Flygt Multitrode Pump Controller Mt2pc

US $350.00

Woodlyn, Pennsylvania, United States
Jan 30th

Open on mobile:
QR code

Easy level settings via keypad or laptop PC. Full mode control for pumps and alarms. Level indication, pump and fault status. Monitors four levels of motor faults. Multiple pump operation - up to 9 pumps. Multiple level inputs from multi-sensor probe, 4-20mA or ball floats. Automatic probe backup when using 4-20mA analog input. Industry standard communications, RS485 & RS232. Connects directly to a MonitorPro for total control panel solution. Din-rail mountable base unit and removable keypad for remote mounting. Station efficiency improvement functions. Plug-in screw terminals. In-built transient protection. Two levels of security access. Remote mimic & control (up to 3000ft). Configurable inputs & outputs. The Duplex MT2PC Pump Controllers offer advanced control functions in a compact integrated controller. MultiTrode pump controllers provide level and pump status at a glance in an intuitive interface for operating pumps, resetting alarms, pump alternation and level settings. In addition, more than 50 preset essential and useful pump management functions are incorporated to safeguard and protect equipment, as well as reduce or eliminate common problems such as water hammer, station odors and fat problems. Operators can change level set points and many other functions easily, in seconds, all via keypad. This product has set the standard in pump controllers. Complex wiring and many standard components such as timers, thermistors, alternators, seal failure devices, flashing and level sensing relays, indicator lights and switches are eliminated. This not only simplifies and reduces the size of the panel, but reduces costs, and enables operations and maintenance personnel to efficiently control their water and wastewater pump stations. Pump Controller MT2PC Duplex ControllersVisual Indication Pump mode (auto/off/hand), lead/alternation, next pump to start, liquid level, high/low level alarms and several individual pump faults (active and unacknowledged) are displayed at a glance. Fail-safe Hand/Off Mode: Operators sometimes forget to set pumps back to Auto when leaving a station. With "Hand/Auto”; Fail Safe, pumps will never be damaged. Level Alarm Muting Level alarms can be temporarily muted or disabled to allow work to be carried out without the distraction of visual and audible alarms. Level Simulation Level simulation eliminates the common, but very risky, practice of leaning into the well to move level sensing devices to check pump and alarm activation. Maximum Number of Pumps to Run The number of pumps allowed to run at one time can be preset. This prevents electrical overloads and also protects the hydraulic network from excessive pressure. Jockey Pump Control When using jockey pumps, it is beneficial to turn off the jockey pump(s) when a large pump is activated during peak periods. Group alternation is also available. Multi-well Mode The Split or Multi-well design enables one well to be shut down for maintenance, while inflow is diverted into the other. In the past, pumps either ran dry or could not keep up due to the flow equalization between pits. MultiTrode’s pump controllers correctly manage both pits and alternate the pumps. Municipal Functions Blocked pump detection Eliminates the damage to pump seals and wasted energy caused by blocked pumps. The controller can be set to allow several attempts at restarting before locking out the pump. Odor reduction Complaints from residents regarding odor are a problem with some stations. These controllers have a configurable maximum off-time function which prevents wells turning septic during periods of low activity. Excessive station starts Excessive starts can result in pump and control damage and excessive energy consumption. MultiTrode controllers offer innovative solutions by monitoring pump starts and adaptively changing level set points so as to minimize starts during peak periods. Reduced station fat build-up Random duty start delay can be set to prevent fat build-up at the activation level. Preset factory defaults Are available for both water and sewage, greatly simplifying installation. Advanced Pump Protection Flygt seal and thermal faults Flygt seal and thermal (minicas) as well as standard thermistor and pump seal monitoring and protection functions are incorporated in the controller. This reduces panel components, cost and complexity, and provides advanced pump protection, resulting in improved reliability. Excessive pump starts Pumps are designed to have a maximum number of starts per hour. By setting the controller to the manufacturer’s recommended value, additional protection is provided. Critical and non-critical faults By separating the critical, non-critical and delay faults, reliable user-selected fault detection is provided . Peak Level The controller can store two groups of set operating points and time delays for all pumps and level alarms. These can be activated via a digital input from a timer or via Outpost municipal SCADA. Off-Peak Pumping Significant energy savings can be achieved in municipal water applications by pumping in off-peak periods. Pulse start, hold out and peak levels provide valuable tools to effectively manage both water and sewerage networks. Pump Decommissioning This feature allows the operator to decommission a pump that is requiring maintenance. Pump decommissioning can also be used where a second or third pump is to be installed in the future, saving control panel modifications when the additional pumps are installed. Charge/Discharge Mode The pump controller can be used for both water and sewer applications, helping with standardization across a municipal authority's network. Each mode has preset factory default settings to simplify installation. Level Indication Pump Status DIN-rail Mounting Transient Protection RS485, RS422 & RS232 Communications Plug-in Screw Terminals Connects Directly to MonitorPro Communications Port Level Sensing Input Options for Probe, 4-20mA & Ball floats Low Voltage Detachable Keypad Simple Programming via Keypad Dual Supply 110V AC &12V DC Configurable Outputs The user may configure up to 5 digital outputs. Each output can be activated from a selection of 64 sources, e.g. desired station starts exceeded, well washer on, all pumps unavailable, level device fault, no pumps running, thermal fault, or any pumps running, etc. Additionally, each output can be set as a N/C or N/O relay, providing flexible control and indication to other devices. Redundant Level Sensing Where analog level sensors are used, a probe can be used as a redundant level sensor. Alternation Comprehensive pump alternation, duty selection and grouping options are easily selected via the keypad. Fault Enunciation Fixed Starting Order Pump start, sequence fixed. Alternation Starting Pump start, sequence alternates. Two Groups Alternating Jockey pump mode: Group 2 on Group 1 off Display: LEDs High Intensity ( Red & Green) Mounting Panel mounted or internal. (DIN Rail) * Keypad may be remotely mounted. Enclosure Extruded aluminum Power Supply: Supply Voltage AC 110, Nominal 50/60Hz 18VA Max Supply Voltage DC 10-30VDC - 6 watts max. Environmental Range: Fahrenheit +140 F to +1400 F Centigrade - 100 C to +600 C Humidity 90% non condensing Available Models & Ordering Information: MT2PC 110VAC & 10-30VDC Mode of Operation: Mode Charge or Discharge (Fill or Empty) Probe Inputs: Sensor inputs 10 Sensor voltage 5VAC Nominal Sensor current 0.8mA max. (per sensor) Sensitivity 1k, 2k, 4k ,10k, 15k 20k, 30k, 40k, 80k, 120k Other Inputs: Analog 4-20mA x 2 Fault inputs Critical, Non-critical, Delay fail, Thermistor & Seal fail for each pump, Keypad lockout, Power fail Pulse start, Power fail(Hold out), Peak Levels All inputs are also configurable as SCADA inputs Relay Outputs: No of relay outputs MT2PC - 2 Pumps + 5 Configurable Output delays 0.25 sec to 120 min Relay contact rating 250VAC 5A Resistive, 2A Inductive Relay contact life 105 Operations Terminal size 2 x 13 AWG / 2.5mm2 Other outputs Keypad (can be remotely mounted) Analog 4-20mA, (locally powered via 13.8vdc supply) - Optional external supply maximum 15vdc - Maximum allowable loop resistance 500 Ohms Communications: Local area network Digital RS485

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second, or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Flygt
MPN	MT2PC
Model	MT2PC
