Fluke 97 Auto Scopemeter Dual Trace 50 Mhz Handheld Oscilloscope

US $495.00

Toledo, Ohio, United States
Aug 6th

Open on mobile:
QR code

The Following Items Are Included: Fluke 97/Auto ScopeMeter 50MHz Oscilloscope (BC# 42595) (3) Fluke Flexible Test Leads (3) Fluke Test Probes (3) Fluke Alligator Clips (2) Fluke Banana BNC Adapters Fluke Inductive Pickup Fluke Quick Operating Guide DC Car Charger AC Adapter/Charger Hard Copy User Manual Hard Carrying Case BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Fluke 97/Auto ScopeMeter, Dual Trace, 50-MHz Bandwidth HandHeld Oscilloscope Simultaneous display of four waveforms (any combination of live and stored) allows for useful comparisons. Autoset configures ScopeMeter to select the best voltage and time base settings for a meaningful display. Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 1 YEAR WARRANTY Fluke 97 Auto Scopemeter Your Fluke 97/Auto ScopeMeter combines the capabillities of a dual-trace, digital-storage oscilloscope with teh versatility of a digital multimeter. This combination allows you to analyze and compare complex waveforms, read voltage levels, or simply measure resistances. ScopeMeter features include: - Dual Trace, 50-MHz Bandwidth Scope - 25 million samples-per-second, 40 ns glitch capture capability - 3000 Count Digital Multimeter (DMM) - Menu-Driven Interface for easy operation. - Storage for 10 front panel setups (Meter and Scope Modes). - Digital starage for eight waveforms. - Simultaneous display of four waveforms (any combination of live and stored) allows for useful comparisons. - Autoset configures ScopeMeter to select the best voltage and time base settings for a meaningful display. - Undo featrue allows you to step back through the 10 most recent key presses. - true portability and three source choices allow for testing in real-life environments. Specifications Multimeter DC Volt Ranges: 300 mV, 3V, 30V and 300V Accuracy: ±0.5% ±5 counts AC Volt Ranges: 300 mV, 3V, 30V and 250V Accuracy: ±1% ±10 coutns, 50 Hz to 50 Hz ±2% ±15 coutns, 20 Hz to 20 kHz ±3% ±20 coutns, 5Hz to 1 MHz additonal error ±1% ±1 kHz For <10Hz with 10:1 probe or >100 Hz direct (1:1 probe), use function Vrms AC + V DC. The 10:1 accessory probe increases the ranges by a factor of 10. To create more accurate measurements on ac, or on dc with a large ac component, the time base often can be optimized by pressing "auto-set" or by changing the settign accessed by pressing "Time" mV DC Ranges: 300 mV and 3V Accuracy: ±0.5% ±5 counts This range has a low-pass filter with a bandwidth of 5 kHz. Ohm Ranges: Ranges: 300, 3k, 30k, 300 k, 3 M and 30M Accuracty: ±0.5% ±5 counts Range: 30 Accuracty: ±2.4% ±25 counts Diode Measuring Current: 0.5mA Maximum Voltage: 4V If Output Voltage is higher than 2.8V, OL (OverLoad) is displayed. Display Modes Frequency The Frequency can be displayed withing the following parameters: Range: 1 Hz...5MHz Accuracy: ±0.5% Resolution: 4 Digits Trace DISP The display trace can be switched off. Duty%+, Duty%- Relative on-to-off time of a varying input can be displayed as a percentage. Range: from <2.0% to >98.0% for signal amplitudes >10% of the input voltage range. Resolution: 0.1% Accuracy (logic or pulse waveforms): within ±0.5% Accuracy (sine or triangle waveforms): within ±1% + ((Voltage Range/RMS Input Voltage) x 1%) %/Delta Displays the difference after 0% or % is pressed. Scaling 0% and 100% can be set, creating an a + bx computed reading where a and b are the 0 and 100% values, respectively, and x is the measured value. Volt Match Results can be displayed in dBV, dBm, dBW, or Audio Watt. The assumed load resistance can be chosen from: 1,2,4,8,16,50,60,75,93,110,125,135,150,200,250,300,500,600,800,900,1000,1200 , depending on teh display mode. Record In meter mode, the actual value is displayed simultaneously with the maximum, average, and minimum values. Tough Hold Feature Can be activated by pressing "Hold Run" Oscilloscope Vertical System Deflection Factor 1mV to 100V per division in 1-2-5 sequence, for time base 60s/division to 1ms/division. This can be expanded by a factor of 10 witht eh 10:1 accessory probe. Vertical Resolution 8 bits, 25 levels per division DC Accuracy ±2% Rise Time Vertical amplifier response limits the rise time to 7ns. For time base settigns slower than 200ns teh rise time is smaller than the sample distance, so the measured rise time is unreliable if it is smaller than (2xs/div)/25 Bandwidth With 10:1 prove only:> MHZ (-3dB) Nonlinearity Including analing to digital converter, which will have no missing codes and is monotonic: ±)2% ± 1 digit) Move Control Range From +4 divisions to -4 divisions DC Balance Base line is automatically readjusted after switching the attenuator or ac/dc/ground MIN/MAX Acquisition mode at 1 ms per division or slower on Channel A only. Pulse width for 100% probability of detection is 40ns. Average The running average can be set to 256 maximum. In Roll Mode, the average is fixed at 10. Zoom Expand or contract view centered around the 4th division, withing teh limits of the time base and teh maximum dleay. Horizontal System Range: 5s to 10ns per division with triggered start. The roll mode is active from 60s to 10s Single shots are possible from 5s to 100 ns per division For tiem base settings faster than 1ms, an automatic interpolation takes place. The useful band-width is about 6MHz. For time base settings of 50ms or slower, the channels are chopped. for time base settigns of 20ms or faster, teh channels are alterneated. Channel A is dipslayed first and, after a second trigger pulse, Channel B is diplayed second. ACCURACY: Accuracy is ±0.1% 1 LSB Sample Frequency Dependent on time base: 25/sec-per-div) Hz (maximum 25 MHz) in Min/Max: 25 MHz Record Length 512 samples calibrated for 25 samples per division. Capture Allows selection of a record length of 10 or 20 divisions Move Control From +4 divisions to -16.5 divisions. A Versus B Channel A is displayed along the vertical axis. The time base is set manually. Trigger Internal Sensitivity For frequencies lower than 10MHz: <0.8 div Extra amplification in the vertical system allows for 2 mV and 1 mV per division for the input signal, but not for the trigger. Therefore, sensitivity at 2mV adn 1 mV decreases by a factor of 5. Level Range From +4 division to -4 divisions. External TTL Compatible. Selectable for 0.2V or 2V. Trigger level is indicated on the screen. Delay Range Time Delay: -20 to +640 divisions Events: 1 to 1023 N_CYCLE: trigger frequency divided by N (2 to 255.) Waevform Memoies For waveform storage, eight extra memories are avialable. The memories can be cleared all together. Each memory contains 412 words for waveform and the setup belonging to this waveform. For full Fluke 97 Auto ScopeMeter product specifications, please click here: Fluke 97 Auto Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Sell Smarter with Kyozou. Inventory and Ecommerce Management

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	Fluke Networks
Number of Channels	2
MPN	97 Auto
Features	Handheld/ Portable
Oscilloscope Type	Digital Storage Oscilloscope (DSO)
Model	97 Auto
Maximum Bandwidth	50 MHz
