Fixturlaser Pat Belt Alignment Tool Detector Laser Unit W/ Case And Accessories

US $94

Palm Harbor, Florida, United States
May 27th

Open on mobile:
QR code

BELT DRIVE ALIGNMENT Fixturlaser PAT - the final solution to all your belt alignment needs! With the Fixturlaser PAT, you are never in doubt on whether your belt transmissions are aligned or not. By using the groove as reference, you will achieve a precise alignment which reduces belt wear, bearing failures and vibrations. Two transmitters with visible red laser line The Fixturlaser PAT comes with two line laser transmitters, each equipped with two spring loaded guides which fit into the pulley grooves. The use of two laser transmitters with integrated targets makes it very easy to find out what kind of alignment that is required. Parallel offset, angular error and twist is instantly visible to the operator. Within a few minutes the operator can determine if the machine requires alignment or not. Mounting of the transmitters The Fixturlaser PAT units are very easily mounted on the pulleys. The spring action probe finds the center of the belt groove. The industrial built-in magnets snap the units to the pulley in a perfect fit. The Fixturlaser PAT is equipped with various sized removable guides to fit standard sheave sizes A-E (6 mm - 40 mm). The alignment process with the Fixturlaser PAT The visible red laser line makes it easy to determine the position of your belt driven machines. The alignment process is as easy as the mounting. Just turn on the lasers and look at the opposite mounted unit. The laser draws a line on the target label as in the illustration to the left. If necessary, adjust your machine position until the laser lines are aligned with the centre mark on both units. Fixturlaser PAT - COMPLETE SYSTEM Weight (incl. all standard parts): 1,5 kg (3,3 lbs) Storage Temperature: -20 to 70°C (-4 to 158°F) Case Material: High Impact ABS Plastic Sealing: Dust, water (5m/16 feet), and air tight with air pressure compensation valve Drop Test: 3 m (10 feet) on to concrete floor Dimensions: 250 x 180 x 80 mm (9,84 x 7,09 x 3,15 inch) Measuring units Housing Material: Extruded aluminum (molded PA cover) Operating Temp: 0 to 40°C (32 to 104°F) Relative Humidity: 10 – 90% Weight: 340 g (12 oz) Dimensions: 61 x 77 x 61 mm (2,4 x 3 x 2,4 in) Environmental Protection: IP 65 Laser: 630 - 675 nm class II diode laser Laser Line Fan Angle: 90° Laser Power: < 1 mW Measurement Distance: 50 mm - 6000 mm (1,97 - 236,22 in) Measurement Accuracy: Better than 0,5 m (0,02 in) or 0,2 degrees Pulley Diameter Range: From 75 mm (2,95 in) and larger (standard) Pulley Belt Groove Width: 6 mm - 40 mm (0,23 - 1,57 in) (standard) Power Supply: 2 pcs of LR03 (AAA)1,5 V per unit Operating time: 20 hours of continuous operation On Mar-09-16 at 10:04:42 PST, seller added the following information:
