Eth-sc09 Ethernet Communication Adapter Remote Module Mitsubishi Fx Series Plc

US $125.00

shenzhen GD China, China
Jun 9th

Open on mobile:
QR code

1. Support for Windows 95/98 / ME / NT / 2000 / XP / 2003 / XP / Win7 / Win8 operating system 2. FX series PLC via the programming port directly connected to the Ethernet, Internet Internet or 3G wireless network. Without modifying the original serial communication protocols and software, 3. Support DNS name resolution, users can maintain PLC remote control via the Internet. ? completely replace wired USB-SC09 programming cable or USB-SC11, and remote upload and download, monitor, enforce, modify all operating procedures. ? can be directly connected to the computer via a network cable or via a wireless router (sold separately or supplied) LAN consists of wireless connected machine. ? Power supply: from the FX series PLC programming port RS422 socket 5V ± 10% DC power supply, the power consumption of approximately 1 watt (no external power supply) product description: ETH-SC09 is the use of Ethernet and Internet Internet or 3G wireless network of industrial grade products Mitsubishi FX series PLC networking communication. It integrates many complex network protocols, support TCP Server, TCP Client, UDP Unicast, UDP and multicast variety of operating modes, It has 10M / 100M adaptive Ethernet port and meet the technical specifications of Mitsubishi RS422 interface allows the user to simply set up after the FX series PLC easily connected to the Ethernet or Internet internet. ETH-SC09 is an industrial product, its Ethernet port and RS422 interfaces implemented a quarantine to accommodate the harsh environment of industrial site. And each signal pins with anti-static protection and surge protection, effective protection of the PLC communication port from outside surges and common mode interference. The need to draw the user's attention, when ETH-SC09 for communication between PC and FX series PLC communication, or PLC and PLC, Support compliance with RS422 / RS485 / RS232-based communication UART serial data communication standards. Some fieldbus such as PROFIBUS, PPI, MPI, CC-Link, PC-Link, etc., although its physical interface is RS485, but they do not comply with UART serial data format, so do not apply this product! ? High-speed, highly reliable industry standard, anti-jamming design suitable for harsh electromagnetic environment applications ? 32 ? RISC (NP7 series) ARM7TDMI 55DMIPS ? 128KB SRAM, 128KB Code + 32KB Boot ? 10 / 100M adaptive Ethernet interface ? Support RS422 / RS485 interface the data bits can be set to 5,6,7,8 ? Support RS422 / RS485 interface stop bit 1,2 bit can be set ? Support RS422 / RS485 interface parity bit NONE, ODD, EVEN, MARK, SPACE can be set ? Support RS422 / RS485 interface, baud rate 110 ~ 460800bps standard baud file can be set, but does not support dynamic variable baud rate. ? Support RS422 / RS485 communications conform to the standard UART asynchronous serial interface does not support fieldbus protocol RS422 / RS485 ? intelligent protocol suite: TCP, UDP, ARP, IP, ICMP, DHCP, BOOTP, DNS ? can be customized to support the DNS dynamic domain name resolution function (requires RE version support) ? Working mode can be selected as TCP Server, TCP Client, UDP multicast and UDP unicast ? Built-in Flash memory, long-term preservation configured parameters ? Ethernet port 1500VDC electromagnetic isolated, RS422 port 1500VDC electromagnetic isolated ? Interface protection: power supply port has reverse polarity protection and overcurrent protection; RS422 ports have surge protection; anti-static protection on all pins and terminals ? Dimensions: 35mm standard rail mounting Delivery Time: 1. Delivery USA ship by e-packet(ebay international shipping service tool), Delivery 7-16days to USA. you can tracking it on www.ems.com.cn or www.usps.com 2, Delivery worldwide ship by HongKong regular post without tracking No.. Delivery time as below : Delivery 20-35days to Most Asia countries. Delivery 25-40days to Canada,Australia Delivery 30-45days to,France,UK Africa countries, and European countries. Delivery 45-60days to Italy, Spain ,Russian Federation,Argentina,Brazil, and others South America countries. 3, If you do not accept our delivery time, Pls drop to buy !!! 4, If HongKong regular post is slow for you ; Suggest ship via HK DHL or EMS express , freight is additional. 5, If add USD3 again, We will ship by China Post Registered Mail, And with tracking No. Dispute & Feedback: 1, Pls contact us at first if parcel do not delivery in time. 2,If you don’t receive the items within 42days, Please do not send Paypal dispute or eBay case, pls contact us via eBay messages firstly,we can refund to you,when you get the parcel,pls resend the payment to us. 3,No matter what unpleasant things happen, pls don’t give us negative feedback, please remember to contact us firstly, and believe that we can make you satisfied. 4,Regarding the shipping time of DSR, Please do not give low scores below 3 star,please remember to contact us firstly, and believe that we can make you satisfied. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	fliegend
Driver languages:	Chinese
MPN	mpn
Country/Region of Manufacture	China
Set of item :	1piece
