Ethernet Cnc Controller W/3 Nema23 620 Oz/in Steppers Mill/lathe

US $1,495.00

Simi Valley, California, United States
Mar 12th

Open on mobile:
QR code

This system has an Ethernet interface which provides 3 Parallel ports on the controller face. - Parallel Port 1 is dedicated to the motor drivers. - Parallel Ports 2 and 3 are for user interface such as pendants, encoders or other TTL I/O. Use it to set up a mill or lathe. Ask us about adding the Bobcad. (We are an authorized BobCAD reseller.) Included: 404E Series Ethernet 4 Channel Controller and power cord. Included: 3ea Pre-wired 620 oz/in motors w/ 8' cables and home switches. Included: 10' Ethernet Cable. Included : 12" Parallel Cable Included: 404E Series Instruction Manual. Motors can be combined with 300 oz/in or add a 4th motor, ask us how! Included: Mach 3 Software on CD. We are an authorized Mach3 dealer. Included: Mach3 license. This auction is for a Model Shop CNC, Inc 404 Series 4 channel Ethernet Contoller with 3ea pre-wired Single or Dual Shaft Nema23 620 oz/in stepper motors. As Easy as 1,2,3. 1. Mount the Motors. 2. Install the Software and cables. 3. Run your program. This system is ready to run. You provide the machine and the motor couplings and we provide the controller, motors, cables and software. Specifications: Controller Supply Voltage 120VAC Motor Voltage 48VDC Controller Power 400Watts Controller Channels 4 Box Size 8.5” x 10” x 4” Box Type Powder coated Steel Controller Interface Ethernet Motor Outputs 3.5A Maximum per port Motor Connectors DB9 Controller Fuse 8A I/O Ports (3) 6pin Input RJ45 (Ethernet Port) Motors Motor Current 3.5A Max Speed/Max Torque Motor Wires 4 Motor Length 2.6" Shaft Diameter .375 with flat Motor Outputs 3.5A Maximum per port Motor Connector DB9 (Male) Controller includes: - (4) Motor Driver Channels - (2) I/O Ports with 2 inputs and 1 output each and 5V Supply (1A Max all ports) - (1) VFD Port with 10VDC Output. - Parallel Port Interface - Mechanical Latching Emergency Stop Switch. - Built in cooling fan System can be used for precision inspection, automated sonic welding, custom XY positioning, milling, lathing, manual drilling and much more. Motor features: 620 oz/in motor with a nema 23 mounting flange. Extremely high power to weight ratio Superior linearity (better microstep accuracy) Low audible noise Less torque drop at upper speeds 4 wire configuration Our step motors feature an improved stator design wherein geometries are altered for greater torque output than other 2-phase step motors of comparable length. The exceptional static torque profile makes it possible to use shorter motors than before in a given application. Since shorter motors inherently produce better speed vs. torque characteristics due to lower resistance and inductance, the net result is an ability to push same loads at higher speeds or higher loads at same speeds. This makes these steppers good candidates for some applications currently beholden to servos. The new stator design also features improved linearity, the characterisitic most influential on microstepping accuracy. The better the motor's linearity, the lesser tendency there is for micorsteps to stretch and compress. The RS motors rightly deserve the classification, "Microstep Optimized". Additionally, the motors are surprisingly quiet in comparison to other stepper motors. The system includes our standard 1 year warranty. Typical handling lead time is 5 days.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Make	Model Shop CNC, Inc.
Model Year	2015
Model	404E Series
Control Type	Stepper
Type	CNC Controller
