US $90.36
Condition: |
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is
applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details.
...
|
Country/Region of Manufacture | China |
MPN | XJX1261-73 | ||
Analog bandwidth | 120MHz | ||
Display | 320x240 LCD screen | ||
Display area | 50mm x 40mm/1.96x1.57'' | ||
Storage | 2500 DSO waveforms | ||
Vertical resolution | 8 bits | ||
Vertical accuracy | ±(5%+ 0.2div) | ||
Backlight | White, brightness adjustable | ||
Impedance | x1: 1M / x10: 10M | ||
Battery | 18650 lithium battery | ||
Auto shutdown | No operation for 15 minutes | ||
Size | 124 x 80 x 35mm/4.88x3.14x1.37'' | ||
Use conditions | 0C~ +40; < 75%RH | ||
Storage conditions | -10C~ +60; < 90%RH | ||
Auto zero reference | During DC measurement | ||
Trigger level | ±3.8div (0. 1div per step) | ||
Trigger position | ± 6div (0. 1div per step) | ||
Cursor function | V, t, 1 /t | ||
Measurement Accuracy | ±(5%+ 0.2div) | ||
Non. linearity | ±1 bits | ||
Coupling method | DC/AC | ||
Division: Vertical | ±3.8 Horizontal:12 | ||
Time base range | 6ns/div ~ 50s/div | ||
Time base accuracy | ±(0.01%+0.1div) | ||
Scan mode | Auto/Single/Normal | ||
Trigger slope | Rising / Falling | ||
Record length | 12div | ||
Maximum Real-Time Sampling Rate | 500MS/s | ||
Auto configuration | Automatically set time base and vertical amplitude | ||
Brand | Unbranded | ||
UPC | 6933834694746 |
