Fluke Networks 686 Enterprise Lanmeter 10/100 Ethernet Token Ring Network

US $79.00

Issaquah, Washington, United States
Jan 29th

Open on mobile:
QR code

Fluke Networks 686 Enterprise LANMeter 10/100 Ethernet Token Ring Network Photos are of actual unit and is what you will receive. The battery is dead. It works when the power is plugged in. 3 prong power cord not included. If there is ANY problem with your item, PLEASE contact us before filing claims or leaving feedback. We are happy to resolve your problem! We happily accept returns! I ship within 24 hours! PLEASE READ We are an electronics recycling company. Most items we received are used surplus, and we do not have any personal experience with these items. Please understand that most items are power tested only, unless the ad specifies otherwise. Please bid with the understanding that we have not tested all functions, and do not guarantee every item works 100% as intended. Enterprise LANMeter's extensive network monitoring capabilities include: Ethernet Network Statistics - Monitors the general health of a network by calculating statistics for key network parameters. The results show Utilization, Collisions, Errors, and Broadcasts as average, maximum, and total values, in numeric and bar graph formats. Error Statistics - Monitors the types and sources of errors. Displays chart which shows error distributions by error type. For Error Types that are preceded by the icon, highlight the specific Error Type and press the "Zoom In" softkey to obtain a list of stations sourcing those errors Token Ring Network Statistics - Monitors the general health of a network by calculating statistics for key network parameters. The results show Utilization and Soft Errors in numeric and bar graph formats, and other key frames as average, maximum, and total numerical values. Error Statistics - Monitors the types and sources of errors. Displays results in numerical and pie chart formats. Highlight a category and press the "Zoom In" softkey for fault domain address information. Token Rotation - Calculates the time for the token to travel completely around the ring. This test shows the last, average, and maximum values for token rotation time and the number of active stations. The LANMeter analyzer also reports when token rotation is outside of the normal range. Ring Stations - Monitors the Network and compiles an ordered list of stations inserted into the ring. The list is in the correct physical order around the ring, starting with the active monitor. Stations may be displayed in the following address formats, depending on which are known; symbolic name, manufacturer prefix, or hexadecimal MAC address. Use the active monitor history screen to view a time-stamped log of which stations have been the active monitor. This helps you isolate hard-to-find problems related to which station is the active monitor. Beaconing Rings - Push one button and, in seconds, the LANMeter analyzer will insert into a beaconing ring and automatically identify the fault domain. No more wading through screens of decodes to extract the buried fault domain information. A beacon alert pop-up window is displayed when the LANMeter analyzer detects beacon frames on the network. Ethernet and Token Ring Protocol Mix - Displays a percentage-ranked listing of the top protocols measured by frame count on the local segment. The LANMeter analyzer automatically identifies encapsulation types for IPX. Highlight a protocol and press the "Zoom In" softkey for a list of the top stations transmitting that protocol. The list of all protocols and stations recorded for each protocol may be printed or viewed. Top Senders - Monitors the busiest transmitting nodes on the local network. The LANMeter analyzer can be configured to filter on a single address and show the top senders to a particular station. Top Receivers - Monitors the busiest receiving nodes on the network. Information is displayed in the same format as Top Senders. Top Broadcasters - Monitors the type and source of broadcasts and can be used to identify misconfigured stations. The LANMeter analyzer distinguishes between broadcast, multi-cast, and non-broadcast frames for Ethernet. For Token Ring, the LANMeter analyzer distinguishes between all routes, single routes, no route control, and non-broadcast frames. Traffic generation - Traffic generation is used to stress test network components. Adding traffic reveals media and other physical layer problems on networks. The traffic generator may be run concurrently on Ethernet networks with Network Statistics, Error Statistics, and Collision Analysis, and on Token Ring networks with Network Statistics, Error Statistics, and Ring Stations. Use traffic generation to characterize network behavior in high traffic circumstances. User selectable parameters include frames-per-second of added traffic and frame size. To assist in testing bridges and routers the LANMeter analyzer automatically builds IP and IPX headers, all you need to supply is the source and destination address. While the test is running, users may increase or decrease the current frame rate and size on the fly with the cursor keys. This is particularly useful when trying to locate sources of throughput problems and failure conditions. For Token Ring networks, select among three different worst-case data patterns. These patterns are known to test for correlated phase jitter sensitivity resulting from cabling, adapter card, and interoperability problems. MAC Matrix - Monitors the busiest transmitting nodes on the local network and displays test results by Source/Destination address pairs. Test results include frame count transmitted by each address in the pair combination. When address filtering is on, displayed conversations are limited to those that are to or from the filtered address. With filtering off, the test tracks the first 512 conversing station pairs seen on the network, displaying the busiest eight. A list of all conversations recorded as transmitting during the test may be printed or viewed.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Fluke Networks
Model	686
