Fluke 773 Milliamp Process Clamp Meter With Soft Case

US $786.16

shenzhen, China
Jan 29th

Open on mobile:
QR code

Packing included: Fluke 773 Milliamp Process Clamp Meter with soft case Fluke 773 Milliamp Process Clamp Meter Milliamp process clamp meters can measure mA signals without breaking the loop. The Fluke 773 mA Clamp Meter is Fluke’s premier mA Clamp Meter, providing you with the best in troubleshooting and process calibration power. Need more hours in your day? Save time by NOT breaking the loop on 4-20 mA signal measurements. Are you spending time: Taking mA measurements by removing a wire and breaking the loop Calling the control room to isolate a loop Testing analog input/output on a console Troubleshooting devices with mA inputs and outputs Repairing intermittent or erratic 4-20 mA loops Going back to the shop to get extra tools If you need more time in your busy day take a good look at the Fluke 773mA Clamp Meter. It’s designed to save you time, and money, by eliminating time wasting activities. Now you can troubleshoot and repair 4-20 mA loops without breaking the loop or bringing down the system. Here are some specific ways the Fluke 773 Clamp Meters will help you: Milliamp Clamp Features Application How it saves time and money Measure mA signals for PLC and control system analog I/O without breaking the loop. Measures low level dc current Correlate process indication with real physical value Measure output signals from transmitters without breaking the loop Maintain and troubleshoot process and automation equipment without breaking the loop No disruption to the process Detachable clamp with extension cable Measurements in tight locations Enables measurements in difficult situations Source, simulate and measure mA signals in circuit (break the loop) Confirm non-contact measurement. ve the next tool in hand for troubleshooting (source simulate) Eliminates the need to return to the shop to get a loop calibrator for troubleshooting after finding a bad signal with non-contact measurement Source and measure VDC Troubleshoot voltage input and output devices. Measure presence of 24V loop power. Measure 1 to 5 or 0 to 10V process signals. Test chart recorders 4 to 20 mA In/out Dual channel mA source and measurement for troubleshooting Source 4 to 20 mA signals into valves and mA signal conditioners and simultaneously measure 4 to 20 mA positioning output signals. 4 to 20 mA scaled output Scaled mA output provides a mA signal output representative of the measured mA value Connect a logging DMM and log the mA signal without breaking the loop Loop power supply Power a transmitter Substitute testing of the installed 24V loop power supply. Power a transmitter and measure its mA output signal for troubleshooting. Dual backlit display with both mA measurement and percent of 4 to 20 mA span Clear measurement presentation Allows quick measurement evaluation Measurement Spotlight Illuminates hard to see wires in dark enclosures Measurement process is easier and quicker Measure up to 99.9 mA range non-contact Wide range of measurements Measures 10 to 50 mA signals in older control systems Automatic power off After 15 minutes and 2 minute automatic off for backlight and spotlight Saves battery life The 773 mA Clamp Meter features: Best in class 0.2 % accuracy 0.01 mA resolution and sensitivity Measure 4 to 20 mA signals without ”breaking the loop” Measure mA signals for PLC and control system analog I/O Dual backlit display with both mA measurement and percent of 4 to 20 mA span Measurement Spotlight illuminates hard to see wires in dark enclosures Detachable clamp with extension cable for measurements in tight locations Measure 10 to 50 mA signals in older control systems using the 99.9 mA range Automatically change the 4 to 20 mA output for remote testing Power saving features, auto-off, backlight timeout extend battery life Hold function captures and displays changing measurements Measure 4 to 20 mA signals with in-circuit measurement Simultaneous mA in-circuit measurement with 24V loop power for powering and testing transmitters Source 4 to 20 mA signals for testing control system I/O or I/Ps mA output linear ramp or 25% step output Automatically change the 4 to 20 mA output for remote testing DC voltage measurement to verify 24V power supplies or voltage I/O signals Source DC voltage to test input devices that accept a 1-5V or 0 to 10V signals Scaled mA output provides a continuous mA signal that corresponds to the 4 to 20 mA signal measured by the mA clamp Enables milliamp signal logging to a separate logging device without breaking the loop Output mA signal enables a logging DMM or other device to record the 4- to 20 mA signal without breaking the loop mA in/out: simultaneously measure the mA signal with the clamp and source a mA signal Apply a mA input signal to a device and measure its’ 4-20 mA output on devices such