Exfo Ftb-200 10gig Ethernet W/ Ftb-8510g Ftb-8510b Optical Gigabit Ftb200 200-s1

US $4,295.00

Toledo, Ohio, United States
Jun 5th

Open on mobile:
QR code

The Following Items Are Included: EXFO FTB-200-S1 Test Platform Main Frame (BC# 41522) EXFO FTB-8510G Packet Blazer 10 Gigabit Ethernet Test Module (BC# 7649A) Installed Options: SK-ADV-F Advanced Traffic Filtering SK-IPV6 Internet Protocol Version 6 (IPv6) SK-MPLS Multi Protocol Label Switching SK-PBB-TE Provider Backbone with Traffic Engineering SK-LAN Local Area Network SK-WAN Wide Area network EXFO FTB-8510B Packet Blazer Ethernet Test Module (BC# 7469B) Installed Options: SK-TCP-T TCP Throughput Measurement SK-1000M-E Ethernet 1000Base-T SK-1000M Ethernet 1000Base-X SK-100M Ethernet 100Base-TX SK-10M-E Ethernet 10Base-T SK-2ND-P Enable Second Port SK-ETH-T Ethernet Throughmode Ciena XCVR-020M31 Transceiver 1310nm Ciena XCVR-000G85 Transceiver 850nm (2) Ethernet Cables (2) SM LC-LC Duplex Fiber Optic Cables (2) MM LC-LC Duplex Fiber Optic Cables Stylus AC Adapter/Charger Power Cord (4) Fiber Wipes User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! EXFO FTB-200 Test Platform Main Frame With EXFO FTB-8510B Packet Blazer Ethernet Test Module & EXFO FTB-8510G Packet Blazer 10 Gigabit Ethernet Test Module FTB-8510B Installed Options: - SK-TCP-T TCP Throughput Measurement - SK-1000M-E Ethernet 1000Base-T - SK-1000M Ethernet 1000Base-X - SK-100M Ethernet 100Base-TX - SK-10M-E Ethernet 10Base-T - SK-2ND-P Enable Second Port - SK-ETH-T Ethernet Throughmode FTB-8510G Installed Options: - SK-ADV-F Advanced Traffic Filtering - SK-IPV6 Internet Protocol Version 6 (IPv6) - SK-MPLS Multi Protocol Label Switching - SK-PBB-TE Provider Backbone w/ Traffic Engineering - SK-LAN Local Area Network - SK-WAN Wide Area network Includes Hard Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 1 YEAR WARRANTY The FTB-200 is a compact, modular platform designed for multilayer and multimedium testing Tests physical, transport and datacom Accommodates two field-interchangeable modules Integrated hardware options such as visual fault locator (VFL), fiber inspection probe and power meter Designed for metro/access and FTTx networks Lightweight construction Touchscreen resistant to shock, water, dust and common chemicals Dial and shortkeys for easy scrolling and selecting Extended battery autonomy of more than eight hours, perfect for OTDR testing Improved productivity Four-second power-up time with Windows CE Faster acquisition, processing and reporting A Compact Platform Optimized for Large-Scale Network Deployments EXFO has created the first true compact platform for the supertech. Whether you are testing triple-wavelength insertion loss at the CO or testing data ntegrity at the core, the FTB-200 has the power, speed and modularity that you need in the field. Optimized for all phases of the network lifecycle Construction/installation System provisioning/service activation Maintenance/troubleshooting Lightweight 2.5 kg/5.4 lb (platform only) Fast and powerful Four-second power-up time with Windows CE/mobile Faster acquisition, processing and reporting Instantaneous AutoSync USB data transfer Faster acquisitions—down to five seconds Remote control and virtual applications Flexible connectivity File transfer and software upgrading through USB USB A/A-B, RJ-45 and Bluetooth flexibility Compact Flash (memory, Wi-Fi and Bluetooth) Built for the outside plant Waterproof outer shell, sealed joints, door panels for extra port protection Advanced TFT transflective display, for great visibility under direct sunlight Rugged shortkeys and tracking knob GR-196-CORE-compliant Extended battery autonomy of more than eight hours Spcifications: Display Touchscreen, color, 640 x 480 TFT 163 mm (6 7/16 in) Interfaces USB A main USB B remote RJ-45 LAN 10/100 Mbit/s Compact Flash Fiber inspection probe connector port (video) Storage Internal 80 MB (Flash) USB sticks 1 GB and 2 GB (optional) Compact Flash cards (optional) Batteries Rechargeable Li-Ion 8 h of operation as per Bellcore TR-NWT-001138 Power Supply AC/DC adapter, input 100-240 VAC, 50-60 Hz, 2 A