Fluid Passage Bolt 6-66646-2, 3/8" Threaded, NSN 4730003404143, Appears Unused, US $34 – Picture 0
Fluid Passage Bolt 6-66646-2, 3/8" Threaded, NSN 4730003404143, Appears Unused, US $34 – Picture 0

Fluid Passage Bolt 6-66646-2, 3/8" Threaded, Nsn 4730003404143, Appears Unused

US $34

  • Hurricane, Utah, United States
  • Nov 3rd
Open on mobile:
QR code
Fluid Passage Bolt 6-66646-2 3/8" Threaded NSN 4730003404143 Appears Unused Government Specs Below: BBDF  WRENCHING FEATURE STYLE  HEXAGON  BBLF  WRENCHING FEATURE HEIGHT  0.064 INCHES NOMINAL  ASDB  WIDTH ACROSS FLATS  0.552 INCHES MINIMUM AND 0.564 INCHES MAXIMUM  MDCL  MATERIAL DOCUMENT AND CLASSIFICATION  MIL-S-5626 MIL SPEC 1ST MATERIAL RESPONSE OR MIL-S-6049 MIL SPEC 2ND MATERIAL RESPONSE  BBKR  LENGTH FROM BEARING SURFACE OF WRENCHING FEATURE TO END OF FIRST DIAMETER  1.230 INCHES MINIMUM AND 1.270 INCHES MAXIMUM  BBLD  LENGTH FROM BEARING SURFACE OF WRENCHING FEATURE TO BOLT END  1.590 INCHES MINIMUM AND 1.640 INCHES MAXIMUM  MATT  III MATERIAL  STEEL COMP 4140 OR STEEL COMP 8740  ABHP  OVERALL LENGTH  1.670 INCHES NOMINAL  CQFM  HARDNESS RATING  36.0 ROCKWELL C MINIMUM AND 39.0 ROCKWELL C MAXIMUM  BBKY  FIRST RADIAL FLUID HOLE DIAMETER  0.070 INCHES MINIMUM AND 0.072 INCHES MAXIMUM  CQKK  FIRST END THREAD QUANTITY PER INCH  24  CQMM  FIRST END THREAD SERIES DESIGNATOR  UNF  ATKZ  FIRST END THREAD LENGTH  0.298 INCHES NOMINAL  ACLL  FIRST END THREAD DIRECTION  RIGHT-HAND  ACLK  FIRST END THREAD CLASS  3A  CQYM  FIRST END NOMINAL THREAD SIZE  0.375 INCHES  BBKL  FIRST DIAMETER FROM WRENCHING FEATURE  0.373 INCHES MINIMUM AND 0.374 INCHES MAXIMUM  AAXC  CONCENTRIC HOLE DIAMETER  0.118 INCHES MINIMUM AND 0.122 INCHES MAXIMUM  AAWX  CONCENTRIC HOLE DEPTH  1.470 INCHES MINIMUM AND 1.530 INCHES MAXIMUM  AAQL  BODY STYLE  PLAIN  BBLB  DISTANCE FROM FIRST RADIAL HOLE CENTER TO END OF BOLT  1.360 INCHES NOMINAL Subject to prior sale! Photos show everything that is included. For more information, please feel free to visit our ME page. Handling fee may apply to items requiring additional packing time or materials. 30 day right of return if not satisfied. Thanks for looking!!! Please visit our store for more great items! 10456 3A-19
