Fluke I3000s Flex-36 Ac Current Clamp, 600v Voltage, 3000a Ac Rms Current, 915mm

US $590

USA, United States
Nov 4th

Open on mobile:
QR code

Fluke I3000S FLEX-36 AC Current Clamp, 600V Voltage, 3000A AC rms Current, 915mm Head Item Description The i3000s Flex is an ac current clamp utilizing the Rogowski principle. It can be used to measure currents up to 3000 A when used in conjunction with oscilloscopes, recorders or data loggers. The flexible and lightweight measuring head allows quick and easy installation in hard to reach areas. Three ranges: 30A, 300A and 3000A, 1, 10 or 100 mV/A output. Ideal for current measurement on thick and hard to reach conductors without breaking the circuit. Maximum conductor diameter 178mm. CAT III 600V safety rating. Output sensitivity (AC-coupled): 100 mV, 10 mV, 1 mV per A. Load impedance: 100 kilo ohm minimum. Accuracy at +25 degree C: +/-1 percent of range (45 Hz to 65 Hz). Linearity 10 to 100 percent of range: +/-0.2 percent of reading. Noise: 8 mV AC rms (30 A), 2 mV AC rms (300A, 3000A). Frequency range: 10 Hz to 50 kHz (-3 dB). Phase error: less than +/-1 degree (45 Hz to 65 Hz), +/-10 degree (at 20 kHz). Position sensitivity with cable greater than 25 mm from the coupling: +/-2 percent of range. External field with cable greater than 200mm from the head: +/-1 percent of range. Power supply: 2 x AA/MN 1500/LR6 Alkaline, 400 hours, low battery indicator or dedicated external power supply. Temperature Coefficient: +/-0.08 percent of reading per degree C. Working voltage: 600V AC rms or DC. Head circumference: 915mm. Head cable diameter: 14.3mm. Head bend radius: 38.1mm. Cable length (head to electronics): 2m. Output connection: 0.5m cable terminated with safety BNC connector. Supplied with 4mm safety plug adapter. Operating temperature range: -20 to +90 degree C (-4 to 190 degree F) (head), -20 to +85 degree C (-4 to 185 degree F) (electronics). Storage temperature range: -40 to +105 degree C (-40 to 221 degree F) (head), -20 to +85 degree C (-4 to 185 degree F) (electronics). Operating humidity: 15 to 85 percent (non-condensing). SPECIFICATIONS Three ranges: 30A, 300A and 3000A, 1, 10 or 100 mV/A output Ideal for current measurement on thick and hard to reach conductors without breaking the circuit Maximum conductor diameter 178mm CAT III 600V safety rating The flexible and lightweight measuring head allows quick and easy installation in hard to reach areas ADDITIONAL FEATURES Manufacturer: Fluke Corporation Shipping Weight: 150 Product Dimensions: Width: 6.70 Length: 9.70 Height: 2.00 SHIPPING INFORMATION ● Our stock all ships from our US-based warehouses. ● Shipped via USPS or UPS (depending on location and package weight) ● Unless stated otherwise, all orders will ship within 24 hours of your payment being processed. Check our feedback to see the great reviews of FAST shipping we offer. ● Shipping is always FREE! RETURN & REFUND POLICY ● We offer a 30 day return/exchange policy for our products. ● You can choose refund or exchange if you are dissatisfied for any reason with your product. ● Only factory defects are accepted as a reason for a return. In the case of factory defects, we will replace the product for you. ● When returning an item, it must be in all of the original packaging and include all of the original accessories or items that came with it. The item and package should be in original and perfect condition. ● You will be required to cover shipping on the return of defective items. ● All returns MUST be done within 30 days of date of purchase. Please note that we cannot give refunds or replacements after the 30 day limit has expired. ● When sending in a return, please note that it can take up to 7 business days for the return to be processed. We do our best to process as quickly as possible. ● Buyers outside the U.S.A please note - ALL of our electrical appliances sold in our store are 110-120V. ● Return policy for buyers outside the U.S.A - We offer to return the items within 30 days. The BUYER will ship the item at his own cost. We are extremely fair, and in the rare event of something out of the ordinary happening with our products or shipping, we will gladly work with you to find a solution. ABOUT BELLE'S STORE We have been available to online customers, offering a variety of brand new products at great prices. All of our products ship directly from our different warehouses across the United States so you get your items quickly and in perfect condition. We know how important it is for you to get what you ordered and get it fast. Our products are a 100% authentic and brand new. We work with the biggest suppliers of high quality products to bring you only the best items. It is very important to us that we put our customers first and you will see this reflected in every transaction with us. We consider it a top priority that our customers are happy and in the rare event that they are not, we do everything we can to fix the situation. No customer will walk away from our store unhappy. If there's a problem, just let us know and we fix it. We guarantee you only the best experience when shopping with us!