max, output: 24 VDC, 90 W Temperature operating —5 °C to 50 °C (23 °F to 122 °F) storage —40 °C to 70 °C (—40 °F to 158 °F) Relative humidity 0 % to 95 % non-condensing Size (H x W x D) 322 mm x 197 mm x 109 mm (12 11/16 in x 7 3/4 in x 4 5/16 in) Weight 2.5 kg (5.4 lb) Vibration < 1.5 g at 10 Hz to 500 Hz (on three main axes) Mechanical shock < 760 mm on six sides and eight main edges (according to GR-196-CORE) FTB-8510B Packet Blazer Applications Performance validation of carrier-grade Ethernet services IPTV testing and analysis (option available only with the FTB-400 platform) Key Features and Benefits Complete EtherSAM (ITU-T Y.1564) test suite. EtherSAM is the new standard for turning up and troubleshooting mobile backhaul and business Ethernet services Throughput, back-to-back, latency and frame loss measurements as per RFC 2544 (bidirectional results) Multistream generation and analysis, allowing quality of service (QoS) verification through VLAN and ToS/DSCP prioritization testing True wire-speed, stateful TCP throughput test for undisputable SLA reinforcement for Ethernet services IPTV testing and analysis Up to 1 Gbit/s full-line-rate data capture and decode Complete Carrier Ethernet services portfolio: PBB-TE (MAC-in-MAC), MPLS, MPLS-TP, 802.3ah and IPv4/IPv6 1x and 2x Fibre Channel testing Details Assessing the Performance of Ethernet Services EXFO’s FTB-8510B Packet Blazer™ brings performance assurance to Ethernet-based services. Its wide range of test functionalities provides all the necessary measurement tools for verifying service-level agreements (SLAs) between service providers and their customers. The FTB-8510B module tests connectivity in its native format: 10/100/1000Base-T, 100Base-FX, 100Base-LX, 1000Base-SX, 1000Base-LX and 1000Base-ZX for today’s Ethernet services. The FTB-8510B module is the ideal tool for turning-up and troubleshooting Ethernet-based mobile backhaul, commercial and wholesale services. Combined with its rack-mounted manufacturing/R&D-environment counterpart, the IQS-8510B Packet Blazer, the FTB-8510B simplifies and speeds up the deployment of Ethernet services. Key Features Complete EtherSAM (ITU-T Y.1564) test suite allowing full validation of today’s Ethernet services (bidirectional results through dual test set) Throughput, back-to-back, latency and frame loss measurements as per RFC 2544 (bidirectional results through dual test set) Multistream generation and analysis, providing per-stream measurements for throughput, latency, frame loss and packet jitter True wire-speed and stateful TCP throughput testing PBB-TE and MPLS support for Carrier Ethernet Up to 1 Gbit/s full-line-rate data capture and decode IPTV testing and analysis Dual port capability for simultaneous traffic generation and reception at 100 % wire speed for 10/100/1000Base-T, 100Base-FX, 100Base-LX, 1000Base-SX, 1000Base-LX or 1000Base-ZX full-duplex networks at all packet sizes Ethernet in the First Mile 802.3ah testing Fibre Channel 1x and 2x test suite Remote control capability through Visual Guardian Lite and VNC software Configurable advanced filters for in-depth network troubleshooting Service disruption time measurement IPv6 testing EtherSAM: The New Standard in Ethernet Testing ITU-T Y.1564 is the new standard for turning up and troubleshooting Carrier Ethernet services. This methodology is completely adapted to today’s Ethernet services especially mobile backhaul and commercial services. Up to now, RFC 2544 has been the most widely used methodology. However, it was designed for network device testing in the lab, not for services testing in the field. ITU-T Y.1564 is the first testing standard developed for the field. It has a number of advantages over the RFC 2544 including validation of critical SLA criteria such as packet jitter and QoS measurements. This methodology is also significantly faster, therefore saving time and resources while optimizing QoS. Contrary to other methodologies, EtherSAM supports new multiservice offerings. It can simulate all types of services that will run on the network and simultaneously qualify all key SLA parameters for each of these services. Moreover, it validates the QoS mechanisms provisioned in the network to prioritize the different service types, resulting in more accurate validation and much faster deployment and troubleshooting. EtherSAM is comprised of two phases, the service configuration test and the service performance test. Service Configuration Test The service configuration test consists in sequentially testing each service. It validates that the service is properly provisioned and that all specific KPIs or SLA parameters are met. Service Performance Test Once the configuration of each individual service is validated, the service performance test simultaneously validates the quality of all the services over time. EtherSAM Bidirectional Results EXFO’s EtherSAM approach proves even more powerful as it executes the complete ITU-T Y.1564 test with bidirectional measurements. Key SLA parameters are measured independently in each test direction, thus providing 100 % first-time-right service activation—that is the highest level of confidence in service testing. RFC 2544 Test Suite The FTB-8510B Packet Blazer can perform the RFC 2544 test suite for 10/100/1000M interfaces at all frame sizes and at full line rate, allowing the provider to certify that the circuit is efficient and error-free at 100 % utilization. More importantly, when in dual test set mode, the Packet Blazer allows bidirectional testing, providing independent RFC 2544 test results for each direction (local to remote and remote to local) simultaneously. This is especially important when testing Ethernet services as traffic from each direction often takes different paths in the network. Performance results can therefore vary depending on the direction. The Packet Blazer supports automated RFC 2544 testing, including throughput, latency, burst (back-to-back) and frame loss. Automation also provides ease of use for field technicians by enabling accurate, efficient measurements and results through a clear and simple pass/fail indication. In addition, the Packet Blazer generates reports that can be given to customers for future reference related to their specific SLAs. Efficient Testing Leads to Reliable Performance TCP Throughput The Internet protocol (IP) and transmission control protocol (TCP) together form the essence of TCP/IP networking. While IP deals with the delivery of packets, TCP provides the integrity and assurance that the data packets transmitted by one host are reliably received at the destination. Applications such as hypertext transfer protocol (HTTP), e-mail or file transfer protocol (FTP) depend on TCP as their delivery assurance mechanism within networks. Customers deploying such applications expect not only physical and link level SLAs from their service providers, but assurance that their TCP traffic requirements will be supported across the network. The TCP throughput feature on the Packet Blazer™ offers Ethernet service providers the capability of measuring and validating that the services offered to their customers support the TCP traffic performance they expect. MPLS, MPLS-TP and PBB-TE: Carrier Ethernet Transport Solution Testing As technologically-sophisticated business and residential consumers continue to drive demand for premium, high-bandwidth data services such as voice and video, service providers worldwide are evolving their transport infrastructures to support these bandwidth and quality intensive services. No longer is an all-IP core sufficient; providers must now expand their IP convergence to the edge/metro network, in a cost-effective, quality-assured manner. Ethernet has long been accepted as an inexpensive, scalable data networking solution in LAN environments. The stringent QoS expectations require solutions that tap into the cost-effectiveness of Ethernet without sacrificing the benefits of connection-oriented (albeit it costly) TDM solutions such as SONET/SDH. Ethernet tunneling technologies such as Provider Backbone Bridge-Traffic Engineering or PBB-TE (also referred to as PBT) and transport MPLS address these requirements. These technologies enable connection-oriented Ethernet, providing