100-day, 100 percent satisfaction guarantee. We expect payment within 3 days. We suggest Priority Mail for lighter weight items under 4lbs and UPS for heavier items when shipping in the Unites States. WE USUALLY SHIP THE NEXT BUSINESS DAY AFTER PAYMENT RECEIVED, SAME DAY IN SOME CASES. UPS SENDS TRACKING INFORMATION TO YOUR E-MAIL ADDRESS USED FOR SALE. TRUCK TRACKING INFO SENT IN SEPARATE E-MAIL. All items are covered by Manufacturer warranties. We will help you with any warranty issues. Small items shipped by UPS ground or USPS Priority Mail, unless you choose 1st or 2nd day air at additional charge. Larger welders are shipped via common carrier of our choice. We get it to your door. Additional charges for lift gates or special delivery are at your cost. We strive to always have stock available for shipping, but from time to time stock-outs may occur. Some welders are not stock items and will be ordered from manufacturer when paid for. It usually takes only a few days to ship to you. Some are shipped direct from manufacturer. PLEASE CALL BEFORE RETURNING ANY ITEM. EXCHANGES AND RETURNS SUBJECT TO 20% RE-STOCK PLUS OUTBOUND SHIPPING CHARGES AND RETURN SHIPPING CHARGES. ALL PRODUCTS COVERED BY MFG. WARRANTIES. INTERNATIONAL BUYERS: ONLY ITEMS MARKED FOR SALE FOR INTERNATIONAL SALES WILL BE SOLD INTERNATIONALLY. WARRANTIES MAY NOT BE HONORED IN ALL COUNTRIES. BUYER SOLELY RESPONSIBLE FOR ALL IMPORT FEES AND DUTIES. ALL PAYMENTS IN US DOLLARS, ON CREDIT CARD OR INSTITUTION DOING BUSINESS IN USA. PAYPAL USERS SUBJECT TO EXCHANGE FEE. Paypal is preferred payment method. BUYER SOLELY RESPONSIBLE FOR ALL IMPORT FEES AND DUTIES. ALL PAYMENTS IN US DOLLARS, ON CREDIT CARD OR INSTITUTION DOING BUSINESS IN USA. PAYPAL USERS SUBJECT TO EXCHANGE FEE. Credit Card: Call 800-284-6992, 8:00AM-4:00PM EST M-F to use all major credit cards. ALL PAYMENTS IN US DOLLARS, ON CREDIT CARD OR INSTITUTION DOING BUSINESS IN USA.
