Fluke Ts 30 Test Set / 30800001

US $230.00

Ravensdale, Washington, United States
Jun 9th

Open on mobile:
QR code

TS® 30 Series Test Sets The TS30 features the latest in test set case design, at an affordable price. High impedance DataSafeTM operation in monitor mode DropSafeTM reliability passes 20-foot drop test RainSafeTM protection in severe weather conditions Mute switch Last number redial Audible ringer for callbacks Overview Recognized as the industry standard for basic test sets, the TS30 Test Set provides superior quality at an affordable price. With its high impedance Monitor for DataSafe™ operation, technicians can clip onto a line in Monitor mode without disrupting existing traffic. Fluke Networks’ unsurpassed RainSafe™ protection standards and DropSafe™ durability assure the test set will keep working even in the toughest environments. Solid weatherproofing provides enhanced resistance to severe weather conditions. Features Rugged butt-in telephone test set at an affordable price Models & Accessories Models Model Number/Name Description 30800001 TS30 test set with piercing pin clips 30800009 TS30 test set with ABN 12001005 TS120 test set with alligator clips (outside of N. America only) Specifications Electrical Return Loss >14 dB (ref 600 ?) Line Current Range 15 mA to 120 mA Resistance to Continuous Current (Talk Mode) 275 ? typical at 20 mA Monitor Mode Impedance >120,000 ? 300 Hz to 3400 Hz Pulse Dial Output Pulsing Rate 10 pps pps Open/Close Ratio 60/40 Inter-digit Interval 800 ms %, -10% Resistance During Pulse Open > 200,000 ? Protection Against Alternating Current Overvoltage The TS30 survives up to 250 Vrms across its test leads. Peak Acoustic Output of the Receiver <120 dBspl DTMF Output Tone Frequencies Tone Frequency Error per ITU-T Q.23 ±1.5% Maximum Tone Level High Group Low Group -4 dBm (into 600 ?) -6 dBm (into 600 ?) High vs Low Tone Difference 2dB +1db Last Number Redial (Tone/Pulse) Memory Capacity Memory Retention 23 digits 8-minutes nominal Flash Duration 600 ms ±100 ms Ringer Loudness > 70 dBA at 1 meter Ringer Equivalent (REN) 0.14 Measurements 10 in x 2.83 in x 3.34 in (25.5 cm x 7.2 cm x 8.5 cm) Weight 16.8 ounces (0.476 kg) Environmental Temperature Operating Storage -4 °F to +140 °F (-20°C to +60°C) -40 °F to +151 °F (-40°C to +66°C) Relative Humidity 5% to 95% Safety Telecom Electrical TNV-3 Safety Classification IP54 Regulatory Standards Used 47 CFR Part 15, Subpart B ICES-003 Issue 3 AS/NZS 3548 EMC Directive 89/336/EEC, EN 55022:98, EN 61326:97, A1:98 Annex C, EN 61000-4-2, EN 61000-4-3 LV Directive 73/23/EEC, EN 610010.1 (1993) Certifications and Compliance Conformite Europeenne. Conforms to relevant European Union directives. CAN/CSA-C22.2 No. 60950-1-03 CAN/CSA-C22.2 No. 1010.1-92 CSA-C22.2 No. 1010.1B-97, UL/ANSI 3111-1 Notes: Specifications subject to change without notice. Legal requirements may exist regarding permission to connect equipment to a Telecom network opterated by a public network operator. Documents Catalogs Title/Description Download Fluke Networks? Solution Catalog NEW 68 page guide to selection and ordering Fluke Networks? Solutions and Products Download PDF 7.32 MB Demos Title/Description Demo Terminate to Test Demo View Demo

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Fluke
MPN	2328034
Model	30800001
Country/Region of Manufacture	China
