Fluke 43b/003 Single Phase Power Quality Analyzer With Flukeview & Cable mint

US $1,499.00

Chino Hills, California, United States
Feb 13th

Open on mobile:
QR code

Fluke 43B/003 Single Phase Power Quality Analyzer SLIGHTLY & GENTLY USED IN MINT CONDITION! MSRP Over $3,000.00 Including FlukeView Software SW43W V3.34 for Window & Fluke USB Interface Cable P/N OC4USB. Including user manual booklet & CD. Including Fluke accessories as shown in pictures only. Items are free from owner marking. Actual items are showing in pictures & included. S/N Sticker on Fluke 43B came loose and missing. Please review my 100% positive feedback from other Fluke buyers and purchase with confidence. Item will be shipped via FedEx ground with insurance on next business day after payment receive (PayPal only). Fluke 43B Single Phase Power Quality Analyzer Fluke’s single phase analyzers perform the measurements you need to maintain power systems and troubleshoot power problems and diagnose equipment failures. Get control of power problems The Fluke 43B has been the go-to industry leading single phase analyzer for over a decade in both industrial and classroom settings because of its intuitive ease of use and overall simplicity in performing just the right the measurements that you need to maintain power systems and troubleshoot power problems and diagnose equipment failures. Features; NiMH Battery provides extended operating time of 6.5 hours Combines the most useful capabilities of a power quality analyzer, multimeter and scope Calculates 3-phase power on balanced loads, from a single-phase measurement Trends voltage, current, frequency, power harmonics and captures voltage sags, transients and inrush current Monitoring functions help track intermittent problems and power system performance Records two selectable parameters for up to 16 days 20 measurement memories to save/recall screens and data with cursor readings FlukeView® software can log harmonics and all other readings over time and provides a complete harmonics profile up to the 51st harmonic Measures resistance, diode voltage drop, continuity, and capacitance Users/applications manual and power quality video to help answer tough questions Complete package with voltage probes and 400 A current clamp, FlukeView Software and optically isolated interface cable Harmonics Voltage, current, and power harmonics Up to 51st harmonic Total harmonic distortion (THD) Phase angle of individual harmonics Power Watts, power factor, displacement power factor (cos ?), VA and VAR Voltage and current waveforms Three phase On-screen graphics show you how to set up 3-phase power measurements Sags and swells Measurements are always automatically recorded to instantly show changes over time Use cursors to read time and date of sags and swells Transients Catch voltage transients and waveform distortion down to 40 nS Catch and save up to 40 transients Correlate the cause of transient with time and date stamps Specifications Input characteristics Input impedance 1 M?, 20 pF Voltage rating 600V rms, CAT III V/A/Hz display True-rms voltage (AC + DC) Ranges 5.000 V, 50.00 V, 500.0 V, 1250 V* Accuracy ±(1% + 10 counts) True-rms current (AC + DC) Ranges 50.00 A, 500.0 A, 5.000 kA, 50.00 kA, 1250 kA Accuracy ±(1% + 10 counts) Frequency Ranges 10.0 to 15.0 kHz Accuracy ± ([% of reading] + [counts]): 0.5% + 2 CF crest factor Ranges 1.0 - 10.0 Accuracy ±(5% + 1 count) Power display Watts, VA, VAR 1-phase and 3-phase,3 conductor balanced loads Ranges 250 W - 1.56 GW Accuracy ±(4% + 4 counts) Fundamental Power Accuracy ± (2 % + 6 counts) Total Power PF power factor Range 0 - 1.0 Accuracy ±0.04 DPF displacement power factor, Cos .F Range 0.25 - 0.9 Accuracy ±0.04 Range 0.90 - 1.0 Accuracy ±0.03 H2 frequency fundamental Ranges 40.0 to 70.0 Hz Accuracy ± ([% of reading] + [counts]): 0.5% + 2 Harmonics display Voltage, current, frequency Ranges Fundamental to 51st harmonic Accuracy VA ±(3% + 2 counts) W ±(5% + 2 counts) Fundamental 2 to 31st harmonic VA ±(5% +3 counts) W ±(10% +10 counts) 32 to 51st harmonic VA ±(15% +5 counts) W ±(30% +5 counts) Frequency fundamental Ranges 40 Hz to 70 Hz Accuracy ±0.25 Hz Phase Range V, A (Between fundamental and harmonics) Accuracy ±3? to ±15? Range W (Between voltage fundamental and current harmonics) Accuracy ±5? to ±15? K-factor (Current and Power) Range 1.0 to 30.0 Accuracy ±10% THD total harmonic distortion Range 0.00 - 99.99 Accuracy ±(3% + 8 counts) Sags and swells Recording times 4 min to 16 days (selectable) Vrms actual, vrms max, min (AC + DC) Ranges 5.000V, 50.00V, 500.0V, 1250V* Accuracy Readings ±(2% +10 counts); Cursor readings ± (2% + 12 counts) Arms actual, arms max, min (AC + DC) Ranges 50.00A, 500.0A, 5.000 kA, 50.00 kA Accuracy ±(2% +10 counts) Transient capture Minimum pulse width 40 ns Useful bandwidth input 1 DC to 1 MHz Number of transients 40 Voltage threshold settings 20%, 50%, 100%, 200% above or below reference Reference signal After START, the Vrms and frequency of the signal are measured. From these data a pure sinewave is calculated as reference for