Fire-lite Firelite Ms-10ud-7 Ten Zone Fire Alarm Replacement Board Only

US $199.99

Milwaukee, Wisconsin, United States
Aug 3rd

Open on mobile:
QR code

Fire-Lite Firelite MS-10UD-7 ten zone conventional fire alarm replacement board only Power supply and chasis not included I am selling as parts because I dont know the history of this board Shown powered up in the normal condition All 10 tested for alarm All 4 NACs and Remote Sync all activate upon fire alarm All plugs and EOLRs shown are included Firmware version 3.1 B2 Program and passwords all set to factory defaults Manufacturer date code is 12th week of 2015 MS-10UD MS-10UD-7 is a ten zone conventional fire control panel has features normally found in more expensive addressable systems. The MS-10UD-7 is fully programmable via built-in keypad and 80 character LCD display, so you do not need an external programmer. The ten zones panel has a built-in Digital Alarm Communicator Transmitter (DACT) and availability to add optional equipment: Remote annunciator, Relay module, LED Driver module, Transmitter module and Printer interface module. MS-10UD Features and Benefits Ten-zone Style B (Class B) or Five-zone Style D (Class A) with optional module Four NAC Circuits Style Y (Class B) or Four NAC Circuits Style Z (Class A) with optional modules Built-in NAC synchronization for System Sensor, Wheelock, Gentex, Faraday and Amseco devices Built in programmer: Integral 80 character LCD display with backlighting and keypad Annunciator bus supports up to 8 devices, including ANN-80 LCD Remote Annunciator, ANN-S/PG remote serial or parallel printer gateway, ANN-RLY, 10 form C relay board, ANN-LED Zone annunciator and ANN-I/O LED driver board for graphic annunciators Built-in two-line digital communicator for off premises monitoring Three Form-C programmable relays 7.0 amps total usable current. These control panels provide reliable fire signaling protection for small to medium-sized commercial, industrial, and institutional build- ings. Both panels include built-in communicators for Central Station Service and remote upload/download. Each of these FACPs is compatible with System Sensor’s microprocessor-based i3 series detectors. These conventional smoke detectors can transmit a maintenance trouble signal to the FACP indicating the need for cleaning and a supervisory “freeze” signal when the ambient temperature falls below the detector rating. Additionally, both the MS-5UD-3 and MS- 10UD-7 are compatible with conventional input devices such as two- and four-wire smoke detectors, pull stations, waterflow devices, tamper switches, and other normally-open contact devices. Refer to the Fire•Lite Device Compatibility Document for a complete listing of compatible devices. Outputs include four NACs (Notification Appliance Circuits), three programmable Form-C relays (factory programmed for Alarm, Trouble, and Supervisory) and 24 VDC special applica- tion resettable and nonresettable power outputs. The FACPs supervise all wiring, AC voltage, battery level and telephone line integrity. Activation of a compatible smoke detector or any normally- open fire alarm initiating device will activate audible and visual signaling devices, illuminate an indicating LED, sound the piezo sounder at the FACP, activate the communicator and FACP alarm relay, and operate an optional module used to notify a remote station or initiate an auxiliary control function. New options include a UL listed printer, PRN-6F and FireLite’s IPDACT Internet Monitoring module. The FireWatch Series internet monitoring modules IPDACT-2 and IPDACT-2UD per- mit monitoring of alarm signals over the Internet saving the monthly cost of two telephone lines. Although not required, the secondary telephone line may be retained providing backup communication over the public switched telephone line. NOTE: The MS-5UD-3E and MS-10UD-7E offers the same fea- tures as the MS-5UD-3 and MS-10UD-7 but allow connection to 240 VAC. Unless otherwise specified, the information in this data sheet applies to both the 120 VAC and the 240 VAC versions of these panels. NOTE: For ULC-listed models, see DF-60440. Features • Listed to UL Standard 864, 9th edition. • Built-in DACT (Digital Alarm Communicator/Transmitter). • Style B (Class B) IDC (Initiating Device Circuit) – MS-5UD-3 - five IDCs. – MS-10UD-7 - ten IDCs. • Style Y (Class B) NAC (Notification Appliance Circuit) - spe- cial application power – MS-5UD-3 - four NACs. – MS-10UD-7 - four NACs. • Notification Appliances may be programmed as – Silence Inhibit. – Auto-Silence.

Condition:	For parts or not working: An item that does not function as intended and is not fully operational. This includes items that are defective in ways that render them difficult to use, items that require service or repair, or items missing essential components. See the seller's listing for full details. ...	Brand	Fire-Lite
Model	MS-10UD-7
Type	Fire Alarms
MPN	MS10UD7
UPC	Does not apply
