Fireye Ultra Violet Scanner 45uv3-1050 45uv31050 3/4" Sleeve/set Screw

US $820

Boiling Springs, South Carolina, United States
Jun 6th

Open on mobile:
QR code

FIREYE UV-EYE PHOTOEYE SENSOR 45UV3 10509102 FIREYE PHOTOEYE SENSOR 45UV3 CATALOG # 10509102 3/4" SLEEVE/SET SCREW MOUNT It has been moved in a metal tool box awhile and moved from one storage spot to another for years. it looks like its used ? from scratches and dents >so I checked it . It passes all test ready for work. The 45UV3, Scanner is used with the M-Series, M-Series II, MicroM, FlameWorx, MB-2 and D-Series controls as well as the Fireye FLAME-MONITORTM, BurnerLogix and Nexus System. The 45UV3 Scanner has a rugged cast housing that mounts on a 3/4 inch pipe with sleeve and setscrew. The replaceable UV tube is mounted in a vertical position for greater sensitivity. Non selfchecking. (90°) mounting which, in some applications allow the scanners to obtain a clearer view of the flame. eliminates the need for a threaded sight pipe. The UV tube is made of quartz and is filled with a gas that ionizes when struck by UV radiation from the flame. In the absence of UV radiation, the gas acts as an insulator between two electrodes which are mounted inside the tube. These electrodes are energized continuously by a high voltage. During combustion, UV radiation ionizes the gas, causing current pulses to flow between the electrodes. These current pulses result in a flame signal which is transmitted to the amplifier in the control, where it is processed to energize or hold in the flame relay. online manual at (fireye.com/Documents/SC-102.pdf) APPLICATION UV scanners are recommended for detecting flames from standard fuel gases, some waste gases and light oil fuels such as No. 2 oil. Flames from heavier oils can be detected with UV scanners but the unburned fuel shroud and/or atomization shroud can block passage of the UV from the flame zone to the UV tube, causing nuisance burner/boiler trips. Infrared detection is recommended for fuel oil heavier than No. 2, and some installations where waste gases are burned together with natural gas as a main flame. SPECIFICATIONS FIREYE ULTRA VIOLET SCANNER 45UV3-1050 45UV31050 3/4" SLEEVE/SET SCREW mount, unshielded leads Operating Voltage: (S1-S2): 560 VAC @120V (230V) 50/60 Hz applied Operating Temperature Limits: Maximum: 200? F (94? C) Minimum: -40? F (-40? C) Humidity: 85% RH maximum non-condensing Country of Manufacture: United States Payment from PayPal with confirmed address only.Items Will be Shipped by USPS Ground on the Same or Next Business day of receiving full payment USPS Tracking Number will be provided with confirmation. The Item Description is to be used to determine what you are bidding on along with pictures Check out my other items.
