Flowline Lv55-s001-36 Floatek Ultrasonic Float Level Transmitter, 36" Length

US $499.95

  • San Ramon, California, United States
  • Jul 17th
NEW Flowline, LV55-S001-36, FloaTek 36" Stainless Steel Float Level Transmitter ABSOLUTELY BRAND NEW! The general purpose float level transmitter provides continuous level measurement up to 6.5' with a 4-20 milliampere signal output, and is factory configured to your selected dimension. This stainless steel liquid level sensor is well suited for high temperature or pressure tank level applications with relatively clean liquids such as water, diluted chemicals and light weight oils. Application examples include boilers and process vessels. Use in applications with foam or turbulence. Loop powered output will interface directly with PLC/SCADA or local display. Range: 12" to 6.5'. Accuracy: 0.25 percent span in water. Configuration: none, fixed span. Orientation: +/- 20 degree from vertical. Specific gravity: 0.55 minimum. Supply voltage: 10 to 30 VDC. Loop resistance: 600 Ohms at 24 VDC. Signal output: 4-20 milliampere, two-wire. Process temprature: -40 to 185 degreeF. Ambient temprature: -40 to 140 degree. Pressure: 200 psi. Enclosure rating: NEMA 4X (IP65). Enclosure material: polypropylene, UL94VO. Conduit entrance: Single, 1/2" NPT. Process mount: 2" NPT. Guide-float material: 316 stainless steel. Classification: general purpose. Compliance: CE. 36" Length. Key Features: High pressure or temperature level measurement up to 6.5' Rugged 316 stainless steel float guide and process mounting plug Assembled to your guide length and measurement span dimensions Polypropylene junction box rated NEMA 4X with conduit port and terminal strip Great for high pressure applications up to 200 psi Transmitter Length 36" (91cm) Range 12" to 6.5' (30cm to 2m) Accuracy 0.25% span in water Configuration None, fixed span Orientation ± 20° from vertical Specific gravity 0.55 minimum Supply voltage 10 to 30 VDC Loop resist. 600 Ohms @ 24 VDC Signal output 4-20 mA, two-wire Process temp. F: -40° to 185° C: -40° to 85° Ambient temp. F: -40° to 140° C: -40° to 60° Pressure 200 psi (13.8 bar) Enclosure rating NEMA 4X (IP65) Enclosure mat. PP, UL94VO Conduit entrance Single, 1/2" NPT Process mount 2" NPT Guide-float mat 316 SS Classification General purpose Compliance CE     Shipping Details: Item will be mailed out the next business day after payment is received. Combined shipping is available. Please inquire before bidding. Please note that you are responsible for insurance if you want your item covered in case of loss or damage.     International Bidders: International shipping is generally available. There will be a small flat-fee depending on the value of the item, in addition to the actual shipping cost. International bidders should be PayPal verified, shipping to a confirmed address, and have good feedback.     Payment Details: Paypal
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Model LV55-S001-36
Brand Flowline
MPN LV55-S001-36
UPC 634746301697
