Flint & Walling CJ103203 Booster Pump 2 HP 3-Phase 208-230/460V, US $170.00 – Picture 0

Flint & Walling CJ103203 Booster Pump 2 HP 3-Phase 208-230/460V, US $170.00 – Picture 1

Flint & Walling Cj103203 Booster Pump 2 Hp 3-phase 208-230/460v

US $170.00

Loves Park, Illinois, United States
Jan 30th

Open on mobile:
QR code

I am offering a Flint & Walling CJ103203 Booster Pump 2 HP 3-Phase 208-230/460V. The Item is listed as new other because the mounting bracket is bent due to freight ( see pictures ), the original box may be in good to fair condition. What you see in the picture is exactly what will arrive at your door. Thanks for Looking. Your Satisfaction is Guaranteed. Specs Include: ItemBooster Pump Motor EnclosureODP Housing MaterialCast Iron HP2 Phase3 Voltage208-230/460 Amps7.4/3.7 Hz60/50 Inlet (In.)1-1/2 FNPT Outlet (In.)1-1/4 FNPT GPM @ 25 PSI96 GPM @ 30 PSI86 GPM @ 35 PSI75 GPM @ 40 PSI61 GPM @ 50 PSI43 Max. Pressure (PSI)45 Suction Lift (Ft.)25 Max. Case Pressure (PSI)100 Best Efficiency GPM @ Head (Ft.)56 @ 92 Best Efficiency Range GPM @ Head (Ft.)66-44 GPM @ 82-102 Ft Motor RPM3450/2875 Motor TypeODP DutyContinuous Wetted MaterialsBrass,CI,416 SS,Buna N,Carbon,Silicon Carbide,BR Impeller MaterialBrass Impeller TypeClosed Diffuser MaterialCast Iron Seal MaterialStainless Steel, Buna N and Carbon/Silicon Carbide Seal TypeMechanical Shaft MaterialStainless Steel Seal ApplicationWater Bearing TypeBall Max. Liquid Temp. (F)200 Degrees Min. Inlet Flow Required2 GPM Max. Inlet Pressure (PSI)56 Stages1 Max. Fluid ViscosityClear Water Plug or Connector TypeDirect Wire Length (In.)15-5/8 Width (In.)8-1/4 Height (In.)3-5/16 Motor Ambient Temp. Rating65 Degrees C/149 Degrees F Service Factor1.25 Max. Working Pressure (PSI)44 NEMA/IEC FrameNEMA 56J For Use WithNonflammable Liquids Compatible with Pump Component Materials ApplicationWater Circulation Booster Service Water Transfer Agency ComplianceCSA, CUS, UL Listed Includes1/4" Drain Plug, Discharge Rotates In 90 Degree Increments

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	FLINT & WALLING
Stages	1
ManufacturerPartNumber	CJ103203
GPM @ 35 PSI	75
Hz	60/50
GPM @ 25 PSI	96
Max. Liquid Temp. (F)	200 Degrees
Seal Application	Water
Plug or Connector Type	Direct Wire
Motor Ambient Temp. Rating	65 Degrees C/149 Degrees F
Max. Case Pressure (PSI)	100
Max. Working Pressure (PSI)	44
Amps	7.4/3.7
Location	B-1
Motor Enclosure	ODP
