Extron Video Test Generator 150

US $110.00

Fort Washington, Maryland, United States
Jun 9th

Open on mobile:
QR code

IN VERY GOOD CONDITION, ALL FUNCTIONALITY WORKING. feel free to ask questions. Specifications — VTG 150, VTG 200 Test Generators Video signal characteristics Dot clock ....................................... 230 MHz Pixel clock accuracy..................... 0.02 MHz Scan rate accuracy ....................... ±2% Frequency range .......................... 15 kHz to 127 kHz Rise/fall time ............................... <1.2 ns Video output Number/signal type VTG 150 ............................. 1 RGBHV, RGBS, RGsB, RsGsBs VTG 200 ............................. 1 RGBHV, RGBS, RGsB, RsGsBs, NTSC/PAL composite video Connectors VTG 150 ............................. 5 BNC female, (1) 15-pin HD female, (1) 15-pin D female, (1) 9-pin D female VTG 200 ............................. 5 BNC female, 1 BNC female, (1) 15-pin HD female, (1) 15-pin D female, (1) 13W3 D female, (1) 9-pin D female Rates VTG 150 ............................. VGA–UXGA, Apple/Mac/Quadra, TTL, HDTV VTG 200 ............................. VGA–UXGA, Apple/Mac/Quadra, Sun/SGI/NeXT/IBM Power PC, TTL, HDTV Maximum level ............................ 1V p-p Impedance .................................... 75 ohms Return loss .................................... <-30dB @ 5 MHz DC offset ....................................... ±5mV maximum Control/remote — test generator (VTG 200 only) Serial control port ........................ RS-232, 9-pin female D connector Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity Serial control pin configurations 2 = TX, 3 = RX, 5 = GND Program control ........................... Extron’s control program for Windows® Extron’s Simple Instruction Set™ – SIS™ Extron’s Advanced Instruction Set™ – AIS™ General Power............................................. 100VAC to 240VAC, 50/60 Hz, 9 watts, VTG 150 ............................. external, autoswitchable; to 9.0VDC, 0.6 A VTG 200 ............................. internal, autoswitchable Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing Rack mount ................................... No Enclosure type .............................. Metal Enclosure dimensions VTG 150 ............................. 4.7" H x 4.6" W x 1.7" D 11.9 cm H x 11.7 cm W x 4.3 cm D (5.5” (14 cm) H includes connectors) VTG 200 ............................. 6.3" H x 9.0" W x 2.0" D 16.0 cm H x 22.9 cm W x 5.1 cm D (7.0” [17.8 cm] H including connectors.) Product weight VTG 150 ............................. 1.7 lbs (0.8 kg) VTG 200 ............................. 3.3 lbs (1.5 kg) Shipping weight VTG 150 ............................. 4 lbs (1.8 kg) VTG 200 ............................. 7 lbs (3.2 kg) VTG 150, VTG 200 • Specifications 1-3 Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association) Listings .......................................... UL, CUL Compliances — VTG 200 ............ CE, FCC Class B Warranty ....................................... 3 years parts and labor

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	EXTRON
Country/Region of Manufacture	United States
Model	VTG 150
MPN	626012007 E12082
