Flo-tech F6557-15 Signal Wiring

US $180

  • Cleveland, Ohio, United States
  • Jun 14th
Cable is 15 ft. long. By doing a Google search for "Flo-tech F6557-15", you may find a PDF detailing the complete installation instructions for this cable. 0-5 Volt Output The F6557 cable is a five pin, three wire cable used to connect the IFC sensors to the F6700 series displays. Only two of the three wires in the cable are used. 1) Connect the RED wire of the F6557 cable to terminal 6 (+24 V EXC) on the F6700 series display (See Figure 4). 2) Connect the BLACK wire of the F6557 cable to terminal 3 (10 V) on the F6700 series display. 3) Connect the WHITE wire of the F6557 cable to terminal 5 (COMM) on the F6700 series display.