as valves or mA isolators Voltage output linear ramp or 25% step output Automatically change the voltage output for remote testing What’s the difference between the 77X models Environmental Specifications Diameter of measurable conductor 0.177” or 4.5 mm max Operating temperature -10 to 50 ºC Storage Temperature -25 to 60ºC Operating Humidity < 90% @ <30 ºC, < 75% @ 30 to 55ºC Operating Altitude 0 to 2000 m IP Rating IP 40 Size 44 x 70 x 246 mm (2 7/8 x 5 ¾ x 11 5/8 in) Weight 410 g, (14.4 oz) Vibration Random 2 g, 5 to 500 Hz Shock 1 meter drop test (except the jaw) EMI/RFI Meets EN61326-1 Note: For current measurement w/ JAW, add 1mA to specification for EMC field strengths of 1V/m up to 3V/m. Temperature Coefficient 0.01% ºC (<18ºC or > 28ºC) Power, battery life (4) AA 1.5 V Alkaline, IEC LR6, 12 hours in mA source into 500 ohms Warranty Three years for electronics one year for cable and clamp assembly Functional Specifications mA measurement (Measured by clamp) 771/772/773 Resolution and Range: 0 to 20.99 mA Accuracy: 0.2%+2 counts Resolution and Range: 21.0 mA to 100.0 mA Accuracy: 1% + 5 counts mA measurement (Measured in series with test jacks) 772/773 Resolution and Range: 0 to 24.00 mA Accuracy: 0.2% + 2counts mA source (Maximum mA Drive: 24 mA into 1,000 ohms) Resolution and Range: 0 to 24.00 mA Accuracy: 0.2% + 2counts mA simulate (Maximum voltage 50 V dc) Resolution and Range: 0 to 24.00 mA Accuracy: 0.2% + 2counts Voltage source (2 mA maximum drive current) Resolution and Range: 0 to 10.00 V dc Accuracy: 0.2% + 2counts Voltatge Mesaure Resolution and Range: 0 to 30.00 V dc Accuracy: 0.2% + 2counts Notice: The standard package don't include batteries.Because,the international air shipping forbid to ship liquid,powder and batteries,we can not put them in the package box.Hope you can understand buy them in your local store or supermarket.Thanks for your support! Item Description CONDITION: 100% Brand New We are excellent seller with very nice reputation from CHINA. We are selling many different kinds of stuff that you can imagine. Our tenet is not focus on getting more benefit but reputation and friends. The most important thing to us is the customer satisfactions. Add my Store to your Favorites NOW and receive my email newsletters about new items and special promotions! ·If you have any questions, please do not hesitate to contact us on EBay. Emails are normally answered within 48 hours of business day; If you do not receive a response from us PLEASE TEST YOUR EMAIL. Many times it's due to a full mailbox or error in your e-mail. This is very common for AOL & HOTMAIL users . Payment Description We accept only PayPal payment. Please notice that EBay don't allow buyer to combine shipping in different currency. If you want to combine shipping for multiple items, please ensure that all items you buy are in the same currency A non-payment dispute will be opened if full payment is not received after 14 days of auction. Shipping Description We only ship to the approved address given in PayPal payment. Please make sure payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. A notification email of dispatch will be sent to buyer after item is posted. Please email us if you don't receive our email after 5 days of full payment sent. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. Combine shipping: We grant special discount for combine shipping in both Domestic and International area. GBP 1.00 will be deducted for per additional item in British Pounds from the shipping and handling charge. $2.00 will be deducted for per additional item in US dollar from the shipping and handling charge. Combine shipping is only valid for NON-FREE-SHIPPING ITEMS purchased within 7 days from the first won item. All items to be combined must be in the same invoice. We cannot do combine shipping with auctions that you have already paid or in different currency. Please wait until you are completely finish shopping before you checkout or sending us email to request for a final invoice. Return Description We accept return and exchanges when you received the defective items or highly unlikely. Please contact us ASAP to report the problem within 3 days after receiving. After 3 days, we would NOT accept any return and exchanges. We are not focusing on getting more benefits but reputation. The feedback is the most important thing for us. So PLEASE remember that: NEGATIVE AND NETURAL feedback can't solve any problems. Thank you very much for your understanding. In the unlikely event that a return is request, all returns must include all original items undamaged, in re-saleable condition, all original packaging including manuals, warranty forms, etc. Software sales are not refundable. Shipping and handling fees are not refundable. Buyer is responsible for shipping costs incurred shipping products back. Your partner for managing your online business