threshold setting. Vpeak min, vpeak max at cursor 10 V, 25 V, 50 V, 125 V, 250 V, 500 V, 1250 V Accuracy: ±5% of full scale R, C, diode, continuity Resistance ranges 500.0 ?, 5.000 k?, 50.00 k?, 500.0 k?, 5.000 M?, 30.00 M? Resistance accuracy ±(0.6% + 5 counts) Capacitance ranges 50.00 nF, 500.0 nF, 5.000 µF, 50.00 µF, 500.0 µF Capacitance accuracy ±(2% + 10 counts) Diode Ranges 0 to 3.000 V Diode voltage Accuracy ±(2% + 5 counts) Continuity Beeper on at < 30 ? ± 5 ? Max current 0.5 mA Temperature °C or °F Inrush current Inrush times 1 s, 5 s, 10 s, 50 s, 100 s, 5 min Current ranges 1 A, 5 A, 10 A, 50 A, 100 A, 500 A, 1000 A Cursor readings A peak max at cursor 1 and cursor 2 Accuracy ±5% of full scale Time between cursors 4 to 235 pixels (1 pixel = inrush time/250) Accuracy: ±(0.2% + 2 pixels) Temperature (with accessory) Range -100 °C - 400 °C Accuracy ±(0.5% + 5 counts) Scope display Measurements dc, ac, ac+dc, peak, peak-peak, frequency, duty cycle, phase, pulse width, crest factor Time ranges 20 ns/div to 60 s/div Max sampling rate 25 MS/s Bandwidth Voltage channel [1] 20 MHz at inputs, 1 MHz with TL24 leads Current channel [2] DC to 15 kHz at inputs, 10 kHz with i400s current clamp Coupling AC, DC (10 Hz - 3 dB) Vertical sensitivity 5 mV/div to 500V/div Vertical resolution 8 bit (256 levels) Record length 512 samples per channel Base ranges 60 S/div to 20 nS/div ± (0.4% + 1 pixel) Timebase modes Normal, roll, single Pre-trigger Up to 10 divisions Trigger Source Input 1 or input 2 or automatic selection Trigger Mode Automatic Connect-and-View™, free Run, and single Shot Connect-and-view™ Advanced automatic triggering that recognizes signal patterns Automatically adjusts triggering, timebase and amplitude and displays stable pictures Memories 20 (screens, settings, data) Recording Recording times 4 min to 16 days (selectable) Parameters Choose one or two parameters from one of the groups below Volts/Amperes/Hertz Power Watts, VA, VAR, PF, DPF, frequency Harmonics, THD, volts (Fund. and harmonic), amperes (F&H) watts(F&H) Frequency (H), %(H) of total, Phase(H), KF Temperature Resistance Resistance, diode, continuity, capacitance Scope DC voltage, DC current, AC voltage, AC current, frequency, Pulse width + or -, phase, duty cycle + or -, peak max, peak min, peak min-max, crest factor Note *Rated EN 61010-1 600 V CAT III CSA Environmental specifications Operating temperature 0°C to +50°C Safety specifications Electrical safety EN 61010-1 CAT III, 600V. CSA listed Mechanical and general specifications Size 232 x 115 x 50 mm Weight 1.1 kg Battery life Rechargeable NiMH pack (charger included), 6.5 hrs extended operating time (continuous) Shock and vibration Mil 28800E, Type 3, Class III, Style B Case IP51 (dust, drip, waterproof) **************************************Fluke i2000 flex AC Current Clamp************************************************** The i2000 is an AC current probe utilizing the Rogowski principle. It can be used to measure currents up to 2000A when used in conjunction with multimeters, recorders or data loggers. The flexible and lightweight measuring head allows quick and easy installation in hard to reach areas. Three ranges: 20A, 200 A & 2000 A, 100 mV/A, 10 mV/A & 1 mV/A output Ideal for current measurement on thick and hard to reach conductors without breaking the circuit Maximum conductor diameter 178 mm CAT III 600V safety rating Electrical specifications Current ranges 20 A 200 A 2000 A AC rms Output sensitivity (AC-coupled) 100 mV 10 mV 1 mV 1 mV per A Load impedance 100 k? minimum Accuracy at +25 °C ± 1 % of range (45 Hz to 65 Hz) Linearity 10 % to 100 % of range ± 0.2 % of reading Noise 8 mV ac rms (30 A) 2 mV ac rms (300 A, 3000 A) Frequency range 10 Hz to 20 kHz (-3 dB) Phase error < ± 1 ? (45 Hz to 65 Hz) ± 10 ? (at 20 kHz) Position sensitivity with cable > 25 mm from the coupling ± 2 % of range External field with cable > 200 mm from the head ± 1 % of range Power supply 2 x AA/MN 1500/LR6 Alkaline, 200 hours, low battery indicator Temperature Coefficient ± 0.08% of reading per°C Working voltage see Safety standards section 600 V AC rms or DC General Specifications Head Circumference 610 mm (24 in) Head cable diameter 14.3 mm (0.56 in) Head bend radius 38.1 mm (1.5 in) Cable length (head to electronics) 2 m (6.56 ft) Output connection Molded 4 mm safety plugs (not integrated) Operating temperature range 0 °C to +70 °C (32 °F to 158 °F) (head and electronics) Storage temperature range -40 °C to +105 °C (-40 °F to 221 °F) (head) -20 °C to +85 °C (-4 °F to 185 °F) (electronics) Operating humidity 15 % to 85 % (non-condensing) Weight 180 g (6.34 oz) (head) 190 g (6.70 oz) (electronics) Safety standards EN 61010-1: 2001 EN 61010-2-032: 2002 EN 61010-031: 2002 600 Vrms, Category III, Pollution Degree 2 Use of the probe on uninsulated conductors is limited to 600 V ac rms or dc and frequencies below 1 kHz. EMC standards EN 61326: 1998 +A1, A2, & A3 Dimensions HxWxD 116 mm x 68.5 mm x 30 mm (4.56 in x 2.69 in x 1.18 in)

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Fluke
Model	43B/003