carriers with a means of offering scalable, reliable and resilient Ethernet services. The PBB-TE and MPLS options on the FTB-8510B Packet Blazer offer service providers a comprehensive field tool to efficiently qualify Ethernet services from end-to-end, validating metro and core tunneling technologies. Ethernet Advanced Troubleshooting The FTB-8510B provides a number of advanced features essential for in-depth troubleshooting in the event of network failures or impairments. The advanced filtering option allows the user to configure up to ten filters each with up to four operands, which will be applied to the received Ethernet traffic. Detailed statistics are available for each configured filter providing the user with critical information required to pinpoint specific problems. Additionally, the FTB-8510B supports a traffic scan feature that allows quick identification and monitoring of VLAN and MPLS flows on the network. This can help clearly identify top bandwidth users. The FTB-8510B also supports full-line-rate data capture and decode. This key troubleshooting tool enables field technicians to easily identify complex network issues. The comprehensive capture feature includes the capability to configure capture filters and triggers to quickly zero-in on network events. IPTV Testing and Analysis The IPTV software option, available on the FTB-8510B, leverages the current frame-analysis engine, delivering high performing measurement capabilities and providing users with over 45 different IPTV metrics and statistics in a powerful portable IPTV test platform. The key features and capabilities provided with this software option include RFC 4445 media delivery index (MDI)*, TR 101 290 priority 1 metrics in addition to program clock reference jitter, IGMP support, stream rate and bandwidth utilization on 100 simultaneous MPEG-2, MPEG-4 or VC-1 streams. Usability features include user-configurable alarm thresholds for MDI and other selected metrics, enabling customizable test sequences as well as an auto-stream detection capability that automatically discovers valid IPTV streams within the Ethernet layer. Additionally, stream IP addresses can be linked to a user-definable stream name through an alias table typically containing the name of the broadcast channel. The combination of the portable FTB-500 platform and the FTB-8510B Packet Blazer with the IPTV software option offers service providers the most effective tool to quickly and efficiently test and monitor IPTV streams over their network. For more information on the FTB-8510B Packet Blazer IPTV option, please refer to the IPTV Test Option specification sheet. * The MDI feature of the IPTV software option is not available in the USA. EtherBERT™ Ethernet is increasingly carried across a variety of layer 1 media over longer distances. This creates a growing need for the certification of Ethernet transport on a bit-per-bit basis, which can be done using bit-error-rate testing (BERT). BERT uses a pseudo-random binary sequence (PRBS) encapsulated into an Ethernet frame, making it possible to go from a frame-based error measurement to a bit-error-rate measurement. This provides the bit-per-bit error count accuracy required for acceptance testing of physical-medium transport systems. BERT-over-Ethernet should usually be used when Ethernet is carried transparently over layer 1 media, in cases such as Ethernet over DWDM, CWDM or dark fiber. Ethernet QoS Measurements Data services are making a significant shift toward supporting a variety of applications on the same network. Multiservice offerings such as triple-play services have fuelled the need for QoS testing to ensure the condition and reliability of each service and fully qualify SLA parameters. The FTB-8510B Packet Blazer allows service providers to simultaneously simulate and qualify different applications through its multistream application. The user has the capability to configure up to ten streams with different Ethernet and IP QoS parameters such as VLAN ID (802.1Q), VLAN Priority (802.1p), VLAN stacking (802.1ad Q-in-Q), ToS and DSCP. Specific stream profile s t o