Manufacturer: Fluke Networks Model#: 635A QuickBERT-T1 Nomen: T1 Test Set Condition: Used/Battery Pack Inop Return Policy: AS-IS The Fluke 635 includes all the basic T1 testing capabilities you would expect in a larger and more expensive tester. It performs bit-error tests, detects framing type, line coding and bit pattern, and displays signal level, frequency, clock slips, errors and alarms. The 635 transmits the most commonly used loop codes, including HDSL. Full, unframed and fractional (56k and 64k) T1 are supported, along with display of signaling and data bits and capture of DTMF digits. Plus, individual voice channels may be monitored on the built-in speaker or over a headset. Eleven standard BERT patterns are available, including a 64-bit user-defined pattern. The 635 also includes a 'through' mode where the incoming pattern is retransmitted. Errors - including bipolar violations, logic and frame bit - can be injected to confirm proper handling by the network. Two receivers permit detection of any clock slips. Multiple receiver input types allow terminated, bridged or monitor (DSX) connections. Either recovered or internal clock references can be selected. AMI or B8ZS line coding can be transmitted and received, and SF, ESF, SLC96 and unframed framing are supported. The 635 is compact, rugged and easy to use. Just plug it in and you can immediately see essential information without scrolling through layers of menus. The 635 automatically detects framing and line coding type and instantly displays any errors or alarms. A history indicator helps track intermittent problems. Features & Specifications Primary T1 Receiver Range, Bridge: 6 to -36dB Range, Term: 6 to -36dB Range, Monitor: -15 dB to -24dB Framing: NONE, D4, ESF, SLC 96 Line coding: AMI, B8ZS Patterns: QRSS, 1 IN 7, 2 IN 8, 3 IN 24, ALL 0'S, ALL 1'S, 1:1, NET55, OCT55, DALY55, USER (default = 1:16) Status/history: AMI (status only), B8ZS, Signal Present, Out of Frame, Blue Alarm (AIS), Ones Density, Excess Zeros, Yellow Alarm, DS1 Idle Signal (all Tx patterns are frame aligned), Pattern Sync Loss DS0 drop: Selected DS0 channel to eight data bit LEDs and speaker DS0 signaling types: Robbed Bit, CCIS, E-Bit DS0 Signaling Bits: A, B, C, D Reference T1 Receiver Range: 0 to -36dB Compatibility: AT&T TA24/CB113 Transmitter Output Line Codes AMI or B8ZS Framing: NONE, D4, ESF, SLC96 Frequency: 1544000Hz ±5ppm Patterns: QRSS, 1 IN 7, 2 IN 8, 3 IN 24, ALL 0'S, ALL 1'S, 1:1, NET55, OCT55, DALY55, USER, THRU LBO: Fixed at 0dB Tx clock source: Internal, derived from received data, or external Loop codes: CSU, NIU4, NIU5, NETWRK (ESF), LINE (D4), LINE (ESF), PYLD (ESF), ARM (D4), ARM (ESF), HTU-R,HTU-C, HRE1, HRE2, NREM, NLOC, NDU1, NDU2, CREM, CLOC, CDU1, CDU2 Specification Compatibility ANSI T1.403 AT&T PUB62411 Connectors Rx T1 Receiver Term/Mon/Bridge: Bantam jack Tx T1 Transmitter: Bantam jack Ref T1 Receiver: Bantam jack Auxiliary power: DC power jack Headset: 3.5 mm phone plug- stereo Results Display: 4 x 20 liquid crystal display (LCD) Clock slips: Positive number means reference clock faster; negative number means slower Errors: BIT ERR, BPV ERR, FRM ERR, CRC ERR, FREQDEV Signal: DS1 Freq, DS1 Level, DS0 Freq, DS0 Level DS1 Freq accuracy: ±5ppm, 32° to 104°F (0° to 40°C) DS1 Freq resolution: 1Hz DS1 Freq range: 1544000 ± 10,000Hz DS1 Level range: 6dBDSX to -40dBDSX DS0 Freq accuracy: ±1.5Hz DS0 Level accuracy: ±0.2dBm Power Battery Pack: Rechargeable, nickel metal hydride (NiMH); 3.5 amp-hours Battery life: Approximately six hours of continuous operation Low battery: Red LED illuminates, indicating recharge is needed Auxiliary power: 9 to 12VDC, 1000mA Physical Size: 1.75" H x 5" W x 9" L (4.4cm x 12.7cm x 22.8cm) Weight: 1lb, 10oz (0.7kg) SPECIFICATIONS Accessories Included: see picture Battery pack does not take charge; offered AS-IS. Our phone#: 888-542-8256 We are in Vista, California (a community of San Diego) RETURN POLICY Our items are warranted against Operational failure within noted return period Shipping damage, if item is shipped on our account (ie we are the shipper of record) Warranty begins upon receipt. Warranty does not cover noted operational and/or cosmetic discrepancies (if any). Warranty void if tamper seals broken. Refunds are cash back. Buyer pays return shipping. Items listed in AS-IS condition are not eligible for return. It is the responsibility of the buyer to determine whether the item meets their needs; we do not accept returns if the buyer decides the item is not appropriate to their requirements. ATTENTION NON-US BIDDERS Some items may be subject to Export Control Restrictions that will prevent us from shipping to your country. All items to be shipped to non-US countries will first need to be verified by Avalon before they are shipped. Items that are subject to export controls may require additional documentation and information from the bidder or may not be allowed to ship at all. Non-US bidders are STRONGLY encouraged to review U.S. export controls for items you are bidding on PRIOR to bidding. Go to www.bis.doc.gov and follow the procedures listed if this applies to you. INTERNATIONAL SHIPPING International shipments are shipped via the eBay Global Shipping Program. We ship the item to the eBay freight forwarder, who then transships it to its destination. Once the item leaves the forwarder, it is then the responsibility of eBay. That is, if it is lost or damaged, eBay is liable for it, and any shipping claims must be handled through eBay. The international shipping amount will be computed by eBay and will be shown on the auction page. In the listing, the buyer sees Estimated Shipping Charges and Estimated Import Charges which will be charged when eBay submits the invoice. Their shipping method and charges are non-negotiable. We do not ship internationally by any method other than the eBay Global Shipping Program! PAYMENT TERMS Avalon Equipment Corporation accepts the following forms of payment: PayPal (preferred method - item shipped quickly) MasterCard/Visa/American Expres Check (will delay shipment until check clears) i-Escrow (escrow fees to be paid by buyer) CA Residents add applicable county sales tax WA Residents add 8.8% Sales Tax TX Residents add 8.25% Sales Tax Including Shipping SHIPPING POLICIES Every attempt is made to ship on the same day of payment Shipping charges are added to final bid price Most items are InstaPak foamed to ensure that equipment arrives in the same condition as shipped Unit(s) are guaranteed to be in good working order upon your receipt. Calibration not included unless explicitly stated in auction Local pick up okay Shipping can be billed to customer's account if wished (domestic only); contact us for details. CLICK FOR LARGER VIEW:
