Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: EXFO FTB-200-V2-S1 Mini-OTDR Main Frame (BC# 24747) EXFO FTB-7200D-12CD-23B-EI-EI SM MM OTDR Module (BC# 25536) SM OTDR Source: 1310nm 1550nm MM OTDR Source: 850nm 1300nm Ethernet Cable (2) MM SC-SC Fiber Cables (2) SM FC-FC Fiber Cables EXFO Compact Tool Box Software Version 1.0 FTB-7000 Series Quick Reference Guide Stylus (4) Fiber Wipes AC Adapter/Charger Power Cord USB PC Interface Cable Hard Copy User Manual Strap For Unit Carrying Case w/ Strap BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! EXFO FTB-200-V2 Mini-OTDR Main Frame With EXFO FTB-7200D-12CD-23B-EI-EI Singlemode 1310 / 1550nm Multimode 850 / 1300nm OTDR Module Dynamic Range: 850 / 1300 nm : 27 / 26 dB 1310 / 1550 nm : 36 / 34 dB Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty The FTB-200 is a compact, modular platform designed for multilayer and multimedium testing Tests physical, transport and datacom Accommodates two field-interchangeable modules Integrated hardware options such as visual fault locator (VFL), fiber inspection probe and power meter Designed for metro/access and FTTx networks Lightweight construction Touchscreen resistant to shock, water, dust and common chemicals Dial and shortkeys for easy scrolling and selecting Extended battery autonomy of more than eight hours, perfect for OTDR testing Improved productivity Four-second power-up time with Windows CE Faster acquisition, processing and reporting A Compact Platform Optimized for Large-Scale Network Deployments EXFO has created the first true compact platform for the supertech. Whether you are testing triple-wavelength insertion loss at the CO or testing data ntegrity at the core, the FTB-200 has the power, speed and modularity that you need in the field. Optimized for all phases of the network lifecycle Construction/installation System provisioning/service activation Maintenance/troubleshooting Lightweight 2.5 kg/5.4 lb (platform only) Fast and powerful Four-second power-up time with Windows CE/mobile Faster acquisition, processing and reporting Instantaneous AutoSync USB data transfer Faster acquisitions—down to five seconds Remote control and virtual applications Flexible connectivity File transfer and software upgrading through USB USB A/A-B, RJ-45 and Bluetooth flexibility Compact Flash (memory, Wi-Fi and Bluetooth) Built for the outside plant Waterproof outer shell, sealed joints, door panels for extra port protection Advanced TFT transflective display, for great visibility under direct sunlight Rugged shortkeys and tracking knob GR-196-CORE-compliant Extended battery autonomy of more than eight hours Spcifications: Display Touchscreen, color, 640 x 480 TFT 163 mm (6 7/16 in) Interfaces USB A main USB B remote RJ-45 LAN 10/100 Mbit/s Compact Flash Fiber inspection probe connector port (video) Storage Internal 80 MB (Flash) USB sticks 1 GB and 2 GB (optional) Compact Flash cards (optional) Batteries Rechargeable Li-Ion 8 h of operation as per Bellcore TR-NWT-001138 Power Supply AC/DC adapter, input 100-240 VAC, 50-60 Hz, 2 A max, output: 24 VDC, 90 W Temperature operating —5 °C to 50 °C (23 °F to 122 °F) storage —40 °C to 70 °C (—40 °F to 158 °F) Relative humidity 0 % to 95 % non-condensing Size (H x W x D) 322 mm x 197 mm x 109 mm (12 11/16 in x 7 3/4 in x 4 5/16 in) Weight 2.5 kg (5.4 lb) Vibration < 1.5 g at 10 Hz to 500 Hz (on three main axes) Mechanical shock < 760 mm on six sides and eight main edges (according to GR-196-CORE) EXFO FTB-7200D OTDR Module Short Dead Zones: EXFO’s FTB-7200D helps you boost test productivity for inside-plant applications. Their exceptional 1 m event dead zone enables you to easily locate and characterize all events between the transmitter and the central office’s fiber distribution panel. This feature also comes in handy in metro, access and FTTH network applications, where events are usually closely spaced. The FTB-7200D model is ideal for private/premises/enterprise network testing. It offers the industry’s shortest dead zones, as well as lightning-fast acquisitions. Test multimode fiber within premises, or singlemode fiber between premises—all with a single OTDR unit—and maximize your return on investment. Delivering Higher Accuracy for Event Location: The FTB-7200D locates events with pinpoint accuracy: Up to 128 000 sampling points for higher trace resolution Sampling resolution down to 4 cm, for ultra-accurate fault location Better linearity—down to ±0.03 dB/dB—for more accurate event characterization Specifications: Model Wavelength (nm) a Dynamic range b, c (dB) Event dead zone d (m) Attenuation dead zone d (m) FTB-7200D-12CD-23B 850 ± 20/1300 ± 20 1310 ± 20/1550 ± 20 27/26 36/34 1/1 1/1 3/4 4.5/5 Distance range (km) Multimode: 0.1, 0.3, 0.5, 1.3, 2.5, 5, 10, 20, 40 Singlemode: 1.3, 2.5, 5, 10, 20, 40, 80, 160, 260 Notes a Typical. b Typical dynamic range with longest pulse and three-minute averaging at SNR = 1. c Multimode dynamic range is specifi ed for 62.5 µm fi ber; a 3 dB reduction is seen when testing 50 µm fi ber. d Typical dead zone for multimode refl ectance below –35 dB and singlemode refl ectance below –45 dB, using a 5 ns pulse e For multimode port, controlled launch conditions allow 50 µm and 62.5 µm multimode fi ber testing f Does not include uncertainty due to fi ber index g Typical output power is given at 1300 nm for multimode output and 1550 nm for singlemode output Pulse width (ns) Multimode: 5, 10, 30, 100, 275, 1000 Singlemode: 5, 10, 30, 100, 275, 1000, 2500, 10 000, 20 000 Launch conditions e Class CPR 1 or 2 Linearity (dB/dB) ±0.03 Loss threshold (dB) 0.01 Loss resolution (dB) 0.001 Sampling resolution (m) Multimode: 0.04 to 2.5 Singlemode: 0.04 to 5 Sampling points Up to 128 000 Distance uncertainty f (m) ± (0.75 + 0.0025 % x distance + sampling resolution) Measurement time User-defi ned (60 min maximum) Typical real-time refresh (Hz) 3 Stable source output power g (dBm) –1.5 (1300 nm), –7 (1550 nm) For full EXFO FTB-200-V2 FTB-7200D product specifications, please click here: EXFO FTB-200-V2 FTB-7200D Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Manage all your eBay listings with Kyozou eBay Listing Software
