Template By Froo! FIELD CONTROLS SWG-4HD POWER VENTER, 4" 46275400 FIELD CONTROLS PART # 46275400 SWG-4HD POWER VENTER, 4" INLET (HEAVY DUTY) 170,000BTU/HR. 1.10 GPH For sidewall venting of gas and oil fired equipment SWG-4D SPECIFICATIONS PROPERTY OF PATRIOT SUPPLY MODEL MAX* OIL GPH INPUT 100psi MAX* OIL GPH INPUT 140psi MAX** GAS BTU/hr. INPUT Maximum Equivalent Feet of Vent Pipe VENT PIPE SIZE AT MAX BTU/hr. INPUT AT 60% OF MAX BTU/hr. INPUT SWG-4HD 1.1 0.9 170,000 35 100 4" 65 100 5" PROPERTY OF 100 100 6" PATRIOT SUPPLY 100 100 7" Gas and oil heating appliances generate heat through the combustion of fuel. The heat is transferred through the heat exchanger and distributed to the conditioned space. The products of combustion, however, must be vented safely out of the structure. In a conventional chimney, venting is achieved by the natural lifting action of the hot combustion gas. New, efficient systems absorb more of the heat in the heat exchanger and produce lower temperature vent gas. Lower temperature gas does not rise as quickly or as reliably as in older, less efficient systems. Power venting or sidewall venting is more economical and safer than chimney venting. A power venter uses a motorized blower to vent the products of combustion. A power venter is interlocked with the appliance to ensure that proper draft is achieved before the appliance burner is activated. The SWG Power Venter is the safest, most efficient power venter available today. Patented SWG Power Venters are ETL and cETL listed for all LP gas, natural gas, or oil-fired heating equipment. The SWG combines the motor, blower, and vent hood in one complete, easy to install unit. The SWG mounts on the outside of the building and pulls the combustion gases from the appliance through the outside wall utilizing 100% negative pressure. Benefits of the SWG Power Venter include: • 100% negative pressure in the vent pipe for maximum safety. • Standard galvanized pipe can be used instead of expensive stainless steel. • No need to seal vent pipe joints, saving time and money. • Significantly longer vent lengths than positive pressure, direct vent systems. • The SWG is recommended by major heating appliance manufacturers. The SWG must be sized to match the appliance or appliances input firing rate. Most firing rates are published in the manufacturer’s installation manual. SWGs must be installed with a CK Control Kit to ensure proper listing and safe, efficient venting. (CONTROL KITS ARE NOT INCLUDED. MUST BE ORDERED SPEPERATELY) See Below for Control Kits REPLACES SWG-4, SWG4, For SWG Power Venter or DI Draft Inducer PDF Download CK-40 Series PVG or CAS Series for 24 Volt Gas Boiler (CK-40, 40F, 41, 41F, 42, 43F, 44, 44F, PVG, CAS-4Jr., CAS-6, and CAS-7) PDF CK-61 or CK-62 Oil Fired System Multiple PDF CK-40 Series for Multiple 24 volt Gas Boiler with Spark Ignition with or without stack damper (CK-40, 40F, 41, 41F, 43, 43F, 44, 44F) PDF CK-90 Series for 24 volt Gas Furnace and 30mV Gas Water Heater (Co-Venting) (CK-90, 91, 91F, 92F) PDF CK-40 Series, PVG, or CAS Series for 24 volt Gas Furnace (CK-40, 40F, 41, 41F, 43, 43F, 44, 44F) PDF CK-63 Wiring Aquastat Relay Check-Out PDF CK-63 Wiring Check-Out Sheet - Standard Set-up PDF CK-61,62,63 Riello Burner Application PDF CK-63 for an Oil Fired System with Electronic Primary (operates the venter motor and burner simultaneously) PDF CK-63 for an Oil Fired System with Primary Control (operates the venter motor and burner simultaneously) PDF CK-61 or 63 for Two Oil Fired Systems with Standard Primary Control PDF CK-62 for an Oil fired System with Standard Primary Control PDF CK-60 or 61 for an Oil Fired Warm Air Furnace with Electronic Primary Control and Isolation Relay PDF CK-63 MULTIPLE Oil Fired Systems with Standard Primary Controls PDF CK-63 SINGLE Oil Fired System with Standard Primary Control PDF CK-63 Wiring with a Honeywell ST9103 Control Board PDF CK-63 for an Oil Fired System with Honeywell (R8184, R7184), Carlin 60200-02, or Equivalent Primary Control PDF CK-61 or 63 for an Oil Fired Boiler, Furnace, or Water Heater (with standard primary control) PDF CK-20F AND CK-20FG Wiring for a 30mV Water Heater PDF CK-61,62,63 Oil Fired System Single Unit Wiring PDF CK-61,62,63 Oil Fired Warm Air Furnace with a Honeywell ST9103 Control Board PDF CK-63 Gas Furnace