Fairchild T5220 Electro Pneumatic Transducer Tb5220-1

US $780

Chicago, Illinois, United States
May 31st

Open on mobile:
QR code

Store Policies - Payment | Returns | Shipping | Contact Us | About Us Visit our Store Check out my other items! . Fairchild Electro Pneumatic Transducer Part Number: TB5220-1 Manufacturer: Fairchild Products Model T5220 Precision Electro-Pneumatic (I/P, E/P) Transducer more of the same part number in stock Specifications Buster Ratio: 1:1 Filtered Supply: 20 PSI Buster Output: 0-12 PSI (-3 psi bias) Boosted Unit: 15 SCFM Input: 4-20 ma / 10-50 ma The T5220 Transducer is an electro-pneumatic device that converts a DC current or voltage input signal to a proportional pneumatic output This device is made up of two sections, the Signal Conversion Section and the Pneumatic Section. The Signal Conversion Section (PC Board) accepts a DC current or voltage. This signal is applied to a coil which creates a magnetic force that moves a Flexure Arm. The Pneumatic Section operates as a force balance system. A Sapphire Ball floats inside a Nozzle and controls the output pressure by exhausting air supplied through an Orifice. This Sapphire Ball acts as a piston exerting a force which is balanced against the force transferred to the Flexure Arm by the Coil. The Booster Section amplifies the output pressure of the transducer. At set point, the force due to transducer output pressure acting on the top of the Upper Diaphragm is balanced by the force due to booster output pressure acting on the underside of the Lower Diaphragm. Not the item your looking for?? Click here to Search our Store for other Fairchild we sell!! New - Unused Shipping Charge $ 12.99 (USA 48 States only!) This item will ship USPS. Canada, Mexico and Overseas Customers, please submit full address, for shipping cost quote Listing #1285 or contact DYMATIC, INC. Our 30th Year 5328 N. Northwest Hwy. Chicago, IL 60630-1137 USA TEL: 773-763-2100 FAX: 773-763-6877 Excess & Surplus Inventories from FLUID POWER DISTRIBUTORS and the OEM Industry. Inventory of 1,000,000 NEW components and parts for Immediate Delivery. Serving FOR 30 YEARS: THE FLUID POWER INDUSTRY, THE OEM MARKET, THE WHOLESALE AND DISTRIBUTION MARKET. Please ask all your questions before buying or bidding. RETURNS NOT ALLOWED ON THIS ITEM KNOW WHAT YOU BUY , BUY WHAT YOU KNOW . *Dymatic, Inc. is not an authorized distributor of any products listed. More in stock , contact seller for price and delivery. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
