Flowline Lu27-01 Ultrasonic Level Sensor/transmitter

US $450.00

Coatesville, Pennsylvania, United States
Jul 31st

Open on mobile:
QR code

Flowline Lu23-01 Ultrasonic Level Sensor/Transmitter. Condition is "New". Shipped with USPS Priority Mail.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Enclosure Rating	Type 6P
Temp. Range	-4 to 140 Degrees F
Restricted States	[]
Battery Included	No
Power Source	N/A
Bundle Description	No
Custom Bundle	No
Color	N/A
MPN	LU23-01
Overall Length	4.1"
Battery Size	N/A
Material	PVDF
Item Length	7.300
Input Voltage	24 VDC (loop)
Depth	6.600
Range	18 ft.
Item	Noncontact Ultrasonic Level Sensor
Weight	1.8
Accuracy	+/- 0.2% of Range
Max. Pressure	30 psi
Number of Batteries	N/A
Battery Life	N/A
Brand	FLOWLINE
Item Height	5.300
Mounting	2" NPT
Output	4 to 20mA, 2-wire
Type	Noncontact Ultrasonic Level Sensor
Motor Type	N/A
Battery Capacity	N/A
Style	Noncontact Ultrasonic Level Sensor
NumberOfItems	1
Enclosure Material	Polycarbonate
Length	7.300
Cable Length	N/A
Coil Voltage	N/A
Height	3.4"
Gasket Material	Viton
Features	Ultrasonic Level Transmitter, Level Measurement, Classification General Purpose, Range 18.0', Accuracy +/- 0.2 Percent of Range, Resolution 0.039 In., Dead Band 8 In., Beam Width 3 In., Configuration WebCal, Input Voltage 24 VDC (loop), Output 4-20 mA, 2-wire, Temp. Range -4 to 140 Degrees F, Max. Pressure 30 psi, Enclosure Rating Type 6P, Enclosure Material Polycarbonate, PVDF, Gasket Material Viton, Mounting 2 In. NPT, Display None, Standards cFMus, CE, RoHS, Length 4.1 In., Width 4.0 In.
Country/Region of Manufacture	US
Width	6.600
Resolution	0.039"
Item Width	6.600
Display	None
UPC	634746301253
