Fiber Optic Ray Recognizing Ry-3306id Optical Fiber Identifier 800~1700nm New

US $294.50

Hong Kong, Hong Kong
Mar 12th

Open on mobile:
QR code

fiber optic Ray Recognizing RY-3306ID Optical Fiber Identifier 800~1700nm New Brand 12 Months Warranty Description Quickly identify the direction of transmitted fiber and display the relative core power without any damages to the bended fiber. -Easy-to-use with “ONE KEY”operation. -Efficiently identifies the traffic direction and frequency tonel (270Hz, 1KHz, 2KHz) with audible warning. -Displays the relative core power. -More accurate test with Sunshade. -Easy-to-replace adaptors. -Durable metal housing and quality construction. -Lower power indication. Identified Wavelength Range 800-1700 nm Identified Signal Type CW, 270Hz±5%,1kHz±5%,2kHz±5% Detector Type ?1mm InGaAs 2pcs Adapter Type ?0.25 (Applicable for Bare Fiber) ?0.9 (Applicable for ?0.9 Cable ) ?2.0 (Applicable for ?2.0 Cable ) ?3.0 (Applicable for ?3.0 Cable ) Signal Direction Left & Right LED Singe Direction Test Range (dBm, CW/0.9mm bare fiber) -46~10(1310nm) -50~10(1550nm) Signal Power Test Range (dBm, CW/0.9mm bare fiber) -50~+10 Signal Frequency Display (Hz) 270, 1k, 2k Frequency Test Range (dBm, Average Value) ?0.9, ?2.0, ?3.0 -30~0 (270Hz,1KHz) -25~0 (2KHz) ?0.25 -25~0 (1KHz,2KHz) -20~0 (2KHz) Insertion Loss(dB, Typical Value) 0.8 (1310nm) 2.5 (1550nm) Alkaline Battery(V) 9 Operating Temperature -10-+60 Storage Temperature -25-+70 Dimension (mm) 196X30.5X27 Weight (g) 200 Warranty * 12 Months Warranty. * Payment to be returned if Customer is not satisfied with the product and Refund in 3 working days while received the returned product. Service We also have very good offer for: -Brand New Furukawa Fitel S178A V2 splicer Kit -Sumitomo Type Z1C splicer -Fujikrua FSM-60S splicer -Fujikrua FSM-70S splicer -Fujikrua FSM-80S splicer -Fujikrua FSM-70R splicer -Fujikrua FSM-80R splicer -Fujikrua FSM-60R Ribbon splicer -EXFO MAX-715B/720B/730B OTDR -OTDR JDSU MTS-8000/6000/4000/2000, -OTDR EXFO FTB-200V2 -OTDR Ando AQ7275, -Fiber Tool Kit, -Portable Optical Power Meter and Light source. Shipping Shipping to worldwide, Shipping cost around US$20.00 to worldwide from Hong Kong. *We will ship all items within 1-3 working days upon receipt of payment,our goal is: ship it as fast as we can. *Standard Shipping: To USA,UK and Australia by ePacket,need 7-12 working days. *Expedited/Standard Int'l Shipping by Fedex,DHL,TNT and EMS courier: To USA,need 3-6 working days,To other countries,need 4-8 working days normally.But sometimes int'l delivery is highly depended on the courier company and local customs/duties. *Import duties and taxes are not included in the item price or shipping charges.These charges are the buyer responsibility. Payment Only acceptable forms of payment are PayPal. Contact information fonsuntekonline@gmail.com

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	RY-3306ID
Country/Region of Manufacture	China
MPN	RY-3306ID
