Fluke 1587 Mdt Insulation Multimer I400 Clamp 9040 Phase Rotation Indicator

US $799.00

Excelsior Springs, Missouri, United States
Jan 29th

Open on mobile:
QR code

Fluke 1587/MDT Advanced Motor Drive Troubleshooting Kit. This kit is in perfect working condition. No signs of wear or use. Kit Including; -Fluke 1587 Insulation Multimeter -Fluke i400 AC Current Clamp -Fluke 9040 Phase Rotation Indicator Including all manual, CD & accessories as shown in pictures. Actual items are shown in pictures. All items are free from personal marking & S/N are still on them. Fluke 1587/MDT Advanced Motor & Drive Troubleshooting Kit The products in this kit have been specifically selected for both troubleshooting and preventative maintenance applications. Establishing preventative maintenance programs are becoming critical to maintaining the uptime of electrical equipment and can significantly reduce both planned and unplanned downtime. Unplanned downtime costs are difficult to calculate, but often significant. For some industries, it can represent 1 % - 3 % of revenue (potentially 30 % - 40 % of profits) annually. FLUKE 1587 INSULATION MULTIMETER The Fluke 1587 Insulation Multimeter combine a digital insulation tester with a full-featured, true RMS digital multimeter in a single, compact, handheld unit, which provides maximum versatility for both troubleshooting and preventative maintenance. Whether you work on motors, generators, cables, or switch gear, the Fluke 1587 Insulation Multimeter is ideally suited to help you with your tasks and at a cost that is far less than buying the two products. Specifications Voltage DC Maximum Voltage: 1000 V Accuracy: 1577: ±(0.2%+2) 1587: ±(0.09%+2) Maximum Resolution: 0.001V Voltage AC Maximum Voltage: 1000 V Accuracy: 1577: ±(2%+3) 1587: ±(2%+3) AC Bandwidth: 1587: 5kHz* *with low pass filter; 3db @ 800 Hz Maximum Resolution: 0.1 mV Current DC Maximum Amps: 400mA Amps Accuracy: 1577: ±(1.0%+2) 1587: ±(0.2%+2) Maximum Resolution: 0.01 mA Current AC Maximum Amps: 400mA Amps Accuracy: 1577: ±(2.0%+2)* 1587: ±(1.5%+2)* * 1kHz bandwidth Maximum Resolution: 0.01 mA Resistance Maximum Resistance: 50 M? Accuracy: 1577: ±(1.2%+2) 1587: ±(0.9%+2) Maximum Resolution: 0.1? Capacitance(1587 only) Maximum Capacitance: 9,999 µF Accuracy: ±(1.2%+2) Maximum Resolution: 1 nF Frequency (1587 only) Maximum Frequency: 100 kHz Accuracy: ±(0.1%+1) Maximum Resolution: 0.01 Hz Temperature Measurement (1587 only) -40.0 °C to 537 °C -40.0 °F to 998 °F excluding probe Diode Test (1587 only) Range: 6 V Resolution: 1 mV Accuracy: ±(2 % + 1) Insulation Test Minimum Test Current @ 1k?/V: 1mA Test Voltages: 1577: 500, 1000 V 1587: 50, 100, 250, 500, 1000 V Maximum Resistance per Test Voltage: 50V: 100V: 250V: 500V: 1000V: 1577: 600 M? 1587: 2 G? Maximum Resolution per Test Voltage: 50V: 0.01 M? 100V: 0.01 M? 250V: 0.1 M? 500V: 0.1 M? 1000V: 0.1 M? Accuracy per Test Voltage: 50V: ±(3 % + 5) 100V: ±(3 % + 5) 250V: ±(1.5 % + 5) 500V: 1577: ± 1587: ±(1.5 % + 5) 1587: ±(1.5 % + 5) to 600 M?, ±(10 % + 3) above 600 M? Environmental Specifications Operating temperature –20 °C to +55 °C Storage temperature -40°C to +60°C Humidity (Without Condensation) 0% - 95% (10 °C – 30 °C) 0% - 75% (30 °C – 40 °C) 0% - 40% (40 °C – 55 °C) Operating Altitude 2000 m Safety Specifications Overvoltage category Complies with ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA-C22.2 NO. 61010-1-04, and IEC/EN 61010-1 2nd Edition for measurement CAT III 1000 V and CAT IV 600 V Agency Approvals 2000 m CAT III 1000 V, CAT IV 600 V; 3000 m CAT II 1000 V, CAT III 600 V Mechanical & General Specifications Size 203 x 100 x 50 mm (with holster) Weight 624 g Battery life Alkaline Meter use: 1000 hours Insulation test use: Meter can perform at least 1000 insulation tests with fresh alkaline batteries at room temperature. These are standard tests of 1000 V into 1 M? with a duty cycle of 5 seconds on and 25 seconds off. IP Rating IP40 FLUKE i400 AC CURRENT CLAMP CAT IV AC current clamp for DMM's Fluke Current clamps are the ideal tools to extend the functionality of Fluke tools. The i400 is a single range 400 A ac current clamp with current output via safety shrouded banana plugs. The clamp is compatible with most Fluke multimeters or any other current measurement device that accepts 4mm-shrouded banana plugs and has an AC milliamp range. The division ratio is 1000:1. Companion to your DMM to measure up to 400 A AC 1mA/Amp output guarantees easy reading on you meter Only current clamp available with a CAT IV 600 V / CAT III 1000 V safety rating Specially designed to offer maximum utility in a very compact shape Take accurate current readings without breaking the circuit Soft non-slippery overmold handle prevents from accidental touching live wiring Max. conductor ? 32 mm Specifications Nominal current range 400A Continuous current range 1 A - 400 A Maximum Non-Destructive Current 1000 A Lowest measurable current 1 A Basic accuracy 2% + 0.06 A (45-400 Hz) (% reading + floorspec) Useable frequency 5 Hz - 20 kHz Output level(s) 1 mA/A Safety Specifications Safety CAT IV 600 V, CAT III, 1000 V Maximum voltage 1000 V AC rms from earth to ground, in compliance with EN61010 Mechanical & General Specifications 1 year Maximum conductor diameter 32 mm (1.25 inches) Maximum conductor size (busbar) 750 MCM Output cable length 1.5 m (59 inches) Shrouded banana plugs Yes FLUKE 9040 PHASE ROTATION INDICATOR Phase rotation indicator with high voltage capability for industrial applications The Fluke 9040 is effective for measuring phase rotation in all areas where three phase supplies are used to feed motors, drives and electrical systems. The Fluke 9040 is a rotary field indicator and can provide clear indication of the 3 phase via an LCD display and the phase rotation direction to determine correct connections. It allows rapid determination of phase sequence and has a voltage (up to 700 V) and frequency range suitable for commercial and industrial applications. The included test probes have a variable clamping range for safe contact, also in industrial sockets. Technical Specifications Voltage range 40-700 V Frequency range 15-400 Hz Operating timer Continuous Environmental Specifications Operating temperature 0 °C to 40 °C Dust/water resistance IP 40 Safety Specifications Electrical Safety EN 61010, EN 61557-7 Overvoltage category CAT III, 600 V CAT IV, 300V Mechanical & General Specifications Size 124 x 61 x 27 mm Weight 200 g Power supply From unit under test

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Fluke
Model	1587/MDT