transmit VoIP, video and data can be selected for each stream. Throughput, latency, frame loss and packet jitter (RFC 3393) measurements are also available simultaneously for each stream, allowing fast and in-depth qualification of all SLA criteria. Fibre Channel Network Integrity Testing EXFO’s FTB-8510B Packet Blazer module also supports comprehensive Fibre Channel testing. Interfaces This module supports the following Fibre Channel interfaces: Interface Rate (Gbit/s) 1x 1.0625 2x 2.125 Applications Since most storage area networks cover large distances and Fibre Channel has stringent performance attributes that must be respected, testing at each phase of network deployment is imperative to ensure appropriate service levels. EXFO’s FTB-8510B Fibre Channel option provides full wire-speed traffic generation at FC-0, FC-1 and FC-2 logical layers, allowing BER testing for link integrity measurements. Latency, buffer-to-buffer credit measurements for optimization, and login capabilities are also supported. Buffer-to-Buffer Credit Estimation Buffer-to-buffer credits are part of the flow control engine for Fibre Channel connections. This is a crucial configuration parameter for optimal network performance. Usually, network administrators calculate the value by taking the traveled distance and the data rate into consideration. However, since latency issues are not considered, poor accuracy is to be expected. The FTB-8510B module is capable of estimating buffer-to-buffer credit values with respect to latency by calculating the distance according to the round-trip latency time. Latency Transmission of frames in a network is not instantaneous and is subject to multiple delays caused by the propagation delay in the fiber and by processing time inside each piece of network equipment. Latency is the total accumulation of delays between two endpoints. Some applications such as VoIP, video and storage area networks are very sensitive to excess latency. It is therefore critical for service providers to properly characterize network latency when offering Fibre Channel services. From the latency measurement that they perform, the FTB-8510B Packet Blazer estimates buffer-to-buffer credit value requirements. Ethernet Interfaces* Optical interfaces Two ports at 100M and GigE Available wavelengths (nm) 850, 1310 and 1550 100Base-FX 100Base-LX 1000Base-SX 1000Base-LX 1000Base-ZX Wavelength (nm) 1310 1310 850 1310 1550 Tx level (dBm) —20 to —15 —15 to —8 —9 to —3 —9.5 to —3 0 to 5 Rx level sensitivity (dBm) —31 —28 —20 —22 —22 Maximum reach 2 km 15 km 550 m 10 km 80 km Transmission bit rate (Gbit/s) 0.125 0.125 1.25 1.25 1.25 Reception bit rate (Gbit/s) 0.125 0.125 1.25 1.25 1.25 Tx operational wavelength range (nm) 1280 to 1380 1261 to 1360 830 to 860 1270 to 1360 1540 to 1570 Measurement accuracy (uncertainty) Frequency (ppm) ±4.6 ±4.6 ±4.6 ±4.6 ±4.6 Optical power (dB) ±2 ±2 ±2 ±2 ±2 Maximum Rx before damage (dBm) 3 3 6 6 6 Jitter compliance ANSI X3.166 IEEE 802.3 IEEE 802.3 IEEE 802.3 - Ethernet classification ANSI X3.166 IEEE 802.3 IEEE 802.3 IEEE 802.3 - Laser type LED FP VCSEL FP DFB Eye safety Class 1 Class 1 Class 1 Class 1 Class 1 Connector LC LC LC LC LC Transceiver type SFP SFP SFP SFP SFP Electrical interfaces Two ports 10/100BaseT half/full duplex, 1000BaseT full duplex. Straight/crossover cable selection. 10Base-T 100Base-T 1000Base-T Tx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s Tx accuracy (uncertainty) (ppm) ±100 ±100 ±100 Rx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s Rx measurement accuracy (uncertainty) (ppm) ±4.6 ±4.6 ±4.6 Duplex mode Half and full duplex Half and full duplex Full duplex Jitter compliance IEEE 802.3 IEEE 802.3 IEEE 802.3 Connector RJ-45 RJ-45 RJ-45 Maximum reach (m) 100 100 100 *Not all interfaces are available on all models. Please check pictures & enabled options to see what this model has. FTB-8510G Packet Blazer Applications Performance validation of carrier-grade 10 gigabit Ethernet services BERT, RFC 2544 and advanced Layer 3 and 4 traffic generation and analysis Key Features and Benefits Complete EtherSAM (ITU-T Y.1564) test