Application 24V PDF CK-63 Oil Fired System Simultaneous Burner Wiring PDF CK-41F CK-43F CK-91FV-FG 92FV-FG PDF PVO PDF PVG PDF CK-81 PDF CK-62 PDF CK-61 New Style PDF CK-61, 62, 63 Series with Honeywell R7184B and P and Carlin 60200-02 PDF CK-43 CK-91 and old style 61 PDF CK-40 Series or PVG for 24 Volt Gas Furnace PDF Payments We prefer PayPal and accept all major Credit Cards (Visa, MasterCard, American Express and Discover) as well as debit cards. We also accept Checks (must clear before the item(s) ship, and Wire Transfers Payment for all purchases is due within 5 business days from the date of purchase. For assistance with payment questions, quotes and volume discounts, contact our Customer Support at 866-321-HVAC during normal business hours. September 1st through March 31st (Winter Hours) Mon-Fri: 7:30am - 5pm and Sat: 8am - 12pm Sun: Closed April 1st through August 31st Mon-Fri: 7:30am - 4:30pm and Sat: Closed Sun: Closed Shipping Info We combine shipping on all of our items. If you are unsure how to do so, use the buy it now on all items desired. Then email us BEFORE payment and we will combine them for you. All orders are usually shipped the same business day if placed before 3pm EST. Shipment days are Monday through Friday. Next Day Air orders placed on Friday will arrive Monday (The next Business Day) Tracking information is sent to you automatically at the time of shipment and is always available if needed. All orders are inspected prior to shipment and are insured against loss or damage in transit. All international shipments are sent via USPS Priority Mail unless otherwise specified. All international shipments will have tracking numbers. International buyers are responsible for all duties and taxes on internationally shipped orders. Sorry but we do not send "gifts". The package will be insured for the full value of the item(s) being shipped All international transit times are estimates. There is no gaurantee. There are many variables including customs holding items. Returns Refunds and Returns Orders may only be cancelled if the items have NOT been shipped to you. An order is not considered cancelled until you receive an e-mail from us confirming your cancellation (if the order ships before this confirmation is received the customer is still responsible for original shipping and return shipping costs). Once an item has been shipped, it may only be returned for a refund or exchanged for another product. Goods returned must be new, in original undamaged packaging. Items MUST be in resalable condition and will be inspected Refunds and/or exchanges will be provided once the item has been received in its original condition. The refunded amount will be for the price of the item only. We are sorry but we do not refund the original shipping amount All returns require Return Authorization (RA) number. Please contact customer service for your RA number We cannot give refunds for items lost during return shipping. Please ship items via insured methods such as UPS, Fed-Ex or Priority Mail All returns are subject to a 15% restocking fee Electrical items are NOT returnable once they have been installed unless the item is a warranty in which case we will send a replacement. Customer Service Our Friendly and knowledgeable sales staff is always here to help you. If you have any questions or concerns don't hesitate to call. If you want expedited shipping, please inquire. We ship daily via UPS and USPS. Our Hours are: September 1st through March 31st (Winter Hours) Mon-Fri: 7:30am - 5pm and Sat: 8am - 12pm Sun: Closed April 1st through August 31st Mon-Fri: 7:30am - 4:30pm and Sat: Closed Sun: Closed Phone: 866-321-HVAC (Toll Free) Fax: 516-249-3108 e-mail: ebay@patriot-supply.com Web site: Patriot Supply Patriot Supply distributes products that require professional installation. All customers acknowledge that they are responsible to employ trained service professionals to service and repair heating, cooling refrigeration and ventilation appliances. Parts sold by Patriot Supply may call for special tools or procedures for safe operation of the appliances. Buyers hold Patriot Supply harmless for injury, property damage, or any other losses related with the use of parts and equipment purchased from Patriot Supply. Patriot Supply does not support the servicing of HVAC/R appliances