Ethernet / Internet 16 Channel Relay Board: Ip, Snmp, Ios / Android Software

US $43

Europe, Bulgaria
Jun 9th

Open on mobile:
QR code

Denkovi Assembly Electronics ltd. Ethernet / Internet 16 Channel Relay Board: IP, SNMP, Windows / Android Software General description This is kit of IP controler and card with 16 SPDT relays. It is for home automation, hobby and commercial projects. It allows you controlling electrical devices via LAN/WAN (Internet). Just connect the device into your local network and control it from another computer or android smartphone over the LAN or Internet. This IP relay board can be controlled from: Configuration utility - DAEnetIP2 Manager, web browser, command line, android smartphone application or Denkovi Relay Manager Software. We can provide also software examples for developers. Now with free iOS mobile App! Features: 10 Mb Ethernet interface with Link/Activity Led Power supply - 12VDC. (No protection against overvoltage and inverse polarity) Maximal current consumption: 600 mA / 12VDC 16 SPDT Relay channels: RAS-12-15 (10A / 250VAC, 15A / 120VAC, 15A / 24VDC) - single relay channel schematic 8 analog inputs with 10 bit resolution (0-3.3VDC) 16 (2x8) bit configurable digital I/O port (0-3.3VDC) - in this kit they are reserved for the relay board Dimensions: Relay PCB - 85mm / 300mm / 20mm; DAEnetIP2 - 43mm / 55mm / 15mm Standart protocols: ARP, IP, ICMP (ping), DHCP Supports snmp v1 (snmpset, snmpget, snmptrap), HTTP (integrated web server with autorization) , TFTP (for firmware upgrade) Ports for SNMP (161) and HTTP (80) can be changed Two MAC addresses protection It can be configured with SNMP requests or web browser Reset of the relays on incoming/outgoing ping timeout Function "load outputs(relays) states from EEPROM on boot" Each I/O line can be named by user via web browser It can send traps according analog ADC level Analog Inputs may be referred to control the relay according their level Possibility of connection analog sensors to the analog inputs as LM34DZ, LM35DZ, LM335, MCP9700A Relay PCB parameters: FR4 / 1.5mm / two layers / metallized holes / HAL / white stamp / solder mask / Extra PCB openings for better voltage isolation / Doubled PCB tracks for better voltage isolation Software by Denkovi - DRM Software, DAEnetIP2 Configuration utility, DAE-iModules - FREE iOS mobile app 3rd parity software: Command line utility - netsnmp, Android software (by iSwitch LLC, not free but inexpensive) Software examples: .NET, Java, Labview and PHP - please contact us for download. For detailed user manual - please contact us for download. Application examples Security and fire alarm systems Manual or automatic device restart if event occur Management/monitoring for industrial Sensor information processing Remote electrical devices control Remote lock/unlock doors Home automation Control electrical device remotely The auction includes 1 x IP controller (DAEnetIP2) 1 x 16 SPDT Relay Board (Relay type - RAS-12-15) - 12VDC Flat ribbon labeled cable DRM Software - Denkovi Relay Manager Software. CD is not included in the package but the software is available for download from this link Schematics How to connect inductive loads DAEnetIP2 I/O ports Port JP3 (P3) - the relay board is connected here Port JP4 (P5) - the relay board is connected here Port JP5 (P6) Port JP6 (System Port) PIN # Bit FUNC DIR Bit FUNC DIR Bit FUNC DIR Bit FUNC DIR 1 1 Free I/O 1 Free I/O 1 Free Ain - 3.3V PWR 2 2 Free I/O 2 Free I/O 2 Free Ain - 3.3V PWR 3 3 Free I/O 3 Free I/O 3 Free Ain - Reserved - 4 4 Free I/O 4 Free I/O 4 Free Ain - Ping LED Out 5 5 Free I/O 5 Free I/O 5 Free Ain - Reserved - 6 6 Free I/O 6 Free I/O 6 Free Ain - Target RST Out 7 7 Free I/O 7 Free I/O 7 Free Ain - Switch (RST) Out 8 8 Free I/O 8 Free I/O 8 Free Ain - Switch (SCL) Out 9 - GND PWR - 3.3V PWR - Vref(+3.3V) PWR - Switch(SDA) In/Out 10 - GND PWR - GND PWR - GND PWR - GND PWR Legend: "Free"– the pin is free and defined for the user. "XXXXXX" - the pin is reserved "In" - the pin is input "I/O" – digital input or output depending the settings "Out" - the pin is output "Ain"– analog input Note that the relay board is connected to JP3(P3) and JP4(P5) digital outputs ports. All the DAEnetIP2 I/O ports does not have any protection against overvoltage or reversed polarity. For inputs, if the input voltage exceed 3.3V, the controller may be damaged. If you have questions how to use the I/O ports please contact with us or take a look into the manual. Installation Here are the steps (instructions) how to power on and connect the device directly to your computer (see this image). For router LAN connection (see this image)or Internet connection, please see in the user manual: 1.Connect the DAEnetIP2 controller with your computer via UTP crossover cable. (note that the device does not support AUTO MDIX). 2.The flat ribbon cable connector must be fitted into to DAEnetIP2 IDC in this way 3.Connect each "In" labeled wire into the referred screw terminal of the relay board. For example "In 1" wire goes into Relay 1 In screw terminal, "In 2" wire goes into Relay 2 screw terminal and so on. 4.Connect the GND wire of the flat ribbon cable into the GND screw terminal of the relay board. 5.Connect supply jack to DAEnetIP2. You will have to find suitable power supply adaptor. DAEnetIP2 minimal supply voltage is 7.5 VDC. The maximal voltage is 25 VDC. It is recommended the supply voltage to be 12 VDC. DAEnetIP2 doesn't have any protection against inverted supply voltage, so be careful. The middle pin of the power terminal is + Vcc (Center positive tip polarity) 6.Connect the power wires to the relay board as it is shown on the image right to the text. It is possible to supply the DAEnetIP2 controller and relay board either with single either with 2 separate power supply sources. 7.Now you can power on the whole kit (for example plug the supply adaptor into the electricity network) 8.In case of success you have to see this when you power on the kit (the link led (top) is blinking and the bottom led by default shows the power on and it is constantly on) 9.Check if the relay board power led is on constantly 10. The kit in working condition 11.Open your LAN card network settings and save them, because next step is to change them. 12.Your initial computer IP should be in the device network range. So it is recommend to be 172.16.100.1. Mask 255.255.0.0. Gateway 172.16.100.1. Change them. There is lot of info in the net how to do it (for example a good link is this one) 13.Open web browser and type 172.16.100.2 – default username/password are “admin”/”admin” 14.Now you can access all the parameters via your web browser or software on your computer. Default settings The controller has default settings, in case the access is lost. There are several steps for loading the default settings: Turn off the power supply of the IP controller. Move the jumper from position 1 to position 2. Turn on the power supply of the IP controller. Move the jumper from position 2 to position 1. Turn off the power supply of the IP controller. Turn on the power supply of the IP controller. Default settings Parameter Value DHCP Disabled IP 172.16.100.2 Mask 255.255.255.0 Gateway 172.16.100.1 VLAN ID 1 VLAN mode Disabled Access MAC 1,2 000000000000 SNMP access to IP Enabled SNMP listen UDP port 161 SNMP Read-only string 000000000000 SNMP RW string private SNMP/Web Access network IP 172.16.100.1 SNMP/Web Access network Mask 0.0.0.0 (disabled) Ping Timeout 6 Restart on incoming ping timeout Disabled Restart on remote IP timeout Disabled Remote monitor IP 172.16.100.1 I/O ports settings P3,P5 - Outputs Pull-Up/Pull-Down All “pull-down” Reset I/O ports on restart Disabled TFTP update Enabled TFTP Server IP 172.16.100.1 Broadcast Frames Parse Web Server Enabled Web Server TCP port 80 SNMP traps target host 172.16.100.1 SNMP traps community public Low/High Analog Trap Threshold 0/1023 (disabled) Analog Events – Low, High, Acc None Web user/password admin/admin DAE-iModules iOS App DAE-iModules iOS mobile App We, from Denkovi A E LTD, developed absolutley free iOS App DAE-iModules which allows you to access the I/O lines of the current device and will turn your mobile smartphone in powerful automation tool. Support link: here. The video bellow shows how you can control DAEnetIP2 based device - SNMP 8 Relay Board LM35DZ. Any other Denkovi Ethernet Device from this list can be acessed with same success from your iOS device via DAE-iModules. Some useful information about DAE-iModules and DAEnetIP2: Select device DAEnetIP2. You must be sure the IP, UDP Port and SNMP community are correct, otherwise it won't enter into the device To connect and scale the analog inputs with sensors, please refer to this link: http://denkovi.com/connecting-analog-sensors-to-daenetip2 Access via DAEnetIP2 Manager DAEnetIP2 Manager DAEnetIP2 Manager is configuration utility for Denkovi DAEnetIP2 devices Features Access many DAEnetIP2 controllers at a time SNMPv1 protocol Name for each controller Support most of the DAEnetIP2 OIDs Configurating each P3/P5 I/O line separately as input or output Linearization (scaling) for the Analog Inputs (displaying the analog inputs values in human reading values - volts, meters degrees) Thresholds can be converted automaticaly from human units into divisions For more information about DAEnetIP2 Manager, screen-shots and detailed description and downloads - here Download the last version (install package) - DAEnetIP2Manager.exe Download the last version (install archive) - DAEnetIP2Manager.rar For bugs, suggestions or more information please email us DAEnetIP2 Manager DRM Software DRM Software Denkovi Relay Manager (DRM) is multiplatform software for easy controlling all kinds of Denkovi relay boards (USB,SNMP,TCP/IP) CAUTION! Using of Denkovi Relay Manager (DRM) Software with devices which are not manufactured by Denkovi Assembly Electronics LTD is not allowed! The item is supported by DRM Software. DRM Software will hep you to save money for expensive software and time in programming. It allows you to switch ON/OFF your devices at particular date and time, turn ON/OFF the relays with pulses or control them via specific sequence. If you have ordered at least one of our relay boards from this list you may turn your PC in powerful automation tool. Multiplatform software: supported by Windows/Linux (ver. 2.0) Control up to 32 relay boards User-friendly intuitive interface Save/Load file Control mode: single and multiple setting of the relays Single pulse with adjustable delay from the control mode (ver. 2.0) Timer mode: create timer playlist for the relays Weekly mode: each relay may be turned ON/OFF on each day of the week Calendar mode: each relay may be turned ON/OFF on particular date at particular time Pulse mode: each relay may work in pulse mode by setting duration for ON and duration for OFF. Adjustable number of pulses (ver. 2.0) Each relay from each relay board can work independently in some of the five modes Each relay board and each relay can be named by the user Indicator panel Auto load function - the last working file is loaded when DRM is started Auto connect function - when the relay board is disconnected DRM will keep trying to find and when this is done, the relay board will be connected again Auto start function - DRM software starts when the OS starts (currently this is not supported by Windows 8 and Linux) Auto set function - DRM will set the relays automatically when the relay board is connected Possibility of DRM to starts when PC boots and continues to work from the last saved point For more information about DRM Software, screen-shots and detailed description and download - here DRM Software image - control mode for Internet / Ethernet 16 Channel Relay Board Demo video with DRM Software and Internet / Ethernet 16 Channel Relay Board Access via web browser In order to access your DAEnetIP2 controller from browser, your web browser have to supports javascript. Just write the IP address of the controller in the address bar and you will see the page, which is integrated in the controller (it has small built in server). The default username/password are admin/admin. I/O Ports control/monitor Traps/P5 control. DAEnetIP2 can send traps if some analog input changes its level bellow/above some threshold (Low/High). The same logic can be used for setting one of the digital outputs port - JP5 according analog input port JP6. Android Software You may use this inexpensive but very useful application for your Android smart phone or tablet. You may controll DAEnetIP2 digital outputs or read the DAEnetIP2 analog inputs. With the Gauge functions you may set the measured range and value (C, F, Voltage...). The application is marketed by iSwitch, LLC and may turn your android smartphone in very useful tool controlling our home automation ip relay board. Download it from the Android Market The App documentation may be downloaded from here http://www.iswitchllc.com/DAE%20Relay%20Board%20Documentation.pdf DAEnetIP2 + Relay Board + Android Software by iSwitch, LLC Access via command line Steps for Install net-snmp library in Windows. In this way you will be able to control the ethernet controller with command line. Download the last version net-snmp binary for windows from http://net-snmp.sourceforge.net/download. The file must look like net-snmp-X.X.X.X-X.win32.exe Install the downloaded file. Leave the default options. The packet will be install in c:\usr by default. Download the DAEnetIP2 MIB file from here Copy the mib file here c:\usr\share\snmp\mibs Add new line in the file c:\usr\etc\snmp\snmp.conf with the "mibs all" directive. Now you can test different commands for OID access, supported by this module. Their names you may see in the DAEnetIP2.mib file. For most Linux OS, there is built in the same snmp tool in the kernel. Example commands - here You can also create batch/bash files for setting the outputs for example. If you don't know how - please contact with us. Software examples For developers - we can provide examples and support for the following platforms: Java Example labVIEW example VB.NET Express example Pictures Useful links General links User manual - contact us for DAEnetIP2 user manual SNMP definitions file (MIB file) - here Configuration utility - DAEnetIP2 Manager (Windows/Linux) - DAEnetIP2Manager.exe or DAEnetIP2Manager.rar The firmware file with the current actual version for DAEnetIP2 - here (firmware history - here) Software by Denkovi DAE-iModules - Mobile app for iOS mobile devices, support link here DAEnetIP Burner software for firmware upgrade - here Instructions how to upgrade the firmware - see in the manual or here DRM Software download and documentation - here Software examples - Java, .NET, labVIEW or PHP. Please contact with us for download Third parity software Android application for mobile devices by iSwitch LLC, Android market link - here, documentation - here, support page - here Net-snmp command line tool for windows (instructions how to install - see in the manual) and C++ library - here We recommend also Please visit our ebay web store to find what else we can offer for you related with DAEnetIP2! DAEnetIP2 + 2 ch relay board kit DAEnetIP2 + 8 ch relay board kit Only the DAEnetIP2 controller DAEnetIP2 8 ch relay module for temperature measurement Please read before buy Contact information Skype: borislav__denkov

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RAS-12-15
Protocols	HTTP, SNMP, ICMP, APR, TFTP
MPN	DAEnetIP2 + DAE-RB/Ro16-12V
Power supply	12VDC
Country of Manufacture	Bulgaria
Relays count	16
Type	Relays
Software	control, timer, weekly, calendar, schedule, pulse
UPC	NA
