Fluke Networks Analog Tone Probe Kit Phone Data Jack Ports Telephone Test Tool

US $97.69

Glenpool, Oklahoma, United States
Jan 29th

Open on mobile:
QR code

Fluke Networks Pro3000 Tone Generator and Probe Kit Tone and trace wire on non-active networks. SmartToneTM technology provides five distinct tones for exact pair identification. Sends a loud tone up to 16 km (10 miles) in most cables and provides five distinct cadences for isolating individual wire pairs Loud speaker on Probe makes the tone easier to hear through drywall, wood, and other enclosures Angled bed-of-nails clips allow easy access to individual pairs and RJ-11 easily connect to telephone jacks---no need for adapters Attach nylon pouch (included in kit) to your belt for easy transport The Fluke Networks Pro3000 Analog Tone Generator and Probe Kit with ABN (angled bed-of-nails) clips and an RJ11 plug connects to inactive networks to locate and trace cables, wires, and wire pairs by sending a loud tone up to 16 km (10 miles) in most cables and providing five distinct cadences for isolating individual wire pairs. It also checks continuity and polarity, which are indicated by dual-color LEDs—red for continuity, and red and green for polarity of a DC-powered wire pair. The ABN clips allow access to individual wire pairs and the RJ11 plug connects to telephone jacks. The tone generator injects a tone, either constant or alternating, into a cable, and its SmartTone feature allows that tone to be modified to any of five distinct cadences for isolating individual wire pairs within a multi-pair cable. The probe detects the generated tone so that the cable can be located, and has an adjustable-volume speaker that amplifies the tone for tracing through drywall and wooden barriers such as walls and other enclosures. Its 3.5 mm jack allows for an earphone (sold separately) to be attached, muting the speaker for discrete toning or toning in noisy environments. The non-metallic tip of the probe enables testing in distribution blocks without disturbing other services and a spare tip is included inside the probe's battery compartment. Tone generators and probes are used by network technicians to troubleshoot and maintain wires and cable in telephone and data networks. Pro3000 Analog Tone Generator and Probe Specifications Cable compatibility Inactive AC wire, telephone/twisted pair wire, voice and data cable, coaxial cable, speaker wire, security wire Maximum length tested 16 km/10 miles of 24 AWG twisted pair (varies for other wire types); 3.3 km/2 miles for SmartTone signals Line cord connectors ABN (angled bed-of-nails) clips; RJ11 plug Tone frequency (nominal) 1000 Hz for constant tone; 1000/1500 Hz for alternating tone Over voltage protection 60 VDC in toner or polarity mode Output power in tone mode 8 dBm into 600 ? Output voltage in continuity mode 8 VDC with fresh battery Agency certifications and standards met CE (European Conformity) marking; Canadian Standards Association CAN/CSA-C22.2 No. 60950-1-03, CAN/CSA-C22.2 No. 1010.1-92, and CSA-C22.2 No. 1010.1B-97; UL/ANSI (Underwriters Laboratories/American National Standards Institute) 3111-1 Power source (2) 9V alkaline batteries (sold separately), one each for tone generator and probe Dimensions Tone generator: 6.9 x 6.1 x 3.6 cm/2.7 x 2.4 x 1.4 in Probe: 24.9 x 4.1 x 3.3 cm/9.8 x 1.6 x 1.3 in (H x W x D) *H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Datacom and telecom installation and test devices, such as toners and test sets, check cabling and wiring to help ensure proper connections and operation. Tone generator and probe sets, also called toners, are used to locate, trace, and isolate cables in copper media networks. Telephone test sets, also called butt sets, are specialized telephones that connect to telephone lines to check for proper operation and to isolate trouble. Some test sets incorporate a TDR (time-domain reflectometer) and toner for determining cable length and locating faults. While certain devices may be used on live networks, others are only suitable for inactive networks. Field technicians and installers use these devices to set up, maintain, and troubleshoot datacom and telecom cabling within a building or in outside plant (OSP) applications. Fluke Networks manufactures tools for network infrastructure installation, testing, certification, and troubleshooting, in copper, fiber, and wireless networks, with its tools widely used by contractors, enterprises, and communication service providers. The company, which operates globally, is based in Everett, WA. What's in the Box? Fluke Networks Pro3000 Analog Tone Generator Fluke Networks Pro3000 Analog Probe (2) Angled Bed-of-Nails Clips (1) RJ11 Plug Nylon carrying pouch Instructions PLEASE READ TERMS BEFORE ORDERING: WE ONLY ARE ABLE TO SHIP TO THE LOWER 48 STATES AT THIS TIME. ITEMS MAY BE SHIPPED DIRECTLY FROM OUR LOCATION OR SUPPLIER TO GET IT TO YOU ASAP. IN THE UNLIKELY EVENT THAT THE ITEM MAY BE SOLD OUT OR ON BACK ORDER WE WILL REFUND YOUR MONEY. WE SHIP TO PHYSICAL ADDRESSES ONLY. NO P.O. BOXES. NO LOCAL PICKUPS. REFUNDS MAY BE SUBJECT TO 15%-30% RESTOCKING FEE, DEPENDING ON THE ITEM.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Fluke
MPN	26000900
UPC	Fluke Networks 26000900 Pro3000 Tone Generator and Probe Kit
