Extron PVS 204SA PoleVault Switcher (Includes PVT RGB D & PVT CV D) Qty Disc, US $125.00 – Picture 0

Extron PVS 204SA PoleVault Switcher (Includes PVT RGB D & PVT CV D) Qty Disc, US $125.00 – Picture 1

Extron PVS 204SA PoleVault Switcher (Includes PVT RGB D & PVT CV D) Qty Disc, US $125.00 – Picture 2

Extron Pvs 204sa Polevault Switcher (includes Pvt Rgb D & Pvt Cv D) Qty Disc

US $125.00

McDonough, Georgia, United States
Jan 30th

Open on mobile:
QR code

Extron PVS 204SA PoleVault Switcher (Includes PVT RGB D & PVT CV D) (Ask About VGA Distribution Amplifiers and Line Drivers) **Email and ASK ABOUT FREE SHIPPING and Quantity DISCOUNTS*** Specifications: Video — RGB Gain ................................................ Unity † Crosstalk ........................................ -70 dB @ 5 MHz Switching speed ............................ 1 ms (max.) from front panel, 1-2 seconds from remote panel CMRR ............................................. -90 dB @ 100 Hz, -70 dB @ 10 MHz Video input — RGB Number/signal type ..................... 2 VGA-UXGA RGBHV, RGBS Connectors ..................................... 2 pairs female RJ-45 (See chapter 2, “Installation”, “A/V input connections” section, for pin configurations.) Nominal level ................................ 0.7 Vp-p for RGB † Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p with no offset † Impedance ..................................... 75 ohms † Horizontal frequency .................... 15 kHz to 145 kHz Vertical frequency .......................... 30 Hz to 170 Hz DC offset (max. allowable)........... 1.0 V Video output — RGB Number/signal type ..................... 1 VGA-UXGA RGBHV, RGBS (follows input type) Connectors .................................... (1) 15-pin HD female Nominal level ................................ 0.7 Vp-p for RGB † Minimum/maximum levels ........ 0.3 V to 1.5 Vp-p (follows input) Impedance ..................................... 75 ohms Return loss ..................................... <-40 dB @ 5 MHz DC offset ........................................ ±5 mV, max., with input at 0 offset Video — composite video Gain ................................................ Unity † Differential phase error ............... 0.25? at 3.58 MHz and 4.43 MHz Differential gain error .................. 0.15% at 3.58 MHz and 4.43 MHz Switching speed ............................ 1 ms (max.) from front panel, 1-2 s from remote panel CMRR ............................................. -90 dB @ 100 Hz, -70 dB @ 10 MHz Video input — composite video Number/signal type ..................... 2 composite video Connectors ..................................... 2 female RJ-45 (See chapter 2, “Installation”, “A/V input connections” section, for pin configurations.) Nominal level ................................ 1 Vp-p for composite video (including sync) † Minimum/maximum levels ........ Analog: 0.4 V to 2.0 Vp-p with no offset Impedance ..................................... 75 ohms Return loss ..................................... <-40 dB @ 5 MHz DC offset (max. allowable)........... 1.0 VPVS 204SA Switcher • Reference Material A-3 Video output — composite video Number/signal type ..................... 1 composite video Connectors .................................... 1 RCA female Nominal level ................................ 1 Vp-p for composite video (including sync) † Minimum/maximum levels ........ 0.4 V to 2.0 Vp-p (follows input) Impedance ..................................... 75 ohms Return loss ..................................... -40 dB @ 5 MHz DC offset ........................................ ±20.5 mV with input at 0 offset Sync Input type ...................................... RGBHV, RGBS (RGB input) Output type .................................... RGBHV, RGBS (RGB output, follows input) Standards ........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM (for composite video inputs and outputs) Input level ..................................... 2.0 V to 5.5 Vp-p Output level .................................. 4.5 V to 5.5 Vp-p, unterminated Input impedance .......................... 511 ohms Output impedance ....................... 75 ohms Max. propagation delay ............... 40 ns (system only, not due to cable delay) Max. rise/fall time ........................ 15 ns Polarity............................................ Positive or negative (follows input) Audio input — refer to the PVT Series Transmitters’ audio specifications Number/signal type ..................... 4 proprietary signals from Extron PVT Series wall plates and transmitters Connectors .................................... 4 female RJ-45 (2 shared with RGB inputs, 2 shared with composite video inputs) N 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ? 2 dBu Audio — preamplifier Input gain adjustment ................. –18 dB to +24 dB (default = 0 dB), adjustable per input via RS-232 Input level sensitivity ................... -10 dBV (0.316 Vrms) for maximum output before clipping Volume control range ................... 0 to -60 dB Crosstalk ........................................ <-85 dB @ 1 kHz, (with 50' cables) † Stereo channel separation ........... >80 dB @ 1 kHz, (with 50' cables) † Bass adjustment ............................. ±10.5 dB @ 50 Hz Treble adjustment .......................... ±10.5 dB @ 15 kHz Audio input —Aux/Mix Number/signal type .................... 1 mono, unbalanced or balanced Connectors .................................... (1) 3.5 mm captive screw connector, 3 pole Impedance ..................................... >15k ohms unbalanced, DC coupled >22k ohms balanced, DC coupled Nominal level ................................ -20 dBV (100 mVrms) Maximum level ............................. +16 dBV (6.31 V), (balanced) at 1% THD+N

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Some cosmetic wear but works fine. Includes power supply.”
