FMCW FSK VCO RADAR TRANSCEIVER 24GHZ K-Band Module Speed Motion Distance Doppler, US $230 – Picture 0
FMCW FSK VCO RADAR TRANSCEIVER 24GHZ K-Band Module Speed Motion Distance Doppler, US $230 – Picture 0

Fmcw Fsk Vco Radar Transceiver 24ghz K-band Module Speed Motion Distance Doppler

US $230

  • Darstein, Germany
  • Jun 9th
Open on mobile:
QR code
You get a new microwave 24 GHz K-band radar VCO transistor transceiver module with integrated transmit and receive antennas . Due to newest integrated technology the module runs with much lower power consumption than gunn diode modules. The module can be used as rf part of a doppler speed detector or as doppler movement detector. It can be used as RF signal source and as transmitter and receiver in the K-band for FM applications. In a K-Band FMCW radar application you can measure the distance to objects, in a FSK applications data can be transmitted and received. In a VCO application you can use it as test module for testing doppler sensors and to measure the sensitivity of microwave receivers or K-band radar detectors. SPECIFICATIONS:                     DRM-24G-VCO-NB K-Band Module                          Transistor Oscillator TX Frequency:                           24.125 GHz  TX Power Eirp:                           +20 dBm max. RX Frequency:                           24.125 GHz (doppler) Tuning Frequency:                    24.000 GHz to 24250 GHz  Tuning Voltage:                          0.5 to +10 Volt Tuning Slope:                             40 MHz/V min. Modulation Input:                       150 kHz max. IF Output:                                    I / Q RF Output:                                  Stripline Antenna Antennas:                                   One  TX and one RX for max. sensitivity                                                      Horizontal 45 deg Vertical 37 deg typ.                          Temperature drift:                     minus 1 MHz/deg C Power requirements:                5VDC @ 50mA typ. Dimensions:                               1.77 x 1.18 x 0.34 in   or 45 x 30 x 9 mm Weight :                                       about 60 grams Please ask for actual delivery time. Other specifications and quantities are available on request. For additional information please look at our other Ebay store or feel free to contact us . European buyers have to add 19% VAT.