suite. EtherSAM is the new standard for turning up and troubleshooting mobile backhaul and business Ethernet services LAN and WAN PHY capability in a single module Fully integrated functionality for assessing the performance of Ethernet transport networks Packet jitter measurement to qualify Ethernet transport networks for transmission of delay-sensitive traffic such as video and voice-over-IP (VoIP) Throughput, back-to-back, latency and frame loss measurements as per RFC 2544 (bidirectional) Multistream generation and analysis, allowing quality of service (QoS) verification through VLAN and ToS/DSCP prioritization testing Up to 10 Gbit/s full-line-rate data capture and decode MPLS, MPLS-TP, PBB-TE and IPv4/IPv6 support for complete Carrier Ethernet validation Details The Choice for 10 Gigabit Ethernet Performance Assurance EXFO’s FTB-8510G Packet Blazer™ offers performance assurance for 10 Gigabit Ethernet-based services. Its suite of test applications provides all the measurements required for validating service-level agreements (SLAs) between service providers and their customers. Housed in the FTB-500 Platform or FTB-200 Compact Platform, the FTB-8510G module tests connectivity in its native format: 10GBASE-xR or 10GBASE-xW used for transport of Ethernet-based LAN-to-LAN services. It can also be used to test next-generation SONET/SDH, hybrid multiplexers, dark fiber or xWDM networks running 10 Gigabit Ethernet interfaces. Combined with its rack-mounted manufacturing/R&D-environment counterpart, the IQS-8510G Packet Blazer, the FTB-8510G simplifies and speeds up the deployment of Ethernet services. Key Features Complete EtherSAM (ITU-T Y.1564) test suite allowing full validation of today’s Ethernet services (bidirectional results through dual test set) Measures throughput, back-to-back, latency and frame loss as per RFC 2544 (bidirectional results through dual test set) Multistream generation and analysis, providing per-stream measurements for throughput, latency, frame loss and packet jitter LAN PHY and WAN PHY available in a single module Simultaneous traffic generation and reception at 100 % wire speed for 10GBASE-SR, -ER, -LR, -SW, -EW or -LW full-duplex interfaces at all valid frame sizes Transmits and analyzes up to ten streams, perfect for installing, commissioning and maintaining Ethernet networks UDP, TCP and IP header integrity validation Easy-to-use smart user interface (SUI) for configurable screens, customization of test suites, as well as real-time and historical performance reporting Capability to remote control the Packet Blazer test module with the Visual Guardian Lite software or VNC Configurable advanced filters for in-depth network troubleshooting PBB-TE and MPLS support for Carrier Ethernet Up to 10 Gbit/s full-line-rate data capture and decode Smart Loopback Service disruption time measurement Internet protocol version 6 (IPv6 testing) EtherSAM: The New Standard in Ethernet Testing ITU-T Y.1564 is the new standard for turning up and troubleshooting Carrier Ethernet services. This methodology is completely adapted to today’s Ethernet services especially mobile backhaul and commercial services. Up to now, RFC 2544 has been the most widely used methodology. However, it was designed for network device testing in the lab, not for services testing in the field. ITU-T Y.1564 is the first testing standard developed for the field. It has a number of advantages over the RFC 2544 including validation of critical SLA criteria such as packet jitter and QoS measurements. This methodology is also significantly faster, therefore saving time and resources while optimizing QoS. Contrary to other methodologies, EtherSAM supports new multiservice offerings. It can simulate all types of services that will run on the network and simultaneously qualify all key SLA parameters for each of these services. Moreover, it validates the QoS mechanisms provisioned in the network to prioritize the different service types, resulting in more accurate validation and much faster deployment and troubleshooting. EtherSAM is comprised of two phases, the service configuration test and the service