Extron Ipcp 505 Control Processor Perfect Condition # 60-1071-02

US $750.00

Vista, California, United States
Feb 28th

Open on mobile:
QR code

This is an Extron IPCP 505 Control Processor. If you know what it is, and know how to program it, there is little left to tell. Specs are below, but if your an Extron trained integrator, there is nothing left to explain. Its complete. It works. IT has the latest firmware on it, and is 100% complete. I have a touchpanel also listed here on ebay if you need one. Just look at my other items, and you will see it. Its a TLP 700TV. Any questions, let me know- IPCP 505 Ethernet control interface Connectors 1 RJ-45 female connector Data rate 10/100Base-T, half/full duplex with autodetect Protocols ARP, ICMP (ping), IP, TCP, UDP, DHCP, HTTP, SMTP, Telnet Default settings Link speed and duplex level = autodetected IP address = 192.168.254.254 Subnet mask = 255.255.0.0 Gateway = 0.0.0.0 DHCP = off Web server Up to 200 simultaneous sessions 975 MB nonvolatile user memory Program control Extron Global Configurator for Windows® Extron Simple Instruction Set (SIS™) Microsoft® Internet Explorer®, Telnet Global Viewer requirements Microsoft® Internet Explorer® ver. 6 or higher Serial control interface Quantity/type 2 bidirectional RS-232, RS-422, RS-485 6 bidirectional RS-232 Connectors (2) 3.5 mm captive screw connectors, 5 pole (6) 3.5 mm captive screw connectors, 3 pole Baud rate and protocol 300 to 115200 baud (9600 baud = default); 8 (default) or 7 data bits; 1 (default) or 2 stop bits; no parity (default), or even or odd parity NOTE The 5-pole ports support both hardware and software flow control. The 3-pole ports support software flow control. Pin configurations Serial, 5-pole captive screw RS-232 (default) Pin 1 = Tx, 2 = Rx, 3 = GND, 4 = RTS, 5 = CTS RS-422 Pin 1 = Tx-, 2 = Rx-, 3 = GND, 4 = Tx+, 5 = Rx+ RS-485 Pins 1 and 2 (tied together) = data-, 3 = GND, 4 and 5 (tied together) = data+ Serial, 3-pole captive screw Pin 1 = Tx, 2 = Rx, 3 = GND Flex I/O control interface Quantity/type 4 analog input or digital input/output (configurable) Connectors (1) 3.5 mm captive screw connector, 5 pole Digital inputs Input voltage range 0 to 24 VDC, clamped at +30 VDC Input impedance 28k ohms Programmable pullup 2k ohms to +5 VDC Threshold low to high Programmable range: 100 mV to 24 VDC, default = 2 VDC Threshold high to low Programmable range: 100 mV to 24 VDC, default = 1 VDC Digital outputs 250 mA sink from 24 VDC max. Analog inputs 12 bit A/D, 0 to 24 VDC Pin configurations 1, 2, 3, 4 = flex I/Os 1, 2, 3, 4; 5 = GND Control — IR/serial ports Quantity/type 8 programmable: unidirectional RS-232 (±5 V), or TTL level (0 to 5 V) infrared (carrier and non-carrier) up to 1 MHz Connectors (4) 3.5 mm captive screw connectors, 4-pole Baud rate and protocol (RS-232) 300 to 115200 baud (9600 baud = default); 8 (default) or 7 data bits; 1 (default) or 2 stop bits; no parity (default), or even or odd parity Pin configurations For each port, pin 1 = signal, 2 = GND IR output carrier frequency 30 kHz to 1 MHz IR learning carrier frequency 30 kHz to 1 MHz IR learning capture distance 2" (5.1 cm) to 12" (30.5 cm) from the front panel Relay control interface Quantity/type 8 normally open relays Relay control connectors (4) 3.5 mm captive screw connectors, 4 pole Relay control contact rating 24 VDC, 1 A Switched DC power output Quantity/type 4 switched 12 VDC outputs Connectors (4) 3.5 mm captive screw connectors, 2 pole Power Maximum 40 watts total Power sense Range 0.1 watt to 40 watts General Power supply Internal Input: 100-240 VAC, 50-60 Hz Power consumption 63.3 watts Temperature/humidity Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing Cooling Convection, no vents Thermal dissipation 33.2 BTU/hr Mounting Rack mount Yes, with optional 1U rack shelf Enclosure type Metal Enclosure dimensions 1.7" H x 8.7" W x 10.5" D (1U high, half rack wide) (4.3 cm H x 22.1 cm W x 26.7 cm D) (Depth excludes connectors.) Product weight 2.5 lbs (1.1 kg) Shipping weight 5 lbs (3 kg) Vibration ISTA 1A in carton (International Safe Transit Association) Regulatory compliance Safety CE, c-UL, UL Meets UL 60950 for safety. EMI/EMC CE, C-tick, FCC Class A, ICES, KC mark, VCCI Environmental Complies with the appropriate requirements of RoHS, WEEE
