Excelta Tm-200 Intellitweeze Handheld R-c-l Meter - New

US $421.99

Tracy, California, United States
Jan 29th

Open on mobile:
QR code

An R-C-L Meter in a Tweezer New Field Replaceable Tips Measures Capacitance, Inductance, Resistance, Voltage, Continuity, Diode Polarity Ideal for Surface Mount Devices Convenient one-hand operation Auto-Component Recognition Automatic test range selection Ultra-Portable, Ergonomic Design Available through GSA Schedule Excelta's new TM-200 IntelliTweeze is a handheld R-C-L Meter, and an exciting answer to the old problem of testing/troubleshooting SMD components. With the use of only one hand, this lightweight unit provides a perfect solution for testing & identification of Surface Mount Devices (SMD) as well as for troubleshooting of complex electronic systems. TM-200 IntelliTweeze is designed for component evaluation, on board impedance testing and SMD component sorting. Its unique mechanical and electronic design combines a pair of durable gold-plated tweezers and a digital RCL meter in compact, lightweight, battery powered instrument. Handy Tool for Tiny SMD Components Excelta's TM-200 IntelliTweeze greatly simplifies the testing and troubleshooting process Surface mount components are usually tiny and without wire leads, making it more difficult to test and identify SMD's than conventional components. Excelta's TM-200 IntelliTweeze gives users an easy way to sort and evaluate loose components and to perform on-board measurements and debugging. Precise, field replaceable gold-plated tips made of non-magnetic steel are able to pick and reliably contact even smallest SMD components (as small as 0201 format) or take measurements from the devices already mounted on a board. The probe can also be used to test conventional components with wire leads too short to insert into the test terminals. Automatic Component Recognition TM-200 IntelliTweeze automatically determines the type of component (resistance, capacitance or inductance), and selects the proper range/signal frequency for highest accuracy measurements. Manual overrides are available as well. The TM200 display clearly indicates the type of the component, measurement result and test conditions. The primary display shows the present reading. The secondary display (on top) shows the present reading of additional parameters or measurement conditions when the primary display shows some other feature (C, L). When multiple features are present, TM200's secondary display shows one of the values. The Bar Graph provides an analog indication of the measured input TM-200 IntelliTweeze Ergonomic Design and Convenient Controls The TM-200 is NOT the ST-1 Smart Tweezer: New Features/Improvements Excelta's new TM-200 Tip Cap Protector prevents tip (and finger) damage. Tips go in at any angle & snap into place at the screws. The TM-200 IntelliTweeze is part of Excelta's TweezerMeter family of products, replacing the older ST-1 Smart Tweezer. Some of the many improvements and updated features include: Replaceable gold-plated steel tips (Excelta p/n TM-200X) Diode Polarity – Shows polarity Tip Cap Protector/Pocket Clip – Tips go in at an angle, screws snap into place HOLD Feature – Holds the last reading in display, even after you have released the component Auto-Off – Shuts off in any menu/mode except voltage, & when powered up will continue where it left off Auto-Exit – Only necessary to hit ‘EXIT’ once when using the menus instead of exiting out of every sub menu You can now set the secondary parameters Excelta TM-200 IntelliTweeze Specifications Physical Specifications Operating Temperature: Storage Temperature: Relative Humidity: Altitude Operating: Battery Type: Battery Life (continuous ): Electromagnetic Compatibility (EMC): Size: Weight: Warranty: Calibration: 0°C to +50°C -40 °C to +70 °C 0%-90% (0°C to 35°C) 0-2000 meters 3 x 1.5V LR44 Alkaline or Air Zinc 70 Hours typical with alkaline; 200 hours with air zinc batteries Emission according to FCC 15 Class B 14.0 x 2.5 x 3.0 cm (3.94 x 0.9 x 1.5 in) 53 grams (0.11 lb) 1 year Recommended interval 1year NIST traceable calibration Basic Specifications Measured Parameters: Measuring Frequencies: Measurement Update Rate: DC Voltage: Resistance: Capacitance: Inductance: C+R (ESR), L+R, R 100Hz, 1 kHz, 10kHz Up to 4 measurements per second 0 to 800 mV (up to 8V with manual setting) 0.05 Ohm to 9.9 MOhm 0.5pF to 4999?F 0.5?H to 999mH Accuracy Specifications Resistance Range: Accuracy: Test Frequency: Capacitance Range: Accuracy: Test Frequency: Inductance Range: Accuracy: Test Frequency: DC Voltage Range: Accuracy: 5Ohm - 999kOhm 0.1 -9.9MOhm <1% in the 5Ohm - 999kOhm range <5% in the 0.1 -9.9MOhm range 1kHz 10pF - 100?F 0.5pF - 4999?F <3% in the 10pF - 100?F range <5% in the 0.5pF - 4999?F range 1kHz: 10000pF to 1?F; 10kHz: < 9999pF; 100Hz: > 1?F 10?H - 99mH 0.5?H - 999mH <3% in the 10?H - 99mH range <5% in the 0.55?H - 999mH range 10kHz: 0.5 to 99 1?H; 1kHz: 100?H to 99mH; 0.1 kHz: > 100mH 0V - 8V <1%

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Excelta
MPN	TM-200
Model	TM-200
Country of Manufacture	Canada