by untrained or unqualified personnel. Patriot Supply offers the public to buy the necessary parts for use by trained licensed professionals. About Us Payment Shipping Terms Returns Patriot-Supply is located approximately 30 minutes from New York City in Plainview, New York. Our vast inventory encompasses all the areas of the HVAC/R market. We sell everything from residential and commercial controls, to draft controls and venting equipment, to hydronic and steam specialties. When shipping customers their parts we aim for speed and accuracy. With seven distribution centers located throughout the US order transit time to our customers is dramatically decreased. And, our integrated order system helps insure that the correct parts get to our customers as fast as possible. About Us Payment Shipping Terms Returns We prefer PayPal and accept all major Credit Cards (Visa, MasterCard, American Express and Discover) as well as debit cards. We also accept Checks (must clear before the item(s) ship, and Wire Transfers Payment for all purchases is due within 5 business days from the date of purchase. For assistance with payment questions, quotes and volume discounts, contact our Customer Support at 866-321-HVAC during normal business hours. About Us Payment Shipping Terms Returns We combine shipping on all of our items. If you are unsure how to do so, use the buy it now on all items desired. Then email us BEFORE payment and we will combine them for you. All orders are usually shipped the same business day if placed before 3pm EST. Shipment days are Monday through Friday. Next Day Air orders placed on Friday will arrive Monday (The next Business Day) Tracking information is sent to you automatically at the time of shipment and is always available if needed. All orders are inspected prior to shipment and are insured against loss or damage in transit. All international shipments are sent via USPS Priority Mail unless otherwise specified. All international shipments will have tracking numbers. International buyers are responsible for all duties and taxes on internationally shipped orders. Sorry but we do not send "gifts". The package will be insured for the full value of the item(s) being shipped All international transit times are estimates. There is no gaurantee. There are many variables including customs holding items. About Us Payment Shipping Terms Returns Our Friendly and knowledgeable sales staff is always here to help you. If you have any questions or concerns don't hesitate to call. If you want expedited shipping, please inquire. We ship daily via UPS and USPS. Our Hours are: September 1st through March 31st (Winter Hours) Mon-Fri: 7:30am - 5pm and Sat: 8am - 12pm Sun: Closed April 1st through August 31st Mon-Fri: 7:30am - 4:30pm and Sat: Closed Sun: Closed Phone: 866-321-HVAC (Toll Free) About Us Payment Shipping Terms Returns Refunds and Returns Orders may only be cancelled if the items have NOT been shipped to you. An order is not considered cancelled until you receive an e-mail from us confirming your cancellation (if the order ships before this confirmation is received the customer is still responsible for original shipping and return shipping costs). Once an item has been shipped, it may only be returned for a refund or exchanged for another product. Goods returned must be new, in original undamaged packaging. Items MUST be in resalable condition and will be inspected Refunds and/or exchanges will be provided once the item has been received in its original condition. The refunded amount will be for the price of the item only. We are sorry but we do not refund the original shipping amount All returns require Return Authorization (RA) number. Please contact customer service for your RA number We cannot give refunds for items lost during return shipping. Please ship items via insured methods such as UPS, Fed-Ex or Priority Mail All returns are subject to a 15% restocking fee Electrical items are NOT returnable once they have been installed unless the item is a warranty in which case we will send a replacement. You may also be interested in..... Template by Froo Froo Frooition www.froo.com | selling manager applications, eBay design, eBay store design, eBay shop design, eBay template design, eBay listing design Click Here. Double your traffic. Get Vendio Gallery - Now FREE!