performance test. Service Configuration Test The network configuration test consists in sequentially testing each service. It validates that the service is properly provisioned and that all specific KPIs or SLA parameters are met. Service Performance Test Once the configuration of each individual service is validated, the service performance test simultaneously validates the quality of all the services over time. EtherSAM Bidirectional Results EXFO’s EtherSAM approach proves even more powerful as it executes the complete ITU-T Y.1564 test with bidirectional measurements. Key SLA parameters are measured independently in each test direction, thus providing 100 % first-time-right service activation—that is the highest level of confidence in service testing. RFC 2544 Test Suite The FTB-8510G Packet Blazer can perform the RFC 2544 test suite for 10 GbE LAN/WAN interface at all frame sizes and at full line rate, allowing the provider to certify that the circuit is efficient and error-free at 100 % utilization. The Packet Blazer supports automated RFC 2544 testing, including throughput, latency, burst (back-to-back) and frame loss. Automation also provides ease of use for field technicians by enabling accurate, efficient measurements and results through a clear and simple pass/fail indication. In addition, the Packet Blazer generates reports that can be given to customers for future reference related to their specific SLAs. Efficient Testing Leads to Reliable Performance MPLS, MPLS-TP and PBB-TE: Carrier Ethernet Transport Solution Testing As technologically-sophisticated business and residential consumers continue to drive demand for premium, high-bandwidth data services such as voice and video, service providers worldwide are evolving their transport infrastructures to support these bandwidth and quality intensive services. No longer is an all-IP core sufficient; providers must now expand their IP convergence to the edge/metro network, in a cost-effective, quality-assured manner. Ethernet has long been accepted as an inexpensive, scalable data networking solution in LAN environments. The stringent QoS expectations require solutions that tap into the cost-effectiveness of Ethernet without sacrificing the benefits of connection-oriented (albeit it costly) TDM solutions such as SONET/SDH. Ethernet tunneling technologies such as Provider Backbone Bridge-Traffic Engineering or PBB-TE (also referred to as PBT) and transport MPLS address these requirements. These technologies enable connection-oriented Ethernet, providing carriers with a means of offering scalable, reliable and resilient Ethernet services. The PBB-TE and MPLS options on the FTB-8510G Packet Blazer offer service providers a comprehensive field tool to efficiently qualify Ethernet services from end to end, validating metro and core tunneling technologies. EtherBERT™ Ethernet is increasingly carried across a variety of layer 1 media over longer distances. This creates a growing need for the certification of Ethernet transport on a bit-per-bit basis, which can be done using bit-error-rate testing (BERT). BERT uses a pseudo-random binary sequence (PRBS) encapsulated into an Ethernet frame, making it possible to go from a frame-based error measurement to a bit-error-rate measurement. This provides the bit-per-bit error count accuracy required for acceptance testing of physical-medium transport systems. BERT-over-Ethernet should usually be used when Ethernet is carried transparently over layer 1 media, in cases such as Ethernet over DWDM, CWDM or dark fiber. Ethernet QoS Measurements Data services are making a significant shift toward supporting a variety of applications on the same network. Multiservice offerings such as triple-play services have fuelled the need for QoS testing to ensure the condition and reliability of each service and fully qualify SLA parameters. The FTB-8510G Packet Blazer allows service providers to simultaneously simulate and qualify different applications through its multistream application. The user has the capability to configure up to ten streams with different Ethernet and IP QoS parameters such as VLAN ID (802.1Q), VLAN Priority (802.1p), VLAN stacking (802.1ad Q-in-Q), ToS and DSCP. Specific stream profiles to transmit VoIP, video and data can be selected for each stream. Throughput, latency, frame loss and packet jitter (RFC 3393) measurements are also available simultaneously for each stream, allowing fast and in-depth qualification of all SLA criteria. Ethernet Advanced Troubleshooting The FTB-8510G provides a number of advanced features essential for in-depth troubleshooting in the event of network failures or impairments. The advanced filtering option allows the user to configure up to ten filters with each up to four operands, which will be applied to the received Ethernet traffic. Detailed statistics are available for each configured filter providing the user with critical information required to pinpoint specific problems. Additionally, the FTB-8510G supports a traffic scan feature that allows quick identification and monitoring of VLAN and MPLS flows on the network. This can help clearly identify top bandwidth users. The FTB-8510G also supports full-line-rate data capture and decode. This key troubleshooting tool enables field technicians to easily identify complex network issues. The comprehensive capture feature includes the capability to configure capture filters and triggers to quickly zero-in on network events. Functional Specifications* 10BASE-SW 10BASE-SR 10BASE-LW 10BASE-LR 10BASE-EW 10BASE-ER Wavelength 850 nm 850 nm 1310 nm 1310 nm 1550 nm 1550 nm Multimode Multimode Singlemode Singlemode Singlemode Singlemode Tx level (802.3ae-compliant) –7.3 to –1 dBm –7.3 to –1 dBm –8.2 to +0.5 dBm –8.2 to +0.5 dBm –4.7 to +4.0 dBm –4.7 to +4.0 dBm Rx level sensitivity –9.9 to –1.0 dBm –9.9 to –1.0 dBm –14.4 to +0.5 dBm –14.4 to +0.5 dBm –15.8 to –1.0 dBm –15.8 to –1.0 dBm Transmission bit rate 9.95328 Gbit/s ± 4.6 ppm* 10.3125 Gbit/s ± 4.6 ppm* 9.95328 Gbit/s ± 4.6 ppm* 10.3125 Gbit/s ± 4.6 ppm* 9.95328 Gbit/s ± 4.6 ppm* 10.3125 Gbit/s ± 4.6 ppm* Reception bit rate 9.95328 Gbit/s ± 150 ppm 10.3125 Gbit/s ± 150 ppm 9.95328 Gbit/s ± 150 ppm 10.3125 Gbit/s ± 150 ppm 9.95328 Gbit/s ± 150 ppm 10.3125 Gbit/s ± 150 ppm Tx operational wavelength range 840 nm to 860 nm 840 nm to 860 nm 1260 nm to 1355 nm 1260 nm to 1355 nm 1530 nm to 1565 nm 1530 nm to 1565 nm (802.3ae-compliant) Measurement accuracy Frequency ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm Optical power < 2 dB < 2 dB < 2 dB < 2 dB < 2 dB < 2 dB Maximum Rx before damage 0 dBm 0 dBm +1.5 dBm +1.5 dBm +4.0 dBm +4.0 dBm Jitter compliance IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae Ethernet classification IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae Laser type VCSEL VCSEL DFB DFB EML EML Eye safety Class 1 laser; complies Class 1 laser; complies Class 1 laser; complies Class 1 laser; complies Class 1M laser; complies Class 1M laser; complies with 21 CFR 1040.10 with 21 CFR 1040.10 with 21 CFR 1040.10 with 21 CFR 1040.10 with 21 CFR 1040.10 with 21 CFR 1040.10 and IEC 60825-1 and IEC 60825-1 and IEC 60825-1 and IEC 60825-1 and IEC 60825-1 and IEC 60825-1 Connector Duplex LC Duplex LC Duplex LC Duplex LC Duplex LC Duplex LC Transceiver type XFP XFP XFP XFP XFP XFP (compliant with XFP MSA) SYNCHRONIZATION INTERFACES DS1/E1 external input clock interface Parameter DS1 E1 Rx level sensitivity (short haul only) For 772 kHz: For 1024 kHz: TERM: 6 dB (cable loss only) TERM: 6 dB (cable loss only) Reception bit rate 1.544 Mbit/s ± 50 ppm 2.048 Mbit/s ± 50 ppm Input jitter tolerance AT&T PUB 62411, GR-499 section 7.3 G.823 section 7.2 Line coding AMI and B8ZS HDB3 and AMI Input impedance 100 ohms ± 5%, balanced 120 ohms ± 5%, balanced (resistive termination) Connector type BANTAM BANTAM *Not all interfaces are available on all models. Please check pictures & enabled options to see what this model has. For full EXFO FTB-8510 product specifications, please click here: EXFO FTB-8510 Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Sell Smarter with Kyozou. Inventory and Ecommerce Management

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	EXFO
Model	FTB-200
MPN	Does not apply
