Fg Wilson Sti-400, 400 Amp Ats, 190-480v

US $2,030.00

Hollywood, Florida, United States
Jan 31st

Open on mobile:
QR code

THIS IS A SURPLUS ITEM TO BE SOLD AS IS, NO WARRANTY. FREIGHT CHARGES NOT INCLUDED, PLEASE CONTACT US BEFORE FOR A FREIGHT QUOTE The FG Wilson TI range of Intelligent Load Transfer Panels operate in conjunction with our autostart generating set control panels and incorporate the latest state of the art control technology.The panels contain all the control logic to automatically switch the load between the mains supply and the generating set. Only a 2 wire control inter-connection to the generating set control panel is necessary. For ease of access the Printed Circuit Board (P.C.B.) is mounted on a hinged lockable access door. The P.C.B. will operate with any 3 phase voltage from 190 to 480 volts (50 or 60 Hz)and can easily be converted for single phase operation. The connections to the control P.C.B. are by a multi-pin plug and socket. A door mounted Maintenance Control Keyswitch is included as a standard feature so the P.C.B. can easily be removed for maintenance purposes without disrupting the power supply to the load. With the exception of the panels up to the 125 Amp unit which are wall mounting, all panels are of the floor standing type, of modular construction and designed for bottom cable entry. They consist of a robust screw together steel frame with exterior cladding plates, contactor mounting chassis and gland plate. All are painted with polyester powder to ensure a high degree of scuff resistance and durability. The construction permits the panel to be completely dismantled and re-assembled on site in the case of difficult access.This brochure refers only to load transfer panels up to 1600 Amps. For information on TI panels above 1600 Amps, consult the factory. Contactors: Two 4 Pole Mechanically and Electrically Interlocked Load Transfer Contactors up to 1000 Amp Motorised Switch Disconnectors 1250 and 1600 Amp Status Indication: Mains Available, Mains On Load, Generator Available, Generator on Load Voltage Range - 190 to 480 volts Frequency - 50 or 60 Hz Controls: Mode Selector Switch: Test with Load / Auto / Test Without Load Mains Voltage Sensing Relays (50 - 280V AC) Delay On Start Timer (minimum 1 sec; maximim 60 sec. Factory setting 6 sec.) Generator Voltage Sensing Relays (50 - 280V AC)Delay On Transfer Timer (minimum 1 sec; maximum 60 sec. Factory setting 6 sec.) Delay on Retransfer Timer (minimum 2 min. 40 sec; maximum 28 min. Factory setting 2 min. 40 sec) Cool Down Timer (minimum 3 sec; maximum 8 min.Factory setting 45 sec.) Maintenance Control Keyswitch Lamp Test Pushbutton THIS IS A SURPLUS ITEM TO BE SOLD AS IS, NO WARRANTY. FREIGHT CHARGES NOT INCLUDED, PLEASE CONTACT US BEFORE FOR A FREIGHT QUOTE

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Type

STI-400
