Etcr2100a+ Lcd Digital Clamp On Ground Earth Loop Resistance Meter 0.01~200ohm

US $319.18

Shenzhen, China
Jul 23rd

Open on mobile:
QR code

ETCR2100A+ LCD Digital Clamp On Ground Earth Loop Resistance Meter 0.01~200ohm Description Features: 1. Safer and faster. When measuring ground system with loop, there is no need to disconnect the ground wire without auxiliary electrode. 2. Clamp Earth Resistance Test tool can measure the ground fault which can not be measured by traditional method, can apply in the occasion where traditional methods are unworkable 3. Clamp Earth Resistance Test tool measures the integrated value of ground resistance and resistance lead. 4. For ground resistance measurement, loop resistance measurement in fields such as electric power, telecommunications, meteorology, oil field, architecture and industrial electrical equipment, etc. Specification: Power Supply: 4x 6VDC batteries(Not Included) Resistance Range: 0.01-200 Resistance Resolution: 0.001 Highest Resistance Accuracy: ±1%±0.01 Data memory: 99 Sets Alarm Threshold Setting Range: Resistance: 1-199; Current: 1-499mA Working Temperature and Humidity: -20-55 degree Celsius20-90RH LCD Screen: 4 Digits LCD display Clamp Size: 65mm32mm Clamp Opening Extent: 32mm Size: 260x90x66mm Structural Feature: Clamp CT Protection Level: 2 Insulation Shifting Automatic shifting External magnetic field: 40A/m External electrical field: 1V/m Single measurement tim: 0.5 sec Resistance measurement frequency: 1KHz Measured current frequency: 50/60Hz Low Battery Indication: Low battery displays when battery is lower than 5.3V Memory Full Indication: MEM blinks when all 99 sets memory is full Over Range Indication: Out of range indication “OL”, “L0.01” or “OL A” Auto Power-off: 5 minutes after Boot up Power Consumption: Max 50mA either in booting up or normally working, Continuously working for 30 hours 0.010-0.099 Resolution: 0.001 Accuracy: ±(1%0.01) 0.10-0.99 Resolution: 0.01 Accuracy: ±(1%0.01) 1.0-49.9 Resolution: 0.1 Accuracy: ±(1%0.1) 50.0-99.5 Resolution: 0.5 Accuracy: ±(1.5%0.5) 100-199 Resolution: 1 Accuracy: ±(2%1) 200-395 Resolution: 5 Accuracy: ±(5%5) 400-590 Resolution: 10 Accuracy: ±(10%10) 600-880 Resolution: 20 Accuracy: ±(20%20) 900-1200 Resolution: 30 Accuracy: ±(25%30) Package Included: 1*Resistance Meter 1*manual 1*test loop 1*storage box On Jul-23-21 at 11:28:10 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
MPN	Does Not Apply
Type	Air Flow/Anemometer
Power Supply	4x 6VDC batteries(Not Included)
Resistance Range	0.01-200
Resistance Resolution	0.001
Highest Resistance Accuracy:	±1%±0.01
Data memory	99 Sets
LCD Screen	4 Digits LCD display
Structural Feature	Clamp CT
Protection Level	2 Insulation
Single measurement tim	0.5 sec
Resistance measurement frequency	1KHz
Measured current frequency	50/60Hz
Low Battery Indication	Low battery displays when battery is lower than 5.3V
Auto Power-off	5 minutes after Boot up
Clamp Size	65mm32mm
Clamp Opening Extent	32mm
Size	260x90x66mm
UPC	6973691954140
