Fhastron, Dc Amperes Meter, Model# 320-13293, Nsn6625002545229

US $77

Hurricane, Utah, United States
Jun 10th

Open on mobile:
QR code

FHASTRON, DC AMPERES METER, Model# 320-13293, NSN6625002545229 AACT CIRCUIT CURRENT FOR WHICH DESIGNED DC AAPB DIELECTRIC WITHSTANDING VOLTAGE IN VOLTS 1500.0 ABHP OVERALL LENGTH 1.912 INCHES NOMINAL ABTB MOUNTING HOLE DIAMETER 0.150 INCHES NOMINAL ABWG SCALE DIVISION QUANTITY 50 SINGLE INDICATOR SINGLE RANGE ADAV OVERALL DIAMETER 3.490 INCHES NOMINAL ADZC ENVIRONMENTAL PROTECTION AIRTIGHT AND DUST RESISTANT AND FUNGUS RESISTANT AND HEAT RESISTANT AND HUMIDITY RESISTANT AND SHOCK RESISTANT AND VIBRATION RESISTANT AND WATER RESISTANT AFFL MOUNTING BOLT CIRCLE DIAMETER 3.120 INCHES NOMINAL AKYN FURNISHED ITEMS AND QUANTITY NUT 5; LOCKWASHER 5; SEAL 1 AMKD INDICATOR TYPE DIAL W/POINTER AMQY INSTALLATION DESIGN PANEL ANRL MOUNTING ARRANGEMENT STYLE E5 THREE HOLE/STUD BOLT CIRCLE ANTG SENSITIVITY RATING 50.0 MILLIVOLTS APMM DIAL SCALE MARKING COLOR BLACK SINGLE INDICATOR SINGLE RANGE APPN ACCURACY IN PERCENT -2.0 TO 2.0 AT FULL SCALE SINGLE INDICATOR SINGLE RANGE APSN PANEL FOR WHICH DESIGNED MAGNETIC OR NONMAGNETIC APST METER DEPTH BEHIND MOUNTING FLANGE 0.938 INCHES NOMINAL APSW METER BODY DIAMETER BEHIND MOUNTING FLANGE 2.735 INCHES NOMINAL AQEC MOVEMENT TYPE MOVING COIL, PERMANENT MAGNET AQFY BACKGROUND COLOR WHITE SINGLE INDICATOR SINGLE RANGE ASSS POINTER COLOR BLACK SINGLE INDICATOR SINGLE RANGE AWZJ POWER SOURCE EXTERNAL AXHR MOUNTING FACILITY TYPE AND QUANTITY 3 SCREW AND 3 UNTHREADED HOLE BHDC SCALE GRADUATION TYPE LINEAR SINGLE INDICATOR SINGLE RANGE BHMW MEASUREMENT RANGE 0.0 TO 50.0 AMPERES, DC SINGLE INDICATOR SINGLE RANGE BHSX CIRCUIT CONSTRUCTION TYPE NONELECTRONIC CBBL FEATURES PROVIDED MAGNETIC SHIELD AND ZERO ADJUSTER CTQL MOVEMENT SUSPENSION METHOD JEWEL PIVOT BASE CTTD CIRCUIT ATTACHMENT METHOD AND QUANTITY 2 THREADED STUD FEAT SPECIAL FEATURES SEALED; RUGGEDIZED MATT MATERIAL PLASTIC NHCF NUCLEAR HARDNESS CRITICAL FEATURE NONHARDENED SFTT SURFACE TREATMENT PAINT SPCL SPECIAL TEST FEATURES COMPLIES WITH MIL-M-10304 STYL STYLE DESIGNATOR C1 ROUND FLUSH MTG ZZZV FSC APPLICATION DATA TEST SET,ELECT. EQUIP Subject to prior Sale! Handling fees may apply to items requiring additional packing or materials. 14 day right of return if not satisfied. Thanks for looking!! Please Visit our Store for more great items. 10610 S-22 MV209-H
