Fischer & Porter 71k1025a Impact Flow Meter 821a004u88

US $190

Chicago, Illinois, United States
Jun 10th

Open on mobile:
QR code

Store Policies - Payment | Returns | Shipping | Contact Us | About Us Visit our Store Check out my other items! Fischer and Porter Impact Tube Flow Indicator Meter Manufacturer: Fischer & Porter ( a.k.a. Bailey Controls ) Part Number: 821A004U88 / A1033A1 / 10F1033A SERIES 71K1025A This flowmeter is unique - a combination of impact tube and direct reading rotameter. It has only a single line connection, and it reads only when the READ button is pushed, not continuously. Its metal impact tube is installed in the main stream. There it picks up a portion of the fluid and directs it in to the bottom of the meter. When the READ knob is pushed, fluid is allowed to flow in and up the tapered center tube and past the ball float. float position indicates flow rate on a direct reading scale. From the top of the tapered tube, fluid returns to the main stream by flowing down through a larger glass tube that surrounds the metering tube, and then through a line that parallels the impact tube. Designed and calibrated for metering water flow. Brass end fittings, impact tube, mounting connection. Body: extruded aluminum( Not wetted by process fluid) Specifications Pressure limit:175 PSI 1/2" NPT Weld Bushing Mount. Each tube has four 5" long direct reading tubes and scales. Meter Tube: 10" Pipe 1.0-3.0 x1000 GPM Liquid 12" Pipe 1.0-4.0 x1000 GPM Liquid 14" Pipe 1.0-5.0 x1000 GPM Liquid 16" Pipe 1.0-7.0 x1000 GPM Liquid More of the same p/n in stock , contact us Not the item your looking for?? Click here to Search our Store for other Fischer & Porter we sell!! New -Unused Listing #6222 or contact DYMATIC, INC. Our 30th Year 5328 N. Northwest Hwy. Chicago, IL 60630-1137 USA TEL: 773-763-2100 FAX: 773-763-6877 Excess & Surplus Inventories from FLUID POWER DISTRIBUTORS and the OEM Industry. Inventory of 1,000,000 NEW components and parts for Immediate Delivery. Serving FOR 30 YEARS: THE FLUID POWER INDUSTRY, THE OEM MARKET, THE WHOLESALE AND DISTRIBUTION MARKET. Please ask all your questions before buying or bidding. RETURNS NOT ALLOWED ON THIS ITEM KNOW WHAT YOU BUY , BUY WHAT YOU KNOW . *Dymatic, Inc. is not an authorized distributor of any products listed. More in stock , contact seller for price and delivery. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
