Fluorescent Green Futaba M202SD04A VFD Display Module 20 Char x 2 Lines, US $35.00 – Picture 0
Fluorescent Green Futaba M202SD04A VFD Display Module 20 Char x 2 Lines, US $35.00 – Picture 0

Fluorescent Green Futaba M202sd04a Vfd Display Module 20 Char X 2 Lines

US $35.00

  • Lockport, Illinois, United States
  • Jan 29th
Open on mobile:
QR code
Futaba M202SD04A VFD Display Module This vacuum fluorescent display (VFD) module consists of a 20 character by 2 line 5x8 dot  matrix display, DC-DC/AC converter, and controller/driver circuitry.  The module can be configured for a Motorola M68-type parallel interface, an Intel I80-type  parallel interface, or a synchronous serial interface.  A character generator ROM with 240 5x8 characters is provided along with RAM for the  user to program an additional 8 characters. The luminance level of the VFD can be varied by  setting two bits in the function set instruction.  Two hundred and forty character fonts consisting of a alphabets, numerals and other  symbols can be displayed.  This module has a dual-port RAM that allows data and instructions to be the module  continuously. Thus, the busy flag is always 0 and the host never has to read the busy flag bit  to determine if the module is busy.  Due to this feature, the execution times for each instruction are not specified.  Item Value  Number of characters 20 characters x 2 lines  Character configuration 5x8 dot matrix  Character Height 5.34 mm  Character Width 2.35 mm  Character Pitch 3.60 mm  Line Pitch 6.16 mm  Dot Size 0.39 x 0.58 mm  Dot Pitch 0.49 x 0.68 mm  Peak Wavelength of  Illumination Green (p=505nm) x=0.235, y=0.405  Luminance Minimum  350 cd/m2 Typical  500 cd/m2 Display tested as working and being sold "As Is" with no warranties for you specific electronic needs or electrical abilities, faults or errors on installations, drivers, supply power or infinite other factors that may effect performance of the unit. Specification believed to be as accurate from mfg spec data posted.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Futaba
Model M202SD04A
