Field Controls Swg-5af S.s. Power Venter 5" 46544002

US $920

Woolrich, Pennsylvania, United States
Jun 17th

Open on mobile:
QR code

The SWG-AF series power vents are designed for sidewall venting of a single listed automatic feed Corn,Wood Pellet and other Bio-fuel burning heating appliances. Outdoor Mounted Power Venters Heating appliances generate heat through the combustion of fuel. The heat is transferred through the heat exchanger and distributed to the conditioned space. The products of combustion, however, must be vented safely out of the structure. In a conventional chimney, venting is achieved by the natural lifting action of the hot combustion gas. New, efficient systems absorb more of the heat in the heat exchanger and produce lower temperature vent gas. Lower temperature gas does not rise as quickly or as reliably as in older, less efficient systems. Power venting or sidewall venting is more economical and safer than chimney venting. A power venter uses a motorized blower to vent the products of combustion. A power venter is interlocked with the appliance to ensure that proper draft is achieved before the appliance burner is activated. The SWG or ComboVent™ Power Venter is the safest, most efficient power venter available today. Patented SWG or ComboVent Power Venters are ETL and cETL listed for all LP gas, natural gas, or oil-fired heating equipment. The SWG or ComboVent combines the motor, blower, and vent hood in one complete, easy to install unit. The SWG mounts on the outside of the building and pulls the combustion gases from the appliance through the outside wall utilizing 100% negative pressure. Benefits of the SWG or ComboVent Power Venter include: 100% negative pressure in the vent pipe for maximum safety. No need to seal vent pipe joints, saving time and money. Significantly longer vent lengths than positive pressure, direct vent systems. The SWG or ComboVent is recommended by major heating appliance manufacturers. The SWG or ComboVent must be sized to match the appliance or appliances’ input firing rate. Most firing rates are published in the manufacturer’s installation manual. 1. The power vent operates continuously while the heating appliance is in operation. After the mechanical draft vent motor has come up to speed, the pressure switch closes. This closes the circuit to the burner feed circuit and allows the burner to fire. 2. A barometric draft control is required to maintain the proper draft through the appliance. It also regulates the appliance venting under extreme changes in windy weather conditions. 3. A pressure sensing switch and blocked vent safety switch are wired into the burner feed circuit.If proper venting is not maintained, one or both switches will open and the burner feed circuit will de-activate. TYPICAL VENTING SYSTEM COMPONENTS 1 – SWG-AF or SWG-VR-AF Series Power Vent 1 – RC Draft Control (Required Accessory Not Included) 1 – WMO-1 blocked vent switch (Required Accessory Not Included) 1 – DIP-1 pressure switch (Required Accessory Not Included) RC Draft Control, WMO-1, and DIP-1 not included in this sale but are available seperately for purchase.
