Fluke 43b Handheld Power Quality Analyzer Meter 43

US $1,095.00

Toledo, Ohio, United States
Jan 29th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Fluke 43B HandHeld Power Quality Analyzer (BC# 17885) 1000V Test Lead Set (1-Red, 1-Black) Flexible Test Lead Set (1-Red, 1-Black) (2) Alligator Clips AC Adapter/Charger User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Fluke 43B HandHeld Power Quality Analyzer Trends voltage, current, frequency, power harmonics and captures voltage sags, transients and inrush current Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty The Fluke 43 is a single phase power quality analyzer which combines the most useful capabilities of a power quality analyzer, multimeter and scope. It measures power harmonics, captures voltage sags, transients and inrush current. The Fluke 43's monitoring functions help track intermittent problems and power system performance. The Fluke 43 Power Quality Analyzer performs the measurements you need to maintain power systems, troubleshoot power problems and diagnose equipment failures. Features include: New! NiMH Battery provides extended operating time of 6.5 hours Combines the most useful capabilities of a power quality analyzer, multimeter and scope Simulates 3-phase power (assuming balanced loads) from a single-phase measurement Trends voltage, current, frequency, power harmonics and captures voltage sags, transients and inrush current Monitoring functions help track intermittent problems and power system performance Menus use familiar electrical terminology New! Toggle through the most commonly used power quality modes with a single keystroke Records two selectable parameters for up to 16 days New! 20 measurement memories to save/recall screens and data with cursor readings FlukeView® software can log harmonics and all other readings over time and provides a complete harmonics profile up to the 51st harmonic Measures resistance, diode voltage drop, continuity, and capacitance Users / applications manual and power quality video to help answer tough questions Software and optically isolated interface cable Technical Data Input Characteristics Input impedance: 1 MW, 20 pF Voltage Rating: 600V rms, CAT III Volt/Amps/Hertz Display True-rms voltage (ac+dc) Ranges: 5.000V, 50.00V, 500.0V, 1250V* Accuracy: ±(1% +10 counts) True-rms current (ac + dc) Ranges: 50.00A, 500.0A, 5.000 kA, 50.00 kA Accuracy: ±(1% +10 counts) Mains frequency Ranges: 40.0 to 70.0 Hz Accuracy: ±(0.5% +2 counts) Power Display Watts, VA, VAR Ranges: 250 W, 2.50 kW, 25.0 kW, 250 kW, 2.50 MW, 250 MW Accuracy: ±(4% + 4 counts) Power Factor, PF Displacement Power Factor, DPF Range: 0.00 to 0.25 Accuracy: Not specified Range: 0.25 to 1.0 Accuracy: ±0.04 Harmonics Display Voltage Ranges: 1st to 51st harmonic Accuracy: ±(3% +2 counts) to ±(15% +5 counts) Current Ranges: 1st to 51st harmonic Accuracy: ±(3% +8 counts) to ±(5% +8 counts) Power Ranges: 1st to 51st harmonic Accuracy: ±(5% +2 counts) to ±(30% +5 counts) Line frequency Ranges: 40 Hz to 70 Hz fundamental Accuracy: ±0.25 Hz Phase Ranges: 2nd to 51st harmonic Accuracy: ±3 ? to ±15 ? K-factor Ranges: 1.0 to 30.0 Accuracy: ±10% Sags and Swells Recording Recording times: 4 min to 16 days (selectable) True-rms voltage: Ranges: 5.000V, 50.00V, 500.0V, 1250V* Accuracy: ±(2% +10 counts) True-rms current Ranges: 50.00A, 500.0A, 5.000 kA, 50.00 kA Accuracy: ±(2% +10 counts) Other Recording Recording times: 4 min to 16 days (selectable) Parameters: Choose up to two from one of the groups below V/A/Hz: Line voltage, current, frequency Power: Watts, VA, VAR, PF, DPF, frequency Harmonics: THD, harmonic voltage, (or current, or power), frequency, % of total, phase Ohms: Ohms, diode, continuity, capacitance Temperature: Temperature Scope: DC voltage, dc current, ac voltage, ac current, frequency, pulse width, phase, duty cycle, peak max, peak min, peak min-max, crest factor Transient Capture Minimum pulse width: 40 ns Voltage threshold settings: 20%, 50%, 100%, 200% above or below normal voltage Min voltage and max voltage at cursor: Ranges: 10V, 25V, 50V, 125V, 250V, 500V, 1250V Accuracy: ±5% of full scale Inrush Capture Current ranges: Ranges: 1A, 5A, 10A, 50A, 100A, 500A, 1000A Inrush times: Ranges: 1s, 5s, 10s, 50s, 100s, 5 min Cursor readings, Current at cursor Ranges: 12.5A, 25A, 50A, 125A, 250A, 500A, 1250A, 2500A, 5 kA Accuracy: ±5% of full scale Time between cursors Ranges: 4 to 235 pixels (1 pixel = inrush time/250) Accuracy: ±(0.2% + 2 pixels) Scope Display Time ranges: Ranges: 20 ns/div to 60 s/div Max sampling rate: Ranges: 25 MS/s Bandwidth: Voltage channel [1]: 20 MHz at inputs, 1 MHz with TL24 Leads Current channel [2]: 15 kHz at inputs, 10 kHz with 80i-500s Probe Coupling: AC, DC Vertical sensitivity: Ranges: 5 mV/div to 500V/div Vertical resolution: 8 bit (256 levels) Record length: 512 samples per channel Timebase modes: Normal, roll, single Pre-trigger: Up to 10 divisions Measurements: dc, ac, ac+dc, peak, peak-peak, frequency, duty cycle, phase, pulse width, crest factor Ohms, Diode,Continuity Ohms: Ranges: 500.0W, 5.000 kW, 50.00 kW, 500.0 kW, 5.000 MW, 30.00 MW Accuracy: ±(0.6% +5 counts) Diode voltage: Accuracy: ±(2% +5 counts) Continuity: Beeper on at < (30W ±¤5W) Max current: 0.5 mA Capacitance: Ranges: 50.00 nF, 500.0 nF, 5.000 µF, 50.00 µF, 500.0 µF Accuracy: ±(2% +10 counts) Temperature** Ranges: -100.0 ?C to 400.0 ?C, -200.0 ?F to 800.0 ?F Accuracy: ±(0.5% +5 counts) Screen Memories 10 Optically Isolated RS-232 Interface To printer: Supports HP Laserjet®, Deskjet®, Epson FX/LQ and Postscript printers with optional PAC91 Printer Adapter Cable To PC: FlukeView® Power Quality Analyzer Software included FlukeView Power Quality Software Hardware requirements: PC or 100% compatible with Windows® 3.1, Windows® 95, or Windows NT® . Enough RAM for Windows operating system. 4 MB hard drive space. Pointing device (mouse) recommended. Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Put your auctions on autopilot with Kyozou eBay Auction Tools

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	Fluke
Model	43B
