Fluke 125/s Scopemeter® Oscilloscopes With Scc120 Kit

US $2,699.00

Greensboro, North Carolina, United States
Jun 9th

Open on mobile:
QR code

Specifications Oscilloscope bandwidth 40 MHz Dual input true RMS meter VDC, VAC, VAC + VDC, Ohms,Continuity, Diode-test Current, °C, °F, Capacitance, dBV, dBM, Crest Factor, Touch Hold and Zeroset TrendPlot recording Automatic vertical scaling and time compression Display the actual, MIN, MAX and AVG reading Cursors Fluke 125/124: ?T, 1/?T, V, ?V, rise- and fall time Sample rate 2.5 GS/s repetitive sampling 25 MS/s single shot sampling Inputs and digitizers 2 Timebase range 20 ns - 1 min/div Input sensitivity 5 mV - 500 V/div Trigger types Connect-and-View™, Free Run, Single Shot, Edge, Video, External Glitch capture 40 ns Scope measurements Automatic measurements: 26 (all instruments) On top, Fluke 125 has additional measurement functions for Power (W), VA, VAR and Power Factor (PF) for single phase and balanced-three-phase (delta) power systems Harmonics mode Capability to analyze the harmonics contents of power signals (see Harmonics Mode Section below for details) Maximum record length 512 min/max pts per input Memory 20 screens and setups Additional Power Measurement Capabilities Measurement Types Watt, VA VAR, Power Factor (PF) Power Configuration Single phase or balanced three-phase (delta-configuration) mains supply Voltage Measurement Channel A; using STL120, voltage probe or direct input Current Measurement Channel B, using i400s (included) or other compatible current clamp Current clamp or shunt sensitivity 0.1 / 1 / 10 / 100 / 1000 mV/A, 10 mV/mA and 400 mV/A Harmonics mode Converts waveform information into a harmonics display (using FFT processing) which shows the relative amplitudes of the 1st up to the 33rd harmonic Analyzed waveform Voltage waveform(Ch.A), Current wavefrom (Ch.B) or Power (Ch.A x Ch.B), automatically generated Harmonics frequency range DC up to 33rd harmonic (for fundamental up to 60 Hz); DC up to 24th harmonic (for fundamental up to 400 Hz) Display Bargraph showing 1st up to 33rd harmonic and DC; amplitude displayed in % relative to fundamental Measurements Relative amplitude of individual harmonics; THD in %r or %f Bus Health Test Functions Bus health test Verifies the electrical parameters of industrial bus systems using automatic measurement and analysis functions. Next to that, an Eyepattern mode is provided for visual inspection of signal quality. Parameter classification Default values:well within limits = 'good' within certain percentage of the limit values = 'weak' beyond limit values = 'bad' Limits values, as a default, are based on industry standard for the selected bus type or may be set by the user. Bus systems supported AS-i (EN50295, 166 kb/s); CAN-bus (ISO-11898, up to 1 Mb/s); Interbus S (EIA-485, 500 kb/s); ControlNet (61158 type 2, 5Mb/s); Modbus (EIA-232 up to 115 kb/s and EIA-485 up to 10 Mb/s); Foundation Fieldbus H1 (61158 type 1, 31.25 kb/s); Profibus DP (EIA-485 up to 10 Mb/s); Profibus PA (61158 type 1, 31.25 kb/s); Ethernet 10Base2 (coaxial); Ethernet 10BaseT (UTP, 10 Mb/s); RS-232 (EIA-232, up to 115 kb/s); RS-485 (EIA-485, up to 10 Mb/s); User defined single wire or balanced system Modes Waveform Parameter Analysis With Automatic Read-out And Parameter:validation (good / weak / bad); test limits are based on industry standards or may be set by the user Eyepattern display mode Measured parameters (where applicable) Baud rate, Risetime, Fall time, High level, Low level, Bias voltage level, Signal amplitude, Distortion, Jitter Eyepattern display mode Gives waveform display of bus signals with display persistence Timebase and attenuator settings may be altered by the user Environmental Specifications Operating temperature 0°C to 50°C Storage temperature -20°C to +60°C Operating Altitude 3,000 m Safety Specifications Electrical safety 600 V CAT III (EN61010-1) Mechanical And General Specifications Size 232 x 115 x 50 mm Weight 1.2 kg Warranty 3-years on main instrument 1-year on accessories Battery life 7 hrs using NiMH RS232/USB unterface Optically isolated via optional PM9080 or OC4USB for interfacing to Printer or PC

“NEW HAS BEEN REMOVED FROM SHIPPING PACKING TO INCLUDE CARRYING CASE AND THE SCC 120 KIT--VERY NICE PRICED TO SELL.ADDITIONAL ACCESSORIES AND SOFTWARE INCLUDED.”

Brand	FLUKE
Model	125
