Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: EXFO FTB-1-S2-8G MainFrame w/ Options: (BC# 26625) Power Meter: 850nm 1300nm 1310nm 1490nm 1550nm 1625nm 1650nm LC Connector For Power meter Visual Fault Locator EXFO FTB-720-23B-EA SM Fiber OTDR Module (BC# 26626) SM OTDR Source: 1310nm 1550nm FC Connector For Source EXFO FIP-400-P Fiber Inspection Probe (BC# 16738M) U25A Tip For Probe U12 Tip For Probe FS Tip For Probe U25 Tip For Probe IBC Brand Cleaner SC IBC Brand Cleaner LC (2) SM FC-FC APC Fiber Cable LC-LC Duplex Fiber Connector Mini Toolbox 1.0 Software Ethernet Cable FTB-700 Series Quick Reference Guide Stylus Seikoh Giken Handimate Connector Cleaner AC Adapter/Charger Power Cord User Manual on CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! EXFO FTB-1-S2-8G MINI-OTDR Main Frame w/ Power Meter & Visual Fault Locator & FTB-720-23B iOLM SM 1310 / 1550nm OTDR Module w/ EXFO FIP-400-P Fiber Inspection Probe Dynamic Range: 1310 / 1550 nm : 36 / 34 dB Power Meter: - 850nm - 1300nm - 1310nm - 1490nm - 1550nm - 1625nm - 1650nm Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty EXFO FTB-1 OTDR Mainframe Tester KEY FEATURES Flexible connectivity: USB, mobile, Wi-Fi and Bluetooth capabilities Utilities: supports third-party applications and all the tools that enable technicians to complete their work right in the field Test management/reporting: lets you take advantage of the EXFO Connect environment to monitor fi eld operations (local and remote) PC-oriented: Intel ATOM processor with Windows Embedded Standard operating system, for optimized productivity and versatility Power management: latest battery technology for unmatched operation autonomy MAXIMUM CONNECTIVITY FOR MAXIMUM FIELD-TESTING EFFICIENCY The result of EXFO’s time-proven expertise in portable platform design, the FTB-1 Platform is an open testing solution for network infrastructure construction and troubleshooting. The FTB-1’s built-in intelligence empowers frontline technicians to take field-testing efficiency to the next level. Thanks to a highly “connected” set of tools—including Update Manager and compatibility with the EXFO Connect environment, which provides end-to-end operational visibility and centralized reporting capabilities throughout the entire test instrument pool—the FTB-1 delivers maximum return on your investment. FEATURES USB, mobile, Wi-Fi and Bluetooth connectivity capabilities Supports third-party applications and all the tools that enable technicians to complete their work right in the field Lets you take advantage of the EXFO Connect environment to manage fi eld testing/reporting operations as well as your platform pool Intel ATOM processor with Windows Embedded Standard operating system, for optimized productivity and versatility Latest battery technology for unmatched operation autonomy One GigE port and two USB 2.0 ports Windows Remote Assistance and Remote Control EXFO fiber inspection probe connector interface Display: TFT outdoor-enhanced LCD, 7-inch touchscreen Telcordia-compliant THIRD-PARTY TEST TOOLS Wireshark This live-network packet capture utility makes it possible to look “inside” the packets and obtain data such as transmission time, source, destination, protocol type, etc. Users can then diagnose a problem or root out suspicious behavior. Wireshark is a standard utility on all FTB-1 platforms. JPerf This TCP performance testing tool can create TCP and UDP data streams which measure the throughput of a network that is carrying them. Thanks to various user-definable parameters, technicians can rely on JPerf to optimize or tune a network under test. Network Stumbler Network Stumbler verifies wireless network configurations, enabling field techicians to identify areas that have poor coverage or wireless interference, and helping them to aim antennas for full effect and find unauthorized access points. TECHNICAL SPECIFICATIONS Display Touchscreen, color, 800 x 480 TFT, 178 mm (7 in) Interfaces Two USB 2.0 ports RJ-45 LAN 10/100/1000 Mbit/s Fiber inspection probe connector port (video) Storage 8 GB internal memory (flash) Batteries Rechargeable lithium-ion batteries 8 hours of operation as per Telcordia* (Bellcore) TR-NWT-001138 Power supply AC/DC adapter, input 100-240 VAC, 50-60 Hz, 2 A max, output 24 VDC, 90 W Computer Intel ATOM processor Windows Embedded Standard operating system GENERAL SPECIFICATIONS Size (H x W x D) 190 mm x 252 mm x 66 mm (7 1/2 in x 9 15/16 in x 2 5/8 in) Weight (with battery) 1.5 kg (3.3 lb) Temperature Operating 0 °C to 50 °C (32 °F to 122 °F) Storage –40 °C to 70 °C (–40 °F to 158 °F)(Without Battery) Relative humidity 0 % to 95 % non-condensing PM-1 BUILT-IN POWER METER SPECIFICATIONS Calibrated wavelengths (nm) 850, 1300, 1310, 1490, 1550, 1625, 1650 Power range (dBm) 10 to —86 (InGaAs) Uncertainty (%) b ±5 % ± 3 pW (InGaAs) Display resolution (dB) InGaAs 0.01 = max to —76 dBm 0.1 = —76 dBm to —86 dBm 1 = —86 dBm to min Automatic offset nulling range Max power to —63 dBm for InGaAs Tone detection (Hz) 270/1000/2000 EXFO FTB-720 LAN/WAN Singlemode OTDR Features: Dynamic range of up to 36 dB Event dead zone as low as 0.8 meter Specifications: Wavelength (nm) 1310 ± 20, 1550 ± 20 Dynamic range (dB) 36, 34 Event dead zone (m) 0.8 Attenuation dead zone (m) 5, 5 Distance range (km) Singlemode: 1.25, 2.5, 5, 10, 20, 40, 80, 160, 260 Pulse width (ns) Singlemode: 5, 10, 30, 50, 100, 275, 500, 1000, 2500, 10 000, 20 000 Launch conditions Encircled Flux (EF) compliant Linearity (dB/dB) ±0.03 Loss threshold (dB) 0.01 Loss resolution (dB) 0.001 Sampling resolution (m) Singlemode: 0.04 to 5 Sampling points Up to 256 000 Distance uncertainty (m) ±(0.75 + 0.0025 % x distance + sampling resolution) Measurement time User-defined (60 min. maximum) Typical real-time refresh (Hz) 3 Stable source output power (dBm) –7 (1550 nm) General Size (H x W x D) 130 mm x 36 mm x 252 mm (5 1/8 in x 1 7/16 in x 9 15/16 in) Weight 0.65 kg (1.4 lb) Temperature Operating: 0 °C to 50 °C (32 °F to 122 °F) Storage: –40 °C to 70 °C (–40 °F to 158 °F) Relative humidity 0% to 95% non-condensing For full EXFO FTB-1 FTB-720 product specifications, please click here: EXFO FTB-1 FTB-720 Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. --> This item is subject to a FIXED SHIPPING price. This means that the shipping fee will be the displayed amount for all ship-to destinations shown. This item is eligible for pickup unless otherwise stated. We do not ship to any destinations that are not specified here. Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do/do not cover this cost for all of our US customers. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept payment transactions via our online checkout system! Our checkout process is designed that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through our online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hrs upon receipt of payment from the winning bidder. A Shipment Tracking number will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Terms: All transactions are final. Winning bidder assumes all risk of liability with respect to the purchase of the product. Thank you WE ACCEPT ALL MAJOR CREDIT CARDS Powers Your Online Marketplace Make inventory management a breeze with Kyozou eBay Inventory Management Software